AirPoint® Ring

USER MANUAL

FCC ID: 2AXZF-APR1050

WWW.MAGNIMA.COM

Table of Contents

Summary of Contents for MAGNIMA AirPoint Ring

Page 2: Table Of Contents
USER MANUAL CONTENTS Introduction Controls Pairing the AirPoint® Ring Wearing the AirPoint® Ring Using AirPoint® Ring on a surface Using AirPoint® Ring as an air mouse Air Slide Optimize AirPoint® Ring Using AirPoint App Left hand mode Presentation mode Air Mouse sensitivity adjustment Updating AirPoint® Ring firmware Kill Mode Troubleshooting Cleaning Charging Specifications Warranty...
Page 3: Introduction
INTRODUCTION AirPoint® Ring is a finger wearable computer mouse that can be used to wirelessly control a computer or mobile device. The AirPoint® Ring supports both 2D and 3D motion, and it can be used as an air mouse or surface mouse. The included AirPoint® charger can be used to charge and store the AirPoint® Ring when it is not being used. Package contents • AirPoint® Ring • AirPoint® charger • Charging cable (USB-C) • Finger size adapters: small, medium, and large • Quick start guide • AirPoint® Manual Supported devices The AirPoint® Ring can be used with the following operating systems: macOS® 10.10 or later Windows® 8 or later...
Page 4 USER MANUAL The AirPoint® Ring can also be used with the following mobile operating systems with limited functionality (no software): Android™ 5.0 or later Chrome OS™ Safety considerations This product contains small parts that could be a choking hazard. Keep it and all parts out of the reach of children. Do not attempt repairs on this product yourself. Prolonged computer use is associated with several medical conditions, including, but not limited to, muscle soreness and fatigue, repetitive stress injury, vision problems, headache and obesity. Keeping your head straight with a computer screen at eye level, taking regular breaks, and limiting computer use and exercise will help reduce many of these problems. Seek professional medical help if any of these conditions occur. Do not disassemble or remodel the product.
Page 5 CONTROLS Controls On / Oﬀ switch LED indicator Touchpad Finger button Magnetic connector Touchpad...
Page 6: Pairing The Airpoint Ring
USER MANUAL PAIRING THE AIRPOINT RING Slide the AirPoint® Ring power switch to On. The green LED will glow. Open the list of available Bluetooth devices on your device. Find AirPoint in the list and connect. The green LED will stop glowing when the AirPoint® Ring pairs with your device. The green LED will glow when the AirPoint® Ring is disconnected from a device.
Page 7: Wearing The Airpoint Ring
WEARING THE AIRPOINT RING The three sizing adapters can be used to adjust the size to fit your finger. To use the adapter, slide it into the inside of the Ring and make sure it’s locked properly.
Page 8 USER MANUAL USER MANUAL Wear the AirPoint® Ring on your index finger.
Page 9: Using Airpoint Ring On A Surface
USING AIRPOINT RING ON A SURFACE Move the cursor Slide your index finger across the surface. Left Click Tap the lower touchpad with your thumb or press the finger button. Right click Tap the upper touchpad with your thumb. Press and hold the lower touchpad with your thumb or press and hold the Drag finger button over the item you want to drag and move the AirPoint®...
Page 10: Using Airpoint Ring As An Air Mouse
USER MANUAL USER MANUAL USING AIRPOINT RING AS AN AIR MOUSE Activate or deactivate Tap the upper or lower touchpad with your middle finger. air mouse mode Left click Tap the lower touchpad with your thumb or press the finger button.
Page 11: Air Slide
AIR SLIDE In presentations, to navigate to next slide, deactivate air mouse mode and tilt the thumb in clockwise direction as shown in figure. Likewise, to move to previous slide, tilt the thumb in counter-clockwise direction as shown in figure. In macOS, the direction of slide change will be opposite by default.
Page 12: Optimize Airpoint® Ring Using Airpoint App
USER MANUAL OPTIMIZE AIRPOINT RING USING AIRPOINT APPLICATION The Windows and macOS AirPoint® application can be downloaded from www.magnima.com/product/airpoint-ring Install the application to explore more of AirPoint® Ring. The additional features of AirPoint® Ring namely 'Left hand mode', 'Presentation mode' and 'Air mouse sensitivity adjustment' can be activated through 'AirPoint®' desktop application.
Page 13: Left Hand Mode
LEFT HAND MODE To activate/deactivate Left Hand mode, single click on the left hand mode icon on the app as shown in the image below. NOTE: When AirPoint® Ring is in left hand mode, it is designed to be worn on the left hand index finger PRESENTATION MODE To activate/deactivate Presentation mode, single click on the presentation mode icon as shown in the image below.
Page 14: Air Mouse Sensitivity Adjustment
USER MANUAL AIR MOUSE SENSITIVITY ADJUSTMENT To adjust the Air Mouse sensitivity, use the slider in the app as shown in the image below and set the range by sliding. UPDATING THE AIRPOINT RING FIRMWARE The AirPoint® Ring firmware can be updated using the AirPoint® application. When the AirPoint® Ring firmware is being updated, the LED will first glow yellow and green together and then yellow and red together. The LED will glow green when the firmware update is complete and the AirPoint® Ring is ready to...
Page 15: Kill Mode
KILL MODE Kill mode is a quick way to prevent unwanted movement by disabling the AirPoint® Ring. To activate or deactivate kill mode, simultaneously press for three seconds the finger button and the upper touchpad of the air mouse mode activation pads. The LED will blink twice indicating kill mode activation/deactivation.
Page 16: Troubleshooting
2. Verify that AirPoint® Ring is in a ‘connected’ state in the Bluetooth list of the host device 3. If the device is in ‘connected’ state and no pointer movement then remove the device from the Bluetooth device list and connect again. Please visit magnima.com for detailed troubleshooting steps. You can contact customer support at 1-800-694-4815 or contact@magnima.com. CLEANING Use a dry cloth or apply a small amount of cleaner to the cloth to clean the AirPoint® Ring. The AirPoint® Ring...
Page 17: Charging
CHARGING To charge the AirPoint® Ring, dock the ring to the AirPoint® charger. The LED will change to yellow when the power is low and red when the power is extremely low. To charge the AirPoint® charger, connect the AirPoint® charger to a power supply using a USB-C cable. The LEDs on the AirPoint® charger will light up one by one to indicate the charging progress.
Page 18: Specifications
USER MANUAL SPECIFICATIONS AirPoint® Ring: 36mm x 32mm x 39mm Dimensions AirPoint® charger: 65mm x 66mm x 68mm AirPoint® Ring: < 50 grams Weight AirPoint® charger: 150 grams Package: 360 grams Battery life 8-10 hours after fully charged AirPoint® Ring: 65 mAh Battery capacity AirPoint®...
Page 19: Warranty
WARRANTY 1-year limited hardware warranty. FCC compliance statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and meets applicable limits for radio frequency (RF) exposure. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. CAUTION: The grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,...
Page 20 USER MANUAL which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Patent information Patent No. US 9798387 B2 Patent No. US 10782781 B2 Date of Patent: Oct. 24, 2017 Date of Patent: Sep. 22, 2020 Disclaimer Every effort has been made so that the instructions and information in this guide are accurate and complete. Liability cannot be given for any omissions or errors. Do Not Disassemble Or Remodel The Product. Magnima reserves the right to make any changes without notice to this or any other product of the company.
