INSTRUCTION MANUAL
19''-Patch Panel for 24 eLAN
A. Mount the jack on the panel as shown in figure
1 and 2.
B. To mount the cable management, align the bar
to the opening of the panel as shown in figure 3.
C. Push the cable management bar to fix the
management on the panel, as shown in figure 4
and 5.
D. Use a cable tie to fix the cable on the cable
management as shown in figure 6.
(part-no. EX-P24U-0.5)
®
-Jacks
TIX
Advertisement
Table of Contents
Summary of Contents for eLANtix EX-P24U-0.5
- Page 1 INSTRUCTION MANUAL ® 19’’-Patch Panel for 24 eLAN -Jacks (part-no. EX-P24U-0.5) A. Mount the jack on the panel as shown in figure 1 and 2. B. To mount the cable management, align the bar to the opening of the panel as shown in figure 3.
- Page 2 Montageanleitung ® 19’’-Patch Panel für 24 eLAN -Jacks (Art.-Nr.: EX-P24U-0.5) ® A. Setzen Sie das eLAN -Modul in die Aussparung im Patchpanel mit der unteren ® Kante (eLAN -Logo oben) leicht schräg ein, wie es in Abb. 1 und 2 zu sehen ist.
