Summary of Contents for Shulz Krabi
- Page 1 Manual...
- Page 3 NON-USE OF THE INFORMATION SPECIFIED IN THE PRESENT MANUAL. THIS IS A SHORT MANUAL ON THE USE, REPAIR AND MAIN- TENANCE OF A BIKE. IF THERE ARE NO ANSWERS TO SOME OF YOUR QUESTIONS IN THIS INSTRUCTION, CONTACT SHULZ BIKES...
- Page 4 Introduction All Shulz folding bicycles are meant to ride only on solid road surface (pavement, dirt roads, etc.) and do not suit for cross-country riding. Stunt riding, jumps and extreme loads on Shulz bikes are not recommended. The rider’s weight should not exceed the maximum permissible (technical specifics of a particular model are listed on the site www.shulzbikes.ru).
-
Page 5: On The Road
Safety WARNING: Remember that only you are responsible for ensuring that you have all the accessories required by local laws — a head- and a taillight, special clothing with reflective elements, etc. Check out all local laws regarding cycling. First of all, there could be information about mandatory lighting equipment, registration of a bike, and the rules for cycling on public highways or for transporting a bike by public transport, etc. - Page 6 Safety Obey traffic laws, ride along special cycle lane or shared paths if there are any. Be extremely careful at the intersection and always stop at red traffic light. Remember that a cyclist suffers the most when involved in a collision with a car. —...
-
Page 7: Before The Ride
Adjust the brakes if necessary. 5. Make sure that the front and rear wheels, the saddle, seat post, handlebar and grips are firmly fixed. 6. Ensure that the battery is fully charged (on Shulz models with an electric motor). The first ride It is better to take the first ride on a new bike away from traffic, other cyclists, various obstacles and other dangers. -
Page 8: Folding And Unfolding
Folding and unfolding If you’ve bought the Shulz® folding bike , it’s important to learn how to fold it correctly so it takes up little space during storage and transportation as it’s supposed to. Fold the bike in the following order: –... -
Page 9: Saddle Adjustment
If your leg is bent more than slightly, your seat should be adjusted up. If you can’t reach the pedal, your seat should be adjusted down. On most Shulz models there is a special scale on the seat post, so it’s easy to remember the height that that suits you the best. -
Page 10: Front Wheel
Front wheel It may become necessary to remove the wheel to transport the bike or repair. 1. Remove the front wheel: — if you have front rim brake, open the brake, clipping the holding device off, this allows your brake pads to be far enough from the rim for your tire to slide past them;... -
Page 11: Rear Wheel
Rear wheel The rear wheel can be attached using a quick release, nuts or bolts. 1. Remove the rear wheel: — if you have rear rim brake, open the brake, clipping the holding device off, this allows your brake pads to be far enough from the rim for your tire to slide past them; —... -
Page 12: Bicycle Components
Bicycle components Shulz E-GOA as an example... - Page 13 1. Saddle 2. Seat post 3. Handlebar and grips (handles) 4. Brake lever 5. Folding stem 6. Bicycle headset 7. Frame 8. Bottle cage fastening screws 9. Fork 10. Wheel (tire, tube, rim, spokes, hub) 11. Pedal 12. Crankset (bottom bracket, cranks, sprocket) 13.
- Page 14 Brakes Shulz bikes can have rim or disc brakes. The rear brake can also be integrated into the rear hub. Rim brakes work due to friction between the brake pads and rims that occurs when the brake lever is pressed. That is why it is necessary to pay attention to the degree of wear of the brake pads and rims and keep them clean —...
-
Page 15: Shifting Gears
Shifting gears There are two shifting systems on Shulz bicycles: the derailleur or the rear planetary hub. If your bike has a derailleur shifting system, the gear shift mechanism will include: — a set of rear sprockets (cassette or ratchet);... -
Page 16: Planetary Hub
Chain Shulz single-speed bicycle models, as well as planetary hub models, is equipped a standard sin- gle-speed 1/2 x 1/8 chain. Multi-speed models have narrow chains with a dimension of 1/2 x 3/32. The chain service life is heavily dependent on the usage conditions of the bike, and a dealer or a qualified mechanic will help you determine the degree of wear. - Page 17 Tires and inner tubes Shulz bicycles are equipped with universal type of tires, which has a good coasting on paved roads and also has good grip on soil roads. On the sidewall of the tire there are indications of its dimensions and the range of working pressure.
-
Page 18: Battery Charging
Electric bike control If you have a Shulz bike with an electric motor, there are two usage options: you can ride it like a reg- ular bike with the electric motor turned off or you chose electric mode with that the electric motor in the front wheel will turn on itself and help you when you pedal. -
Page 19: Maintenance
Maintenance A bicycle, like any other mechanism, can wear out. Different bike components have a different service life, so it is important to monitor even the new bike’s condition so that it does not let you down at the most wrong time. It’s impossible for this manual to provide all the information required to repair and maintain every bicycle. - Page 20 Notes...
- Page 21 Notes...
- Page 22 Notes...
- Page 24 www.shulz.ru...
