  • Page 2 User Manual JK4000 Series Multi-channel Temperature Recorder Changzhou Jinailian Electronic Technology Co., Ltd No.C3,Building 22,New Impetus Pioneering Center, No.1,Qingyang North Road,Tianning District,Changzhou,Jiangsu,CN TEL: 0086-519-85563477 FAX: 0086-519-85565067 https://jinailian.en.alibaba.com www.jk17.com www.jaldz.com An instruction manual Ver1.0...
  • Page 3 Catalog Chapter One Safety and warranty.........................1 Introduction of instrument.........................2 Application............................3 Chapter Two Difference of temperature recorder....................4 General overview of temperature recorder..................5 Chapter Three Fast introduction..........................7 Introduction of product front panel....................7 Product rear panel introduction......................9 Display and function key introduction.....................11 Parameters setting..........................13 Chapter Four Installation and accessories......................15 Chapter Five...
  • Page 4 Preface Summary The new multi-channel temperature recorder has ultra-thin chassis, light weight, small volume At the same time, the digital synchronous sampling technology has the and easy to carry. advantages of fast measuring speed, high precision, easy to use, light and beautiful and so on. The instrument test precision is 0.5.
  • Page 5 Chapter One Security Do not install on your instrument instead of parts, or execute any unauthorized modification.Please send the instrument to the maintenance department of the company to maintain it, so as to ensure its safety characteristics. Security rules In order to prevent electric shock, not authorized personnel of the company, it is strictly forbidden to disassemble the instrument and strictly prohibit the use of the equipment on the life maintenance system or any other equipment with safety requirements.We are not responsible for direct or indirect financial losses that may occur when using this product.
  • Page 6 Brief introduction JK4000 is a high performance, low price temperature recorder. It can watch multi-channel temperature changes at the same time.It is very suitable for application of temperature acquisition and temperature recording.It has the RS232 interface to upload data directly to the PC, and also has the USB interface to save the measured data directly to the U disk when it is inconvenient to connect to the PC, and then transfer the data to the PC when needed.It is a half frame wide host with a top 64 channel direct slot on the back of which can be measured with a thermocouple,...
  • Page 7 Application Instrument safety index ◆Insulation resistance: the outer part of the housing and the power input are larger than 20MΩ. ◆ Withstand voltage: the power input terminal and the housing are 2 seconds withstanding voltage 1800V, and the rated current is 10mA. ◆Grounding: the power grounding pole, and the resistance between the outer shells is less than 0.2Ω。...
  • Page 8 7 kinds of thermocouples Two screens +PT100 thermal resistance 108 way 7 kinds of thermocouples acquisition module +PT100 thermal resistance The specification and measurement range of JK4000 series input type Input type Specifications measuring range Pt100 -200~850℃ Thermal resistance（RTD） 600~1800℃ -30~800℃ -100~1200℃...
  • Page 9 In table 10, 4000+108 indicates that customers can choose how many channels to collect temperature according to their needs and choose a 108 acquisition module with 8 channels as a unit in the case of a host. If you need 80 channels, you can choose a 64 way host and 2 108 acquisition modules.
  • Page 10 The above information is measured under the following conditions:  Temperature conditions: 23℃±5℃  Humidity conditions: 65% R.H.  Warm-up time: >10 minutes  Calibration time: 12 months Measurement environment:  Index: Temperature 15℃~35℃ Humidity <80%RH  Operation: temperature 10℃~40℃ humidity 10~90%RH ...
  • Page 11 Chapter three Product introduction front panel Introduction of front panel 1 ：display screen 2 ：power 3 ：System function key 4 ：USB disk interface 5 ：Qualified / unqualified 6 ：Lock key 7 ：Digital keyboard 8：Cursor key 9：show key 7/20...
  • Page 12 Display area schematic: 1 ：Display date / time: as shown in the picture 1th January,2007,At 20:26 00 seconds 2 ：Show the temperature of each channel, respectively（001 represents the first channels, 002 represents the second channels), and so on. 3：Thermocouple model 4: Unit of temperature 8/20...
  • Page 13 Rear panel schematic: As shown in the picture. 1：Indicating the interface definition of each channel number and input signal（01 represents 1 channels, 02 represents 2 channels, and so on.） Signal wiring method： 3-3 Terminal description Thermocouple positive terminal Thermocouple negative terminal Ground *Other channel connections are the same as above The isolation voltage between channels is DC 350V, AC 230V...
  • Page 14 4：The RS232 interface can directly upload the data measured to the PC through the RS232 cable line and the host computer software (RS232 and USB choose one). 5:CASCADING: Used for channel expansion and alarm relay contact output terminal, when alarm relay output, contact signal as shown in the figure: 2,3 are normally closed contacts 3,4 are normally open contacts Contact load capacity is DC 24V/1A...
  • Page 15 Equipment parameter page introduction: Channel number: number of test instruments Baud rate: communication rate between instrument and host computer Device address: the host computer inquires the address of the machine Sampling time: speed of reading temperature and data Unit of temperature: a unit of temperature:（℉，℃） Automatic screen change: when the number of passages exceeds 32, the temperature needs multi page display.
  • Page 16 6. Automatic screen switching：ON/OFF Switch. 7.Time settings: set the year, month, hour, minute and seconds that you need to display. 8. Buzzer alarm: when the temperature is adjusted to "ON", if the temperature exceeds the upper limit or lower limit set by you, there is a sound of sound. If it is adjusted to "OFF", there is no sound hint.
  • Page 17 X axis length: X axis time value, 1min~999min can be set freely. Y axis range: Y axis temperature range, -1999~+1999,If you want to set negative numbers, you need to make sure that when the number is not 0 Change+/-. X axis grid number: X axis grid number, 1~9 can be set freely. Y axis grid number: Y axis grid number, 1~9 can be set freely.
  • Page 18 Introduction of Function setting interface At any interface, just press the "DISP" button to return to the Function setting interface. According to the U disk , you can enter the Function setting interface, as shown in the figure. Press the up and down button to select the U save and click Set End . system information The system information interface includes: Instrument model...
  • Page 19 Chapter Four Install Make sure that you receive the following components when you receive multiple temperature records. If there is any shortage, please contact your dealer as soon as possible. Users choose different power JK-E171 lines according to the specifications of JK-E172 the power outlets in the area.
  • Page 20 the back side of the instrument (the front panel is the U disk socket). USB communication requirements: we need to install USB driver software on the U disk to be used. Connect with the computer: connect the USB communication line with the instrument to the computer USB port.
  • Page 21 2. Click on the communication settings option to refresh the serial password. The baud rate of 9600 remains unchanged. 3. Click on the instrument settings option to select the thermocouple model. 17/20...
  • Page 22 4. Click on the choice of curve settings, select the upper and lower limits. 5. Click on the measurement display, click on the start of the test, a curve appears. 18/20...
  • Page 23 In the measurement display interface, click on the testing, select the Excel file in the save path and view the historical data 19/20...
  • Page 24 In the File Options Interface, click View to view historical data and graphs in the save path, as well as data stored on the U disk from the instrument. Wireless mode transmission: Supporting virtual serial port, the computer must have wireless receiving function, and install virtual serial port software.
