SendTek GHN86X User Manual

Wi-fi gb ethernet bridge

Advertisement

Quick Links

G.hn over Coax
Wi-Fi Gb Ethernet
Bridge
User's Guide
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GHN86X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SendTek GHN86X

  • Page 1 G.hn over Coax Wi-Fi Gb Ethernet Bridge User’s Guide V1.0...
  • Page 2 INTRODUCTION This G.hn to Wi-Fi Gb Ethernet bridge connects any wireless and Ethernet devices to a high speed connection of the coax network for Internet access. This bridge brings you the newest Ethernet compatible technology that uses the coaxial cable as the network's physical wiring thereby eliminating the need to install new wiring in a residential environments.
  • Page 3: Hardware Installation

    HARDWARE INSTALLATION Parts Names and Functions LED Indicators on the Rear Panel Status Port Flashing Powered by DC 12V Not powered DC12V Link Receive Disconnect Link Transmit Link fail LAN1 10Mbps 1000Mbps 1000 100Mbps Link Receive Disconnect Link Transmit Link fail LAN2 1000 1000Mbps...
  • Page 4 Ports on the Rear Panel Port Name Type Functions DC 12V Connect to the power adapter plug. Connect to PC or STB or other LAN1/LAN2 RJ-45 Ethernet devics. Factory Reset Button Connect to TV G.hn Connect to G.hn devices Essential Hardwares Items Included Description Purpose...
  • Page 5: Hardware Connections

    CAT5 Connects from Ethernet port cable Ethernet enabled devices as or STB DC12V Connects from Power Power port of adapter the main unit into a wall outlet Hardware Connections 1. Select a convenient location for the bridge near the PC or Ethernet device to which it will be connected.
  • Page 6 The figure above shows the connection diagram of coax network. Follow the same steps to connect any Ethernet devices such as a STB or PC, and Wi- Fi devices to the coax network. Now you should have connected the LAN port, G.hn port and the DC 12V port to the appropriate devices or lines.
  • Page 7: Troubleshooting

    TROUBLESHOOTING The bridge has been designed to be a reliable and easy to use connection device. Please refer to the list below to aid in troubleshooting. The Power (green PWR) LED is off.  Make sure the power adapter is properly plugged into a live electrical outlet.
  • Page 8: Specifications

    SPECIFICATIONS Standards  IEEE 802.3u 100BaseT Fast Ethernet  IEEE 802.3ab 1000BaseT Gigabit Ethernet  IEEE 802.11b/g/n/a/ac compliant  ITU-T G.9960/G.9961 G.hn over Coax Data Rates  G.hn: 2Gbps (6-200MHz / Filter 216MHz)  Ethernet: 100 /1000 Mbps  Wi-Fi : 866M(5GHz)/300Mbps(2.4GHz) max Transmission Range ...
  • Page 9: Federal Communications Commission (Fcc) Statement

    Federal Communications Commission (FCC) Statement You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
  • Page 10 -Consult the dealer or an experienced radio/TV technician for help. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules.
  • Page 11 co-located or operating in conjunction with any other antenna or transmitter. - 10 -...
