Micro Star Computer MS-5519 Manual

The MS-5519 is a wireless music adaptor that can connect to an audio source and
broadcast that audio signal to any radio or stereo within 3~10 meters. For example,
connect it to your MP3 Player and car stereo system, and the passengers in your car can
all hear the songs stored in the MP3 Player through the car stereo.

Instructions:

1. Provide a powering method:
a. Plug the MS-5519 USB Connector to an USB Port of a laptop or a desktop.
b. Plug the MS-5519 USB Connector to the USB Port 1 at the end of the MEGA
Adaptor, and plug the adaptor head into the car cigarette lighter jack. Then the
adapter head into the car cigarette lighter jack.
2. Plug the 3.5mm Stereo Cable Head to the Earphone Jack or the Line-out Jack of an
audio source. (An MP3 Player, a CD Player, a Tape Player, a Notebook, a PC, or
any device with a Earphone Jack or a Line-out Jack can be the audio source.)
3. Select and adjust one of the four frequencies (88.1, 88.3, 88.5 or 88.7 MHz) with the
Frequency Selector to broadcast.
4. Tune your stereo to the same frequency as you selected on MS-5519.
5. Press the Power button on the top of MS-5519 to turn it on. Then the LED will light
up in green.
6. Now you can hear the audio wherever you want, without any wires.

Product Specification:

I/O Port: 3.5ψ mm Audio Cable
Type A Male USB connector
Frequency Modulation : 88.1 ~ 88.9 MHz
Channels: 88.1, 88.3, 88.5 & 88.7 MHz
Operating Range : 3(Min) ~ 10(Max) meters
Safety: FCC, CE & BSMI
Audio Frequency Range: 50Hz to 15Khz
SNR: > 80 dB
*. While using the MEGA Adaptor as the Powering method, you can use the USB Port 2
to recharge your USB device.
