Summary of Contents for TIMPANO TPT-SP4BT
- Page 1 TPT-SP4BT Sound Processor 4-CHANNEL DSP CONTROLLED BY A WIRELESS (BT) CONNECTION USER MANUAL USER MANUAL...
-
Page 2: Before Installing
Introduction Thank you for choosing a TIMPANO product! The TPT-SP4BT is a digital audio processor that offers a variety of high- precision adjustments and settings to enhance the performance of your audio system. Through Bluetooth communication, the processor’s information can be viewed and configured remotely using smartphones with Android or iOS systems. - Page 3 ▪ Perform the installation on a firm surface in a ventilated and dry place. ▪ Installation should only be done by a qualified professional. If you have questions , contact the store where the purchase or installation was done. For more information please contact our Customer Service: (954) 859-5529 Features ▪...
-
Page 4: Processor Overview
Processor Overview Audio Processor TPT-SP4BT 1. REMOTE OUT / SEQUENCER: This feature allows sequenced startup of other products through your remote connection (REM). Make the connection using a minimum 18 AWG cable. Each connection can be configured, enabled or disabled by the application or SMC control. - Page 5 4. POSITIVE POWER CONNECTOR (+BAT): Connect to the positive battery terminal using a minimum 13 AWG cable. It is recommended to use a 1A fuse for external protection. 5. SERVICE CONNECTION: Dedicated connection for authorized support services and updates. 6. AUDIO INPUT WITH WIRE CONNECTION (HIGH INPUT): HIGH INPUT type audio connection with independent action (A and B).
-
Page 6: Installation
▪ The use of fuse is mandatory to protect the system from short circuit and overload. Install them as close to the battery as possible. REM (remote) POWER SUPPLY Radio / Player 13 AWG cables 18 AWG cable TIMPANO Fuse SEQUENCER Install it close Outputs for remote Ground to the battery activation (12”... -
Page 7: Using The Application
RCA connection, the activation must be done by the remote input (REM IN). Using the Application Before you synchronize the TPT-SP4BT with your device, make sure that it has the minimum requirements to operate correctly with the processor application. - Page 8 Pairing with the processor To connect the processor to the application via Bluetooth, follow these instructions: Turn on the TPT-SP4BT and start the APP. Demo mode allows you to use the application without processor connection (some functions will be unavailable in this mode).
- Page 9 The default password for pairing is: 123456. For added security, change the password later in the settings menu. When using the TPT-SP4BT processor for the first time, it is necessary to install some functions and updates. This process is quick and mandatory to ensure the best performance of the processor.
- Page 10 After starting the processor update process, wait for the automatic completion of this process. When completed, the processor will automatically restart and the application will be directed to the search screen to reconnect the processor. With the connection successfully established, the application will be directed to the main menu and will be ready for use.
- Page 11 APP functions and features Learn about some of the functionalities and features present in the main screen of the application. Settings Shortcuts panel Connection status Change app Simplified real-time Connection status and processor control and visualization and opens the device preferences.
-
Page 12: Reset Factory Settings
Reset factory settings It is possible to restore the factory image of the processor. This is important if the user forgets the pairing password or the processor has some other problem that does not allow the connection. To reset, follow these steps: 1. -
Page 13: Troubleshooting
Troubleshooting PRODUCT DOES NOT TURN ON: ▪ Check that the cables are connected correctly. Make sure that all connections have electrical and mechanical contact. ▪ Fuses or circuit breakers may be defective or blown. Check the condition of the circuit breakers and whether it is compatible with the consumption of the equipment. -
Page 14: Technical Specifications
Technical Specifications 2 x RCA (A+B) or 2 x HIGH INPUT (A+B) Number of channels: Input: 4 (1, 2, 3, 4) Output: 15 Bands (gain ±12dB) Graphic equalizer: Graphic equalizer presets: 5 Bands (1 Input + 4 Output) Parametric equalizer: (gain ±12dB, Factor Q 0.4 a 10.0) Butterworth: 12/18/24/36 dB/8ª... - Page 15 10V ~ 15V DC Power supply: Max. Output current SEQUENCER: 180 mA per output 170mA @ 12.6V DC Rated current consumption: 710mA @ 12.6V DC Maximum current consumption: Short Circuit (PTC fuse) Protection: Low Energy (LE) Bluetooth version: 15 meters* Range: Android 5.0 or higher Compatibility:...
- Page 16 19529 - R1...
