Written by Paula Araujo IT Project and Process Manager Alexey Shorokhov Industrial Designer Reviewed by Tim Kipley Infrastructure director Vitaly Kleban Slava Vityk Hardware engineer everynet.com...
5.5 Connect RF jumper cable to the gateway 5.6 Ethernet to gateway cable connection 5.7 Ethernet to PoE adapter cable connection 5.8 Verify all the connectors are correct 5.9 Check LEDs indication 5.10 Verify gateway is affixed securely on the tower History of revision part 6 everynet.com...
Objectives part 1 The purpose of this document is to provide cabling, installation, and bootup instructions of a Everynet gateway in an external or tower environment. Terms of use part 2 Installer MUST strictly follow installation requirements as conditions of product warranty.
EVERYNET under normal use and operation. EVERYNET sole and exclusive obligation and liability under the foregoing warranty shall be for EVERYNET, at its discretion, to repair or replace any Product that fails to conform to the above warranty during the above warranty period.
Page 6
Products will be error free or that operation will be uninterrupted. In no event shall EVERYNET be responsible for damages or claims of any nature or description relating to system performance, including coverage, buyer’s selection of products (including the Products) for buyer’s application and/or failure of products (including the Products) to meet government or regulatory requirements.
Do not use cellular phone data SIM ● Access to the SIM management platform ● for troubleshooting purposes -40 to +85 c temp range ● Each SIM selected must be from different ● carrier using different infrastructure and backhaul everynet.com...
● Follow antenna manufacturer recommended procedures ● Do not use any other attachment method Clamps ● Use only high quality stainless steel ring clamps to securely attach gateway to mounting pole ● Do not use plastic zip ties for attaching the gateway everynet.com...
● Use only 3 pin grounded power cord for PoE power NOTE: Verify with continuity meter that earth grounding pin of PoE power cable is continuous thru the power cord. 4.10 Recommended equipment ● Wire stripper/cutter ● 8P8C cable crimping pliers ● Cutting pliers everynet.com...
Preparing the Gateway and cabling the network part 5 5.1 Connectors specification 1. LoRa radio cable 2. SIM cards holders + USB + reset 3. Ethernet cable everynet.com...
Please see drawing below for grounding diagram. 5.3 Mount Antenna ● Install the clamps that will attach the antenna to the tower everynet.com...
Page 15
Tightening of RF connectors must be made by hand. ● Connect lighting protection and grounding strap to the grounding point on the tower. NOTE: It is not allowed to ground a lighting protector directly to the tower structures. everynet.com...
(one at top and one at bottom of connector). ● Verify weatherproofing on all cable connections 5.4 Mount Gateway Mounting gateway to tower pole ● Insert two steel ring clamps through the gateway ● Use metal ties only everynet.com...
Page 17
● Mount gateway on the tower pole. Tighten steel ring clamps everynet.com...
Page 18
● Penetrox or anti-oxidation agent must be used when attaching grounding strap to tower grounding point IMPORTANT: It is not permitted to ground the gateway directly to the tower structures. everynet.com...
N connectors with 3M Mastic Tape then at least two layers of Super 33+ sealing tape. Two zip tie wraps shall be used for top and bottom of sealing area (one at top and one at bottom of connector). everynet.com...
● Remove the shielding from the cable. ● Carefully fold the aluminum shield to expose the transparent plastic wrapping around the twisted pair cable. Be careful when trimming the braided cable to avoid cutting the shield and ground wire. everynet.com...
Page 21
● Place the wires in the correct order, leave half the foil to connect the shield to the plug. ● Insert the wires carefully into the RJ45 connector and press firmly to seat the wires into fully into the plug. ● Crimp completely and double-check cable wiring everynet.com...
Page 22
● Insert connector into the CONEC housing and screw nut. everynet.com...
● Use a TOUGHCable connector to measure the exposed cable needed (approximately 22mm) and trim accordingly. ● Remove the shielding from the cable. ● Carefully fold the aluminum shield to expose the transparent plastic wrapping around the twisted pair cable. everynet.com...
Page 24
● Insert the wires carefully into the RJ45 connector and press firmly to seat the wires into fully into the plug. ● Crimp completely and double-check cable wiring everynet.com...
Page 25
● Connect network cable POE port of PoE- Ubiquiti PoE 48v-24w injector ● Connect ethernet round wire to the tower according to the scheme. ● Connect PoE power cable to 3 pin AC power jack everynet.com...
5.9 Check LEDs indication ● Check that the connecting lights are in the correct colors. LTE – green ETH – red or green PWR – green or blue (blue means that the battery is charging) GPS – green LORA – green everynet.com...
To maintain compliance with FCC’s RF Exposure guidelines, The 20cm is the minimum distance that has to be maintained between your body and the device. 1. Scan QR code 1. Scan QR code 2. The label and text will appear below 2. The label and text will appear below everynet.com...
