Page 1: Table Of Contents
Website: www.aleddra.com Phone: (425) 430-4555 Technical Support: support@aleddra.com Introduction About This Product ..........2 Safety Precautions ......... 3 Name of the Parts .......... 5 Settings ……… ........... 6 How to Install ..........9 Maintenance ........... 10 Troubleshooting ..........13 Specifications...
Page 2: Introduction
Introduction The Sanitizing de-Odorization LED Lamp adopts photocatalyst technology and provides deodorization and sterilization for indoor use. It helps reducing airborne germs and minimizes household odors caused by bacteria, pets and cooking fumes. What is photocatalyst technology? When light is irradiated on the photocatalyst layer, a strong oxidation effect will be produced.
Page 3: Safety Precautions
Recommended Mounting Areas: • Your home or apartment • Senior and assisted living facilities • Hospital patient rooms and bathrooms • Waiting room in both medical and dental offices • General offices spaces • Classrooms and day care facilities • Restaurants and bars •...
Page 4  Do not use on equipment or circuits with dimming function.  Do not use on emergency lighting equipment, guidance light equipment, mercury lamp or HID lamp equipment.  Do not install or disassemble the lamp with wet hands.  Do not install the product on a broken or fragile lamp holder.
Page 5: Name Of The Parts
Name of the Parts...
Page 6: Settings
Settings Sanitizing de-Odorization LED Lamp has two modes:  Motion Sensor Mode  Manual Mode Before usage, please determine which mode would be applicable in your area. The default setting is Motion Sensor Mode. Motion Sensor Mode When the movement of a person is detected, the LED light will be on automatically.
Page 7 Manual Mode The LED light is turned on / off by the wall switch. When the LED light is on, the deodorizing and sterilizing functions will be activated at the same time. When the LED light is turned off by the wall switch, all the functions of the lamp will be shut off.
Page 8 How to switch between two modes:...
Page 9: How To Install
How to Install Hold the bottom of the main unit and plug it into the E26 socket. Be sure to turn off the wall switch during installation. Be careful not to over tighten the lamp. Do not install in places where the Pre-filter will be hidden, such as downlights.
Page 10: Maintenance
Maintenance This product is a device that collects bad odor components throughout the room, improves the indoor air quality. If the photocatalyst filter have odors or an insulator attached, the deodorizing and disinfecting effect will be reduced. In this case, clean the photocatalyst filter properly.
Page 11 Photocatalyst Filter: Clean every 6 months...
Page 12 Housing (Air Outlet / LED Light / Motion Sensor / Lamp Holder) Use a soft and dry cloth to remove dirt. Note: 1. Do not use detergent, soap, chemicals or oil to clean the photocatalyst filter. 2. Do not use brush to clean the photocatalyst filter. 3.
Page 13: Troubleshooting
Troubleshooting Situations Please Check: Personnel has left The light will keep operating for the room but the three minutes since motion was light is still on detected. When there’s no motion detected, The light was off the LED light will be off. It depends when the on the speed of movement, the personnel is still...
Page 14: Specifications
In this case, clean the photocatalyst filter properly. Specifications Sanitizing de-Odorization Product Name LED Lamp Model # KL-B01 Wattage Power Requirement 100-240VAC at 50/60Hz Color Temperature 2700K Light Output 485 lm Cover Area 30 sq.
