Summary of Contents for Mantiz Saturn Pro Thunderbolt 3

  • Page 2: Table Of Contents

    Mantiz Saturn Pro guide With the Saturn Pro Thunderbolt™ 3 external desktop graphics docking station, you can add external or AMD Radeon™ or NVIDIA® GeForce®, NVIDIA® Quadro® graphics cards* to transform your laptop into a desktop gaming platform . The product has a rated power of 750W, which not only power the graphics card, but also provide 100W power output for compatible notebook via Thunderbolt™...

  • Page 3: Package Contents/System Requirements

    1.Package contents/system requirements What's in the package ▪ Saturn Pro external graphics docking station ▪ Thunderbolt™ 3 (USB-C™) cable*0.7M ▪ Power cord ▪ Important product information guide System Requirements ▪ A notebook that supports Thunderbolt 3™ external graphics card ▪ PCI-E graphics card compatible with Saturn Pro ▪...

  • Page 4: Equipment Layout

    3.Equipment layout C C C B. Power Connector C. Air Vent A. Power Switch ON/OFF D. GPU Output E. USB 3.0 Port F. LAN Port G. THUNDERBOLT 3 PORT H. USB 3.0 Port I. SD Card Slot...
  • Page 5 K. PCI-E Slot L. PCI-E Release Lever M. Cooling Fan N. SSD Bracket...

  • Page 6: Set Up And Install Saturn Pro

    4.Set up and install Saturn Pro P. Turn to Unlock Mantiz eGPU P. Pull to Open Mantiz eGPU Internal Structure...
  • Page 7 R. Remove PCI-E Cover and Locking Screw S. Install a Compatible GPU onto the PCI-E Slot and connect 12V and Connect to GPU Power Slot...
  • Page 8 T. Tighten the Screw for GPU U. Tighten SSD on the Slot, Connect to SATA Cable V. Tighten SSD Bracket...
  • Page 9 W. Push in Mantiz eGPU Internal Structure X. Tighten up the Screw, Connect to PSU, Turn on the System, Use Thunderbolt 3 Cable available and connect to Mantiz eGPU and Laptop Remark: Without connecting to Thunderbolt 3 laptop. Mantiz Saturn Pro eGPU will...

  • Page 10: Safety And Maintenance

    ▪ If you find that the device is operating abnormally and the fault cannot be resolved, please unplug the device and call the Mantiz service hotline or visit the Mantiz store for support.

  • Page 11: Legal Notice

    Limitation of Liability Mantiz is not responsible for any loss of profit, loss of information or data, special, accidental, indirect, punitive, causal or incidental damage caused by the distribution, sale, resale, use or inability to use the product. Under no circumstances will Mantiz's liability exceed the retail price of the purchased product.
