GENERAL INFORMATION:

Two super bright LED arrays, 44 LED's per side. There are other array combinations to suit your jurisdiction or

ordinance requirements from RED, BLUE, AMBER, GREEN or WHITE LED's. Each array equipped with vertical

rows of white LEDs at their outer edges to provide the "halo" effect pioneered by ALERTE to enhance visibility.

Seven flash patterns to choose from:

90 Single FPM Simultaneous

90 Double FPM Simultaneous

70 Quad FPM Simultaneous

120 Alternating FPM

Automatic Alternating Variable Speed

Automatic Simultaneous Variable Speed

Automatic Random Select

To change flash pattern, press the momentary switch (Located on the lighter plug adapter). Each time the

momentary switch is pressed, the flash pattern will change.

INSTALLATION INSTRUCTIONS:

Position the "Visor Light" on the visor, normally on the passenger side with the lenses facing downward when the

visor is in the up position.

Fasten the straps over the visor and position the "Visor Light" with its bottom edge even with the lower edge of the

visor. Tighten the straps to snug the "Visor Light" against the visor.

Clean the cable clip location on the windshield column and the dash with 409

affixing the clips. This procedure is particularly important if a silicone-based protectant such as Armor All

used on these surfaces. Failure to adequately clean the clip mounting locations may prevent the adhesive on the

clips from securing a sound, long-lasting grip.

Place the cable in the clips. Open the clips only as much as necessary to insert the cable.

To operate, flip the visor down, insert the cable plug into the cigarette lighter socket and switch on.

NOTE: If the "Visor Light" is to be permanently wired, please specify at the time of the order, so when manufacturing

your light we can adjust the location of the switch. The current switch is located on the cigarette adapter.

Local & International Numbers:

Phone 417-846-2222 / Fax 417-846-2506

MODEL NO. 10.730

Visor Light 88

A L

E R

T E

A L

E R



T E



A L

E R

T E



ALERTE SYSTEMS INC

901 W 10th Street / P.O. Box 586 / Cassville, MO 65625

, Fantastic

, or the equivalent prior to

U.S. and Canada Toll-Free Numbers:

Phone 800-728-1536 / Fax 800-635-1536

has been

05-27-09
