Summary of Contents for WeHeal TS200
- Page 1 We Heal Smart TENS & Body Analyzer We Heal Biotechnology Co. Version: 2019_v1.0...
- Page 2 Table of Contents 1.Product Specifications 1.1 Device information 1.2 Intended use 1.2.1 Transcutaneous nerve stimulation 1.2.2 Electrical muscle stimulation 1.2.3 Impedance plethysmograph 1.2.4 Galvanic skin response 1.3 Contraindications 1.4 Precautions 1.5 Device summary description 1.6 Signs and symbols 1.7 Replacement parts and accessories 1.7.1 Electrodes 1.7.2 Connection cable 1.7.3 Other accessories...
- Page 3 Table of Contents 3.2 TENS/EMS auto (programmed) mode 3.3 TENS/EMS manual mode 3.4 Body analyzer 3.5 Alarms and problem solutions 3.6.1 Blue light 3.6.2 Orange light 3.6.3 Green light 3.6.4 Reset the machine 4.Warranty and ser vice 5.Electromagnetic compatibility information 6.Federal Communications Commission (FCC) Statement...
-
Page 4: Power Specification
Trade name WeHeal smart transcutaneous electrical nerve stimulation & body analyzer. Model TS200 Monophasic or biphasic rectangular pulse Output waveform 40 – 800 μs / 1 – 200 Hz Pulse length/ frequency Max. 50 V / 90 mA (500 ohm) - Page 5 TENS- transcutaneous symptomatic relief of neuro-muscular pain, chronic intractable nerve stimulation pain, and post traumatic and post-surgical pain. Improvement and facilitation of muscle performance, relaxation of muscle spasm, increasing local blood circulation, prevention EMS- electrical muscle or retardation of disuse atrophy, and maintaining or increase stimulation range of motion.
- Page 6 The device is not a substitute for medical consultation and treatment. Consult your doctor first if you are experiencing any pain or are suffering from a chronic illness such as cancer, diabetes, high blood pressure, and blood coagulation/thrombo-embolic diseases. To avoid damage to health, we strongly advise against using the We Heal Smart TENS &...
- Page 7 2 mA/cm² requires increased awareness. The WeHeal smart TENS & body analyzer is a combination of TENS/EMS unit, galvanic skin response unit, and impedance plethysmograph unit. It is powered by rechargeable lithium-ion battery which is permanently built into the main unit.
- Page 8 Do not use this product if you have implanted pacemaker installed Protected against ingress of solid foreign objects greater than 12.5 mm IP22 in diameter. Protected against drops of water falling at up to 15° from vertical Serial number Read the instructions before use Electrodes as the applied part, type BF Manufacturer Class II symbol...
- Page 9 USB charging cord x 1; soft shell package x 1. 1.7.4Recommended adaptor： Manufacturer: We Heal Biotechnology Co. Address: 9F., No. 205, Minsheng 2nd Rd., Chyan Jin Dist., Kaohsiung City 801, Taiwan (R.O.C.) Phone: +88672216313 Website: www.weheal.com Email: service@weheal.com.tw - 6 -...
- Page 10 ON/OFF button：Press 1 sec to turn on and 3 secs to turn off ENTER button：START/PAUSE button BACK button MODE Shift button : switch the display of treatment setting Setting button ：choose left or right, increasing or decreasing the frequency, impulse width, and working time 1.
-
Page 11: Warning Light
warning light The socket for the connection cables. Dimensions: 121 x 60 x 28 mm Weight: 134.2g The socket for the Color: Black or pink USB charging cord. Connect the connection cables with the electrodes. Guide the connection cable plugs into the socket on the top of the device. Do not pull, twist or make sharp bends in the cables. -
Page 12: Cleaning The Device
Step 1 Pressure the ON/OFF button to switch on the device. Step 2 Use the >/< button to navigate through the modes and press the ENTER button to confirm your selection. Cleaning the device Please turn off the device while cleaning the device. Clean the device after use with a soft, slightly damp cloth. - Page 13 monophasic pulse It distinguishes between monophasic and biphasic pulse currents. In monophasic pulse currents, the current flows in one Time Impulse direction and in biphasic pulse currents shape the electrical impulse alternates its biphasic pulse direction. The device provides both monophasic and biphasic rectangular wave.
-
Page 14: Program Table
Step 1 The digital EMS/TENS unit features a total of 15 programs. Use the >/< setting buttons to select the program number you want and press the ENTER button to confirm your selection. Step 2 You can set the impulse intensity of both channels in all programs. Program table: Mode Area of application, indications... - Page 15 Step 1 Place the electrodes on the desired area for treatment. Choose the waveform. Step 2 Set the impulse frequency between 1 to 200 Hz. Step 3 Set the impulse width between 1%-20% (40-800 μs). Step 4 Set the timer. Adjust the impulse intensity. Program No.
- Page 16 - 1 3 -...
- Page 17 3.6.1 Blue light It represents that this device is charging. 3.6.2 Orange light It represents that at least one of the electrodes are not adhered to the body. Please adhere the electrodes to the body. 3.6.3 Green light It represents the device is in connection with correspondent Apps.
- Page 18 In case of a claim under the warranty please contact your local dealer or the local representation. In case of returning the unit please add a copy of your receipt and a short report of the defect. The following warranty terms shall apply: The warranty period for this product is 3 years warranty period from date of purchase.
- Page 19 Table 1. Guidance and manufacturer’s declaration – electromagnetic emissions The TS200 is intended for use in the electromagnetic environment specified below. The customer or the user of the TS200 should assure that it is used in such an environment. Emissions test Compliance Electromagnetic environment –...
- Page 20 Table 2. Guidance and manufacturer’s declaration – electromagnetic immunity The TS200 is intended for use in the electromagnetic environment specified below. The customer or the user of the TS200 should assure that it is used in such an environment. Immunity test IEC 60601 test level Compliance level Electromagnetic environment –...
- Page 21 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the TS200 is used exceeds the applicable RF compliance level above, the TS200 should be observed to verify normal operation.
- Page 22 Table 4. Recommended separation distances between portable and mobile RF communications equipment and the TS200 The TS200 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the TS200 can help...
- Page 23 Test specifications for ENCLOSURE PORT IMMUNITY to RF wireless communications equipment The TS200 is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the TS200 should assure that it is used in such an environment. Band...
- Page 24 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 25 Manufacturer: We Heal Biotechnology Co. Address: 9F., No. 205, Minsheng 2nd Rd., Chyan Jin Dist., Kaohsiung City 801, Taiwan (R.O.C.) Phone: +88672216313 Website: www.weheal.com Email: service@weheal.com.tw...
