Page 1 IEEE 802.15.4 OEM Module Electrical & Mechanical Datasheet cB-OZS311, cB-0922...
Page 2 Copyright © 2008 connectBlue AB. The contents of this document can be changed by connectBlue AB without prior notice and do not constitute any binding undertakings from connectBlue AB. connectBlue AB is not responsible under any circumstances for direct, indirect, unexpected damage or consequent damage that is caused by this document.
Page 3: Table Of Contents
Section 1.1 - Introduction.Overview Contents 1 Introduction Overview ....................4 Key features ..................4 Related Documents ................4 Product Variants ................5 Block Diagram cB-OZS311..............6 2 Electrical Interface and Connectors Overview ....................7 Pin Numbering ...................8 Pin Description ...................9 Characteristics .................12 Hardware Reset ................15 Power Control ..................15 3 Operating Status LED indication ..................16...
Page 4: Introduction
No external driver is needed. The IEEE 802.15.4 module has a small form factor and the interface layout is the same as the Bluetooth and Wireless LAN modules from connectBlue, which enables customers to prepare their device for both IEEE 802.15.4, Bluetooth and/or Wireless LAN.
Page 5: Product Variants
802.15.4 OEM Module based on the hardware cB-0922-02. “-02” is the revision of the PCB. The product name of the module is cB-OZS311 and is used for referring to the module in this document. The type approval sections refer to the Hardware name cB-0922-02 and is also the name which is used in the type approval process.
Page 6: Block Diagram Cb-Ozs311
Section 1.5 - Introduction.Block Diagram cB-OZS311 BLOCK DIAGRAM CB-OZS311 Figure 1: Block diagram of cB-OZS311 Version 1.3 - 2009-12...
Page 7: Electrical Interface And Connectors
Section 2.1 - Electrical Interface and Connectors.Overview 2 Electrical Interface and Connectors OVERVIEW This section describes the signals available on the module interface connectors. There are three ways to connect to the OEM Serial Port Adapter: • Via the PCB solder pads on the bottom side of the PCB, J6 (see Picture 2). See Section 5.4 for more information.
Page 8: Pin Numbering
Section 2.2 - Electrical Interface and Connectors.Pin Numbering PIN NUMBERING 2.2.1 J2, J3 and J6 Connectors Figure 2: Bottom view of the PCB with the pinning of the J2, J3 and the J6 connector. 2.2.2 JST 6-pol J8 Figure 3: Top view of the PCB with the pinning of the J8 connector. Version 1.3 - 2009-12...
Page 9: Pin Description
RED: Logic Red LED Signal (see Chapter 3, Table 8). Active low. Mode: Not used on cB-OZS311. This pin is also used to select Logic level mode (instead of RS232) for connectBlue products with internal RS232 driver. To be compatible with these products check the datasheet for these products about this signal.
Page 10 Section 2.3 - Electrical Interface and Connectors.Pin Description Pin Nr Signal Level J8 Pin Name Signal Name Type Description GREEN/ Green LED output and CMOS In/Out This signal is multiplexed: Switch-1 Restore switch GREEN: Logic Green LED Signal (see Chapter 3, Table 8).
Page 11 Section 2.3 - Electrical Interface and Connectors.Pin Description Pin Nr Signal Level J8 Pin Name Signal Name Type Description RESET Hardware reset CMOS In/Out Active low. Must be open drain collector. See section 2.5 for design examples. * All signals are logic level UART signals (typically 0 / 3VDC) Version 1.3 - 2009-12...
Page 12: Characteristics
Section 2.4 - Electrical Interface and Connectors.Characteristics CHARACTERISTICS The cB-OZS311 module has a linear power supply, which means that the current is constant if the voltage supply is changed (see Table 4). 2.4.1 Power supply NOTE: Read the safety notes in chapter 7 before using the modules.
Page 13 Section 2.4 - Electrical Interface and Connectors.Characteristics 2.4.2 Input/Output signals Table 5: Input/output signals Symbol Parameter Value Unit Logic LOW level input voltage except the -0.5 RESET signal RESET Logic LOW level input voltage -0.5 signal High Logic HIGH level input voltage on all logic RESET input pins except the signal...
Page 14 Section 2.4 - Electrical Interface and Connectors.Characteristics 2.4.4 Environmental Table 7: Temperatures characteristics Parameter Product Variant Value Unit °C Storage temperature °C +125 °C Maximum operating temperature cB-OZS311i/x-04 °C cB-OZS311i/x-06 °C Version 1.3 - 2009-12...
Page 15: Hardware Reset
Section 2.5 - Electrical Interface and Connectors.Hardware Reset HARDWARE RESET A hardware input is available on the J3 and J6 connectors (see section 2.2). An external RESET reset source must be open drain collector, see section 0 for design examples. The pin is RESET internally pulled-up with 10kΩ.
Page 16: Operating Status
Section 3.1 - Operating Status.LED indication 3 Operating Status LED INDICATION The module can be in different modes (see the Serial Port Adapter AT command Specification for more information about the modes) and the RED, GREEN and BLUE signals can be used to detect or indicating the status, see Table 8.
Page 17: Antennas
SMA connector through a short U.FL to SMA adapter cable. Reverse Polarity SMA antenna versions are also available for usage in US and Canada. Other antennas are also available on request (please contact connectBlue for more information). 4.2.1 Antenna Accessories...
Page 18 Section 4.2 - Antennas.External antennas Part Number cB-ACC-38 Name U.FL to Reverse Polarity SMA adap- ter cable Connector U.FL and reverse polarity SMA male Cable length 120 mm Cable loss Less than 0.5dB Comment The SMA connector may be mounted in a panel. Approved for use in the US, Canada and Europe.
Page 19 Section 4.2 - Antennas.External antennas 4.2.2 Antennas Part Number cB-ACC-16 Name WCR-2400-SMA Manufacture Centurion Type ½ wave dipole Polarization Vertical Gain +2.5dBi Size 100 mm (Straight) Connector SMA male Comment To be mounted on the U.FL to SMA adapter cable. Approval Approved for Europe.
Page 20 To be mounted on the U.FL to SMA adapter cable Approval Approved for Europe. Not approved for use in the US and Canada. Please contact connectBlue for information about US and Canada approved versions of the antenna. Version 1.3 - 2009-12...
Page 21 To be mounted on the U.FL to SMA adapter cable Approval Approved for Europe. Not approved for use in the US and Canada. Please contact connectBlue for information about US and Canada approved ver- sions of the antenna. Version 1.3 - 2009-12...
Page 22: Mounting Information
Section 5.1 - Mounting Information.Board Outlines 5 Mounting Information BOARD OUTLINES Figure 4: cB-OZS311 dimensions [mm]. Version 1.3 - 2009-12...
Page 23 Section 5.1 - Mounting Information.Board Outlines 5.1.1 Mounting Holes There are 2 x 2.3mm mounting holes on cB-OZS311. The reasons for the 2.3mm holes are that the threaded M2 holes on the single and double row connectors (see section 5.2.1) are not aligned.
Page 24: Using The J2/J3 Board-To-Board Connectors
When ordering connectors from Samtec or an official Samtec distributor, please use the ASP order number and refer to the connectBlue global quote number for best price. For technical questions regarding the Samtec connectors please contact connectBlue or Samtec at (Scandinavia@samtec.com).
Page 25 Section 5.2 - Mounting Information.Using the J2/J3 Board-to-Board Connectors Figure 6: Host PCB layout [mm] for single row connector. Version 1.3 - 2009-12...
Page 26 When ordering connectors from Samtec or an official Samtec distributor, please use the REF order number and refer to the connectBlue global quote number for best price. For technical questions regarding the Samtec connectors please contact connectBlue or Samtec at (Scandinavia@samtec.com).
Page 27 Section 5.2 - Mounting Information.Using the J2/J3 Board-to-Board Connectors Figure 7: Host PCB layout [mm] for double row connector. Version 1.3 - 2009-12...
Page 28: Using Press-Fit Nuts For Mounting The Module
• We strongly recommend the modules not being soldered more than 1 time after shipping from connectBlue and that the modules are mounted just before the host product is being soldered the last time. Although, connectBlue devices will withstand up to two reflows to an absolute maximum temperature of 250°C.
Page 29: Antenna Issues
Section 5.5 - Mounting Information.Antenna Issues ANTENNA ISSUES The unit cannot be mounted arbitrary, because of the radio communication. The unit with an internal surface mounted antenna (cB-OZS311i) cannot be mounted in a metal enclosure. No metal casing or plastics using metal flakes should be used, avoid also metallic based paint or lacquer.
Page 30: Regulatory Information
Mats Andersson CTO of connectBlue AB If a cB-OZS311 is used within EU a notification must be made to each of the national authorities responsible for radio spectrum management of the intention to place radio equipment that uses frequency bands whose use is not harmonized throughout the EU, on its national market.
Page 31: Safety Compliance
Consult the dealer or an experienced radio/TV technician for help 6.3.1.2 Caution Any changes or modifications NOT explicitly APPROVED by connectBlue AB could cause the module to cease to comply with FCC rules part 15, and thus void the user’s authority to operate the equipment.
Page 32 Section 6.3 - Regulatory Information.FCC and IC Compliance 6.3.1.4 Labeling Requirements for End Product For an end product using the product cB-0922-02 there must be a label containing, at least, the following information: This device contains FCC ID: PVH092202 IC: 5325A-092202 The label must be affixed on an exterior surface of the end product such that it will be visible upon inspection in compliance with the modular approval guidelines developed by the FCC.
Page 33: Ul Listing Information
Section 6.4 - Regulatory Information.UL listing information UL LISTING INFORMATION If a customer intends to UL list a product including any of the Bluetooth modules based on the PCB cB-0922-02 this information is useful: The printed circuit board if produced according to the following specification: •...
Page 34: Guidelines For Efficient And Safe Use
Read this information before using your OEM Serial Port Adapter. Note: Changes or modifications to the product not expressly approved by connectBlue AB will void the user’s authority to operate the equipment. PRODUCT CARE • Do not expose your product to liquid or moisture.
Page 35: Electronic Equipment
POWER SUPPLY cB-OZS311 must supplied limited...
Page 36: Appendix A - Application Notes
Section A.1 - Application Notes.Step-by-Step Guide Appendix A - Application Notes Usually only a subset of the available functionality is of interest to the designer. In addition, depending on the host system, the electrical interface can be designed in many ways. The designer can use the step-by-step guide in this chapter as an aid in the design process.
Page 37: Design Examples
Section A.2 - Application Notes.Design Examples A.2 DESIGN EXAMPLES This section contains design examples for all interfaces on J2, J3, and J6. The connector type that suits a specific application depends on the needed signal and the preferred interface type (board-to-board or SMD).
Page 38 Section A.2 - Application Notes.Design Examples A.2.2 Serial Interface The serial interface of the module is Logic Level logic levels and the module can be connected to an external CPU (see section A.2.2.1). An external driver is needed if the module should be on another physical interface like RS232 (see section A.2.2.2 - A.2.2.3).
Page 39 Section A.2 - Application Notes.Design Examples A.2.2.2 External RS232 driver An external RS232 driver is needed if the module should have a RS232 serial interface. See Figure 14 for a complete design example that could be connected to the serial port of standard PC.
Page 40 Section A.2 - Application Notes.Design Examples A.2.2.3 External RS422 driver An external RS422 driver could be used in a point-to-point (full duplex) application (see Figure 15). Figure 15: A complete RS422 interface. Version 1.3 - 2009-12...
Page 41 Section A.2 - Application Notes.Design Examples A.2.2.4 External RS422/RS485 transceiver Note: This function is currently not supported A complete RS422/RS485 transceiver design connected to a bus system need to control the en- able signals of the transceiver. The SerialSelect signals are used for this purpose (see Table 12). The module need to be software configured to the corrected interface, see the Serial Port Adap- ter AT Commands document how to configure the module to the correct serial interface.
Page 42 Section A.2 - Application Notes.Design Examples A.2.3 LED and Switch Design A.2.3.1 BLUE Signal The BLUE logic LED signal is not multiplexed with any other functionality, which makes the design more straightforward (for more information see Figure 17). There are two important notes: A blue LED requires about 3.5V forward voltage drop (cannot be used in a 3.3V system).
Page 43 The RED signal pin is also used to select Logic Level mode (instead of RS232) for connectBlue product with internal RS232 driver e.g. cB-OEMSPA312. The mode functionality is not applicable on cB-OZS311 because there is no internal RS232 driver available. To be compatible with these products check this signal in their Electrical and Mechanical datasheet.
Page 44 Note! The internal 20kΩ Ω Ω Ω pull-up is smaller than on previous product generations from connectBlue. This requires a smaller pull-down resistor (4.7kΩ Ω Ω Ω ) for a low state. If a LED is used and a switch is required to be able to restore the settings, a high impendence buffer need to prevent the signal from being pulled-up via the LED.
Page 45 Section A.2 - Application Notes.Design Examples Figure 23: No restore switch used but a green Figure 24: No restore switch used but a green LED in a 3.3V host system. The status of the LED in a 5V host system. The status of the signal can also be used as input to a host signal can also be used as input to a host controller.
Page 46 Section A.2 - Application Notes.Design Examples Figure 27: A low resistance function switch Figure 28: If the resistance in the switch is not used. guaranteed to be low enough, a safer design can be used. A.2.4 Reset RESET pin can be connected to an external reset source, see Figure 29 for a switch example.
Page 47 Section A.2 - Application Notes.Design Examples A.2.5 A Complete 5V Host System Interface This is a complete 5V host system interface example with an RGB LED and two switches (except the serial interface, see section A.2.2 for information). The design is based on the LM339 Quad OP-amp instead of logic gates.
