CarieScan PRO User Manual

CarieScan PRO

User Manual

DFU003, Issue H rev2

Table of Contents

Need help?

Do you have a question about the PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for CarieScan PRO

Page 2 IEC / UL 60601-1 General Requirements for Safety CSA-C22.2 No.601.1-M90 Part 1 General Requirements for Safety CarieScan PRO and the CarieScan logo are trademarks of CarieScan Ltd and are not to be copied or reproduced in any format. The CarieScan PRO is protected by UK Patent 2385136B and Registered Community Designs EC000680467-0002.
Page 3: Table Of Contents
Charging Cradle and Stand ............................... 8 Power Supply Unit................................8 Cable Test Adaptor ................................8 Sensor Pack ..................................8 INSTALLATION / ASSEMBLY.......................... 9 Charging the CarieScan PRO............................9 ® Connections to Compatible Accessories via Bluetooth ....................9 DEVICE START UP............................9 Start Up ....................................
Page 4: Getting Started
The system consists of the CarieScan PRO handpiece, a Soft Tissue Cable for attaching the soft tissue contact (lip clip) to the PRO, and a Sensor. The PRO uses a disposable sensor that resembles a small toothbrush. The sensor is held against the tooth to be examined and the measurement takes about four seconds to complete then the result is displayed.
Page 5: Taking A Measurement On Occlusal And Free Smooth Surfaces
Care must be taken if any plastic sheathing is used for cross-infection control purposes. Ensure that it does not prevent electrical contact between the end of the CarieScan PRO and the contacts inside the sensors. The LCD will show ‘RdY’ (ready), the Occlusal and Smooth surface icons will be shown.
Page 6 5.1). Note: If there is a bad connection or improper site preparation the PRO may not provide a measurement value. 14. With the measurement complete the sensor can be removed from the tooth surface, the result will remain visible on the displays until the next tooth site is detected. Record the last result as required and select another site to measure.
Page 7 • all sensors must be disposed as sharp contaminated waste. All such waste must be placed in a suitable receptacle marked as biohazard, conforming to the required regulations. • the CarieScan PRO and Soft Tissue Cable should be wiped down with alcohol-based wipes. © Copyright CarieScan Ltd 2008...
Page 8: Product Overview
The PRO enables earlier and more accurate detection of “early” caries lesions which are not clearly visible to the human eye enabling remedial (preventive) treatment to be initiated. It also enables detection of the more extensive “hidden”...
Page 9: Box Contents List
CarieScan PRO User Manual Box Contents List Please review the contents below and ensure all the components are present. If there are any missing components please refer to Product Support (Section 10.1). Part Figure Item See Section Number CP-SYS-01 CarieScan PRO...
Page 10: Cariescan Pro
CarieScan PRO 2.2.1 General The CarieScan PRO has a keypad, LCD symbol display, colour LEDs and a soft tissue cable socket. The PRO includes Bluetooth® for future connectivity. Battery charging is achieved via the charging cradle. colour LED results pyramid...
Page 11: Soft Tissue Cable
CP-PSU-01 only. CAUTION: The charging cradle must NOT be placed inside the patient environment. The display stand is a non-electrical unit and should be used to hold the CarieScan PRO within the patient environment. Power Supply Unit The CarieScan PRO has been certified for use via the charging cradle with only the supplied power charger, part code CP-PSU-01.
Page 12: Installation / Assembly
To charge the CarieScan PRO, place it into the Charging Cradle. The blue LED on the CarieScan PRO will illuminate until it is removed from the Cradle or until the CarieScan PRO is fully charged. The product is disabled from use during charging.
Page 13: Standby
Bluetooth On or Off. When enabled, the Wireless Connectivity icon will appear in the status bar at the bottom of the LCD. The CarieScan PLUS, or other approved device, can now connect with the CarieScan PRO. Keys Action...
Page 14: System Health Check
‘CFL’. If ‘CFL’ is observed, then it is likely that the soft tissue cable is damaged. In this case replace or contact your supplier for advice. The PRO will return to the ‘TSE’ state until the Cable Test Adaptor is removed. © Copyright CarieScan Ltd 2008...
Page 15: Caries Detection Protocol
CarieScan PRO User Manual 5 CARIES DETECTION PROTOCOL Caries Detection Evaluation Scale LCD: OBSERVATION: Sound tooth surface LED: 1 green ADVICE: AUDIO: 1 beep No treatment required beyond continuing surveillance, with Reassessment and Review at intervals appropriate to the particular caries risk characteristics of the patient.
Page 16: Setting Up The Device
CarieScan PRO User Manual Setting up the device Ensure the CarieScan PRO is charged in accordance with the instructions given in Charging the CarieScan (Section 3.1). Remove the CarieScan PRO from the Charging Cradle and place it on the Stand.
Page 17 Press the ‘Enter’ button to start measuring. 10. The blue LED on the pyramid will flash indicating that the CarieScan PRO is in measurement mode. 11. Place the sensor firmly onto the chosen occlusal or smooth surface and a measurement will automatically be taken.
Page 18: Cleaning And Maintenance
16. Terminate the measurement process by pressing any button on the Keypad for about 1s. 17. When measurements on the patient are complete: • To remove the sensor from the CarieScan PRO, squeeze the sensor on the side grips to release the catch and remove from the device.
Page 19: Important Information
CarieScan PRO User Manual Important Information Intended Use The CarieScan PRO is intended for use by dental professionals as an aid in the diagnosis and monitoring of dental caries. Indications for use The CarieScan PRO is indicated for the detection and monitoring of primary coronal dental caries.
Page 20: Certifications
Consult the manufacturer or field service technician for help. We hereby declare the product CarieScan PRO FCC ID:TTZ0002 is a class 2 BT device (max 1mW Transmit power) and for typical product usage the antenna distance from a person is 15cm. The product is not subject to the routine RF exposure evaluation as per Section 2.1093 of the FCC rules.
Page 21: Warnings & Precautions
9 WARNINGS & PRECAUTIONS General Only the CarieScan PRO and Display Stand should be taken inside the patient environment, which is defined as a radius of 2m from the patient. For the avoidance of doubt, the Charging cradle and all other accessories MUST remain outside the patient environment.
Page 22: Classification
CarieScan PRO User Manual Classification 9.3.1 CarieScan PRO Internally powered equipment Type B applied part Not intended to be sterilised. iii. Not suitable for use in the presence of flammable anaesthetic mixture with air or with oxygen or nitrous oxide.
Page 23: Lcd Glossary
Intermediate scale between G and R Established caries Navigation Indicates that Bluetooth can be enabled or disabled 10.4 Troubleshooting Please visit Frequently Asked Questions on our website (www.cariescan.com/faqs.php) for up-to-date frequently asked questions and troubleshooting tips. © Copyright CarieScan Ltd 2008 DFU003, Issue H rev2...
Page 24 CarieScan Ltd Tel. +44 (0)1382 598628 Prospect Business Centre The Technology Park Email: support@cariescan.com Dundee Web: www.cariescan.com DD2 1SW © Copyright CarieScan Ltd 2008 DFU003, Issue H rev2...
