Soucy T7.170 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

SOUCY TRACK SYSTEMS USER GUIDE
ST- 600
NEW HOLLAND models:
T7.170 - T7.185 - T7.200 – T7.210
T6030 - T6050 - T6070 - T6080 – T6090
CASE models:
PUMA 115 - 125 - 130 - 140 - 145 – 155 – 160
A-8C0214-3-EN
January 2017
Rev. 0
5450 St-Roch Street, P.O. Box 400 / Drummondville (Quebec) J2B 6W3 / CANADA
Toll free: 1 877 474-6665
Fax: 819 477-9423
www.soucy-track.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T7.170 and is the answer not in the manual?

Questions and answers

Summary of Contents for Soucy T7.170

  • Page 1 SOUCY TRACK SYSTEMS USER GUIDE ST- 600 NEW HOLLAND models: T7.170 - T7.185 - T7.200 – T7.210 T6030 - T6050 - T6070 - T6080 – T6090 CASE models: PUMA 115 - 125 - 130 - 140 - 145 – 155 – 160...
  • Page 2 Page Intentionally Left Blank 5450 St-Roch Street, P.O. Box 400 / Drummondville (Quebec) J2B 6W3 / CANADA Toll free: 1 877 474-6665 Fax: 819 477-9423 www.soucy-track.com...

  • Page 3: Table Of Contents

    6.2 INSTALLATION OF THE FRONT PIVOT SUPPORT ........SOUCY TRACK SYSTEMS USER GUIDE...

  • Page 4: Title Page

    11.4 WARRANTY PERIOD FOLLOWING THE REPLACEMENT ........SOUCY TRACK SYSTEMS USER GUIDE...
  • Page 5 SECTION 12 APPENDIX ..............SOUCY TRACK SYSTEMS USER GUIDE...
  • Page 6 Page Intentionally Left Blank SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 7: Section 1 St-600 Load & Speed Rating And Track System Specifications

    3215 lbs 3166 in² 25 in. (639 mm) 1461 kg 2.04 m² ST-600WT (25 / 32) Rear 4930 lbs 4350 in² 32 in. (813 mm) 2241 kg 2.81 m² 2000 lbs BLADE SYSTEM 907.2 kg SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 8 > DRIVING ON THE ROAD UNDER HIGH AMBIENT TEMPERATURE (85 F / 30 C) OVER LONG DISTANCE NOTICE THIS TABLE IS INTENDED TO SERVE AS A GUIDE ONLY; ALWAYS REFER TO TRACTOR MANUFACTURER’S SPECIFICATIONS AND NEVER EXCEED MAXIMUM AXLE LOADS SPECIFIED BY TRACTOR MANUFACTURER. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 9: Track System Specifications

    1.2 ST-600 TRACK SYSTEM SPECIFICATIONS Figure 1.1 ST-600WT FRONT VIEW MEASUREMENTS 19 in [ 479 mm 25 in 32 in [ 639 mm [ 813 mm 109 in [ 2775 mm SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 10 Figure 1.2 ST-600 FRONT VIEW MEASUREMENTS 19 in [ 479 mm 20 in 25 in [ 500 mm [ 645 mm 98 in [ 2482 mm SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 11 [ 432 mm] 45 in 52 in [ 1145 mm] [ 1327 mm] 69 in 76 in [ 1749 mm] [ 1930 mm] 177 in [ 4504 mm] NOTE *: Height may vary depending tractor models. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 12 Figure 1.4 ST-600 BLADE FRONT VIEW MEASUREMENTS 122 1/4 in 3103 mm SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 13 Figure 1.5 ST-600 BLADE SIDE VIEW MEASUREMENTS 112 1/2 in * [ 2861 mm ] 232 1/2 in [ 5908 mm ] NOTE *: Height may vary depending tractor models. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 14 Page Intentionally Left Blank SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 15: Section 2 Introduction

    2.1 PRESENTATION • This guide contains the information required for safely installing, operating and maintaining your Soucy Track system. Please read this guide carefully to learn and understand how to correctly install, operate and service the Track system. Failure to do so could result in personal injury or equipment failure.

  • Page 16: System Description

    (see next figure). Movement of the track is ensured by the driving sprocket teeth pushing on the internal track teeth when the tractor is moving. Figure 2.1 TRACK SYSTEM MAIN ASSEMBLY (SAMPLE) ITEM DESCRIPTION FRAME SPROCKET TRACK SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 17: Serial Number And Identification

    The track serial number is engraved on its inner surface. NOTICE DEALER: PLEASE COMPLETE THE TRACK SYSTEM REGISTRATION FORM ON LAST PAGE AND RETURN TO SOUCY TRACK TECHNICAL SERVICE DEPARTMENT. Figure 2.2 SERIAL NUMBER AND IDENTIFICATION (SAMPLE) SOUCY TRACK SYSTEMS USER GUIDE...
  • Page 18 Page Intentionally Left Blank SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 19: Section 3 Safety

    The symbol above draws your attention to important instructions concerning your personal safety. Read the accompanying message carefully to avoid personal injury or death. • Keep this manual in the cab while using the Soucy Track System. • Always remove key from ignition before working on the vehicle.

  • Page 20: Safety Signs Used In This Guide

    • Check that safety labels are intact and visible. Replace damaged or illegible labels. • Read the installation, operation and maintenance guide of your Soucy Track system before installing and operating your system. • Make sure the lifting equipment has the capacity to keep the vehicle stable during installation of the system.
  • Page 21 BROKEN OR MISSING HARDWARE. WARNING HEAVY PARTS CAN CAUSE INJURIES. TWO PEOPLE ARE REQUIRED FOR ASSEMBLY AND REMOVAL OF THE SOUCY TRACK SYSTEM. USE A JACK, A FORKLIFT OR A HOIST TO HANDLE SYSTEM AND SUB-ASSEMBLIES. WARNING DO NOT USE TRACKS AND WHEELS AT THE SAME TIME ON A TRACTOR. THE SIMULTANEOUS USE OF TRACKS AND WHEELS COULD SEVERELY AFFECT HANDLING AND LEAD TO LOSS OF CONTROL, POSSIBLY RESULTING IN SERIOUS INJURY OR DEATH.

  • Page 22: Safety Labels

    Check for possible interferences between the tracks and the various accessories used with a tractor such as implements, ballast weights and others. • Due to the numerous accessories that can be used with tractors, Soucy Track cannot guaranty that there will be no interference. 3.1.3 SAFETY LABELS •...

  • Page 23: Section 4 Parts Catalog Of The Track System

    SECTION 4 PARTS CATALOG OF THE TRACK SYSTEM SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 24: Parts List Of The Track System (Dedicated)

    4.1 PARTS LIST OF THE TRACK SYSTEM (DEDICATED) Figure 4.1 EXPLODED VIEW OF THE TRACK SYSTEM SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 25 Table 4.1 EXPLODED VIEW OF THE TRACK SYSTEM CNH T7.170 - T7.185 – T6030 - T6050 - T6070 – PUMA 115 - PUMA 125 - PUMA 130 - PUMA 140 - PUMA 145 ITEM PART # QTY DESCRIPTION 8031004-0010-1 REAR SYSTEM PART...

  • Page 26: Parts List Of The Front Left Bracket

    4.1.1 4.1.1 PARTS LIST OF THE FRONT LEFT BRACKET Figure 4.2 PARTS LIST OF THE FRONT LEFT BRACKET (8031004–0340–1) SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 27 90 DEG.ZERk GREASE FIT STRAIGHT 1/4-28 TAPER MALE Z.P. S6602-00002-000 ZERk GREASE FIT STRAIGHT 1/8-27 NPT HEX. 7/16 Z.P. S6602-00011-000 STRAIGHT COUPLING 1/8-NPT FEMALE S6631-00002-004 FLEXIBLE GREASE HOSE 3/16 DIA X 300mm S8361-06001-400 FLEXIBLE HOSE CLAMP 3/8 DIA SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 28: Parts List Of The Front Right Bracket

    4.1.2 4.1.2 PARTS LIST OF THE FRONT RIGHT BRACKET Figure 4.3 PARTS LIST OF THE FRONT RIGHT BRACKET (8031004–0350–1) SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 29 90 DEG.ZERk GREASE FIT STRAIGHT 1/4-28 TAPER MALE Z.P. S6602-00002-000 ZERk GREASE FIT STRAIGHT 1/8-27 NPT HEX. 7/16 Z.P. S6602-00011-000 STRAIGHT COUPLING 1/8-NPT FEMALE S6631-00002-004 FLEXIBLE GREASE HOSE 3/16 DIA X 300mm S8361-06001-400 FLEXIBLE HOSE CLAMP 3/8 DIA SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 30: Parts List Of The Rear Bracket

    4.1.3 NOTICE CNH T7.170 - T7.185 – T6030 - T6050 - T6070 – PUMA 115 - PUMA 125 - PUMA 130 - PUMA 140 - PUMA 145 4.1.3 PARTS LIST OF THE REAR BRACKET Figure 4.4 PARTS LIST OF THE REAR BRACKET (8031004–0010–1)
  • Page 31 4.1.3 Table 4.5 PARTS LIST OF THE REAR BRACKET (8031004–0010–1) CNH T7.170 - T7.185 – T6030 - T6050 - T6070 – PUMA 115 - PUMA 125 - PUMA 130 - PUMA 140 - PUMA 145 ITEM PART # QTY DESCRIPTION...

  • Page 32: Parts List Of The Rear Bracket

    4.1.4 NOTICE CNH T7.200 – T7.210 – T6080 – T6090 – PUMA 155 – PUMA 160 4.1.4 PARTS LIST OF THE REAR BRACKET Figure 4.5 PARTS LIST OF THE REAR BRACKET (8031004–0630–1) SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 33 LOCK WASHER HD M16 ID 17 OD 27.4 X 4.8 (DIN 127B) S4515-M200H-0EC LOCK WASHER HD M20 ID21.2 X OD 33.6 X 5.74 (DIN 127) S4612-M1600-0B1 FLAT WASHER ZINC PLATED M16 (DIN 125 A) S5361-M2050-000 DOWEL PIN 20 OD X 50mm LG SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 34: Parts List Of The Sprocket Adaptors

    Table 4.7 PARTS LIST OF THE FRONT SPROCKET ADAPTOR (8033001-0620-1) ITEM PART # QTY DESCRIPTION 8033001-0630-1 PAINTED FRONT SPROCKET ADAPTOR S1111-16060-0F1 HEX. B. CL10.9 ZP M16-2 X 60MM DIN 931 S4515-M160G-0DC LOCK WASHER HD M16 ID 17 OD 27.4 X 4.8 (DIN 127B) SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 35 WELDED ASS'Y REAR SPROCKET SHIM # 2 8033001-0910-1 BOLT SHIM 8033017-5030-1 PAINTED FLANGE AXLE REAR SPROCKET ADAPTOR S1111-16090-0F7 HEX. B. CL10.9 ZnNi M16-2.0 X 90mm (DIN931) S4186-M160Q-051 HEX. NYLON NUT CL8.8 ZINC PLATED M16-2.0 (DIN 985) SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 36: Parts Catalog Of The Standard Track System / St-600

    4.2 PARTS CATALOG OF THE STANDARD TRACK SYSTEM / ST-600 4.2.1 EXPLODED VIEW OF THE STANDARD TRACK SYSTEM Figure 4.8 EXPLODED VIEW OF THE STANDARD TRACK SYSTEM SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 37 ST-600 RIGHT FRONT CHASSIS ASS'Y 8032001-0030-5 ST-600 FRONT LEFT CHASSIS ASS'Y 8032001-0040-4 ST-600 LEFT REAR CHASSIS ASS'Y 8032001-0020-4 ST-600 RIGHT REAR CHASSIS ASS'Y 8033001-0150-1 19 TEETH ST-600 FRONT SPROCKET 8033001-0010-2 25 TEETH SPROCKET REAR SPROCKET SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 38: Parts List Of The Rear Pivot

    4.2.2 4.2.2 PARTS LIST OF THE REAR PIVOT Figure 4.9 PARTS LIST OF THE REAR PIVOT(8031002–0520–1) / (8031002–0530–1) SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 39 PIVOT SHAFT 8031002-0620-1 LOCKING DEVICE S1111-10020-0D1 HEX. BOLT CL8.8 ZINC PLATED M10-1.5 X 20 (DIN 931) S1111-20050-0F1 HEX. BOLT CL 10.9 ZINC PLATED M20-2.5 X 50MM (DIN 931) 8031002-0590-1 #2 MACHINED PIVOT SUPPORT (8031002–0530–1) SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 40: Parts List Of The Front Pivot

    4.2.3 4.2.3 PARTS LIST OF THE FRONT PIVOT Figure 4.10 PARTS LIST OF THE FRONT PIVOT (8031002–0630–1) / (8031002–0640–1) SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 41 HEX. BOLT CL8.8 ZINC PLATED M10-1.5 X 20 (DIN 931) S1111-20050-0F1 HEX. BOLT CL 10.9 ZINC PLATED M20-2.5 X 50MM (DIN 931) S1111-20070-0F1 HEX. BOLT CL 10.9 ZINC PLATED M20-2.5 X 70MM (DIN 931) 8031002-0590-1 #2 MACHINED PIVOT SUPPORT (8031002–0640–1) SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 42 4.2.4 4.2.4 PARTS LIST OF THE FRONT FRAME Figure 4.11 PARTS LIST OF THE FRONT FRAME (8032001–0010–4/5) / (8032001–0030–4/5) SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 43: Parts List Of The Front Frame

    S5111-S0863-202 RIVET POP T. DOME 1/4 X 5/8 ALUM.-ACIER S6711-00008-000 RADIAL SEAL(R.WIPER AU/STEEL)3.0X3.5X.312 8032001-0050-4 PAINTED FRONT RIGHT ST-600 FRAME (8032001–0010–4) 8032001-0300-5 PAINTED FRONT LEFT ST-600 FRAME (8032001–0030–5) 8032001-0300-4 PAINTED FRONT LEFT ST-600 FRAME (8032001–0030–4) SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 44 4.2.5 4.2.5 PARTS LIST OF THE REAR FRAME Figure 4.12 PARTS LIST OF THE REAR FRAME (8032001–0040–3/4) / (8032001–0020–3/4) SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 45: Parts List Of The Rear Frame

    HEX. NUT CL8 ZINC PLATED M20-2.5 S5111-S0863-202 RIVET POP T. DOME 1/4 X 5/8 ALUM.-ACIER S6711-00008-000 RADIAL SEAL(R.WIPER AU/STEEL)3.0X3.5X.312 8032001-0310-4 PAINTED LEFT REAR FRAME (8032001–0040–4) 8032001-0280-3 PAINTED RIGHT REAR FRAME (8032001–0020–3) 8032001-0310-3 PAINTED LEFT REAR FRAME (8032001–0040–3) SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 46: Parts List Of The Sprocket

    PAINTED 12 TEETH HALF SPROCKET # 1 8033001-0080-2 13 TEETH HALF SPROCKET S1114-12050-1D7 HEX. FLANGE BOLT ZnNi SERRATED CL8.8 M12-1.75 X 50MM (DIN 6921) S4186-M120P-021 HEX NYLON NUT CL8.8 ZINC PLATED M12-1.75 (DIN 985) 8033001-0020-2 REINFORCEMENT PLATE SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 47: Parts List Of The Wheels And Axle

    Figure 4.15 4 WHEELS 17" DIA. AXLE ASS'Y FOR 25.38" TRACK (2750151–17) ITEM PART# DESCRIPTION 2750100-4000 WHEEL RETAINING RING 2750102-3000 2.455" LG WHEEL SPACER 2750151 ST-600 AXLE ASS'Y 4400074-20 ø19" MOLDED WHEEL S5211-10002-004 O-RING N1400-0400 ø4" SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 48 / DOUBLE LIP SEAL 40 X 52 X 7 Figure 4.17 3 WHEELS 10" DIA. AXLE ASS'Y (2750152–10) ITEM PART# DESCRIPTION 2750100-4000 WHEEL RETAINING RING 2750102-3000 2.455" LG WHEEL SPACER 2750152 ST-820 AXLE ASS'Y 4400036-20 10" WHEEL S5211-10002-004 O'RING N1400-0400 ø4" SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 49 ø45 MM I.D. X ø69 MM O.D. LOCK WASHER S5211-10005-004 SNAP RING S6484-00005-000 PLUG 1/8-27NPTF ZP S6602-00002-000 ZERk GREASE FIT STRAIGHT 1/8-27 NPT HEX. 7/16 Z.P. S6701-00014-000 O-RING 1/8" X 3 3/8 ID S6711-00002-000 DOUBLE LIP SEAL 40 X 52 X 7 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 50 Page Intentionally Left Blank SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 51: Section 5 Preparation

    Make sure you have all the required parts and tools to do the installation. The parts should be clean and free of corrosion. • Familiarize yourself with components and their location. • The systems installation sequence is front/rear or rear/front, NOT left/right, right / left or diagonally. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 52: Pre-Installation Recommendations

    ARRANGE JACKS TO PREVENT INTERFERENCE WITH THE ATTACHMENTS. 5.3 PRE-INSTALLATION RECOMMENDATIONS NOTICE PROPER TORQUING OF BOLTS AND SCREWS IS CRITICAL TO SAFE OPERATION OF THE TRACK SYSTEM AND LONGER SERVICE LIFE OF ITS COMPONENTS. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 53 Before proceeding with the installation of your system, arrange parts per their assembly sequence. • The tractor may be seated on track system frames (rubber track removed). NOTICE SOUCY TRACK HIGHLY RECOMMENDS USING THREAD LOCK ON BOLTS, PARTICULARLY FOR BOLTS WITHOUT LOCKING DEVICES SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 54 Page Intentionally Left Blank SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 55: Section 6 Installation Of The Track System

    1. Raise front of the tractor off the ground and remove the front wheels. (Keep the nuts to install the sprocket adaptor). 2. If required, place a wedge block between the front differential and the frame to improve stability. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 56 4. Remove OEM zerk (I) and replace with 90°angle zerk (See 8031004-0340-1 New Holland front left part list S6601-00007-000 ). 5. Remove bottom kingpin (A), bearing (B) and bolts (C). 6. Repeat previous steps for opposite side. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 57: Front Bracket Installation

    5. Assemble clamp (7) to hose assembly and install to adaptor block (1) with bolt (8) and washer (9). NOTE Parts and fastener in 8031004-0340-1-QUINC left kit. Parts and fastener in 8031004-0350-1-QUINC right kit. ITEM PART# ITEM PART# 8031004-0540-1 S8361-06001-400 8031004-0380-1 S1131-10016-0D7 S6631-00002-004 S4612-M1000-091 S6601-00006-000 S1111-08025-0D1 S6602-00011-000 B365049-CB S6602-00002-000 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 58 7. Put and hold assembly under knuckle with bolts (3). 8. Use shims (3, 4, 5, 6) to fill the gap. Hand tight only. NOTICE FOLLOW OEM PROCEDURE FOR KINGPIN ADJUSTMENT. ITEM PART# ITEM PART# 8031004-0380-1 8031004-0410-1 S1211-12060-0F1 8031004-0420-1 8031004-0400-1 8031004-0430-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 59 11. Use 2 straight edges (C) to measure parallelism between tractor flange and adaptor plate's bolts position. 12. Compare measurement in front of the flange and the rear of flange and adjust to the same measure ±1/32 (0.7mm). 13. Remove bolts (D). SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 60 6.1.2 14. Torque kingpin bolts (1) 15. Install locking devices (2) and bolts (3). Torque bolts 33 Nm (24 Lb−ft) ITEM PART# ITEM PART# S1211-12060-0F1 S1111-08016-0D1 8031004-1410-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 61 16. Install front left bracket (1) with bolts (2) and washers (3). Hand tight only. 17. Repeat previous steps for opposite side. NOTE A ITEM DESCRIPTION NOTE A REMOVE PAINT BEFORE INSTALLATION ITEM PART# ITEM PART# 8031004-0560-1 S4515-M160G-0DC S1211-16090-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 62 WIDE POSITION: FOR STANDARD TRACK 19'' (482 mm) width front track 25'' (635 mm) width rear track) • WIDE POSITION: FOR WIDE TRACK 25'' (635 mm) width front track 32'' (813 mm) width rear track SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 63 ONLY STANDARD TRACK 25” (632 mm) NOTE B APPLICABLE FOR ST-600WT ONLY WIDE POSITION WIDE TRACK 32” (813 mm) STANDARD TRACK 25” (632 mm) ITEM PART# ITEM PART# 8031001-0060-1 / 2 S3233-B1650-0F0F 8031004-0540-1 8031004-0560-1 S3261-B2050-0J1F 4 or 6 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 64 22. Torque bolts (7) of front left bracket (6) . 23. Torque bolts (4). 24. Repeat previous steps for opposite side. 283 Nm (209 Lb−ft) 283 Nm (209 Lb−ft) ITEM PART# ITEM PART# 8031001-0270-1 S4515-M160G-0DC 8031001-0100-1 8031004-0560-1 8031001-0090-1 S1211-16090-0F1 S3233-B1650-0F0F SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 65 27. Install shim (7) and bolt (8). 28. Repeat previous steps for opposite side 114 Nm (84 Lb−ft) 391 Nm (288 Lb−ft) ITEM PART# ITEM PART# 8031004-0620-1 8031004-1580-1 8031001-0060-1 S4612-M180N-OG1 S1111-12025-0F1 8031004-1400-1 S4515-M1209-0CC S1111-18130-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 66: Installation Of The Front Pivot Support

    6.2 INSTALLATION OF THE FRONT PIVOT SUPPORT NOTE Make sure the pivot axle supports configuration is correct. See figures below. Figure 6.1 PIVOT AXLE SUPPORT CONFIGURATION P/N 8031002_0580_1 P/N 8031002_0580_1 P/N 8031002_0590_1 P/N 8031002_0590_1 P/N 8031002_0590_1 P/N 8031002_0590_1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 67 2. Install locking devices (5, 6) with bolts (7). 3. Repeat previous steps for opposite side replacing pivot support 1 (8031002-0590-1) with 8031002- 0580-1 BOLTS #3 BOLTS #4 0’’ 0 mm ITEM PART# ITEM PART# 8031002-0590-1 8031002-0620-1 8031001-0050-1 8031002-0460-1 S1111-20070-0F1 S1111-10020-0D1 S1111-20050-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 68 6. Repeat the two previous steps for opposite side replacing pivot support 1 (8031002-0590-1) with 8031002- 0580-1 BOLTS #3 BOLTS #4 2 1/2’’ 63 mm ITEM ITEM PART# PART# 8031002-0590-1 8031002-0620-1 8031001-0050-1 8031002-0460-1 S1111-20050-0F1 S1111-10020-0D1 S1111-20070-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 69: Installation Of The Front Frame

    NOTE A 45Nm (33 Lb−ft) ITEM DESCRIPTION NOTE A TENSIONER MUST POINT FORWARD FOR JOHN DEERE — MASSEY FERGUSON — KUBOTA FOR CNH ITEM ITEM PART# PART# 8031002-0610-1 S1111-20050-0F1 8032001-0010-5 8031002-0460-1 8031002-0590-1 S1111-10020-0D1 8031002-0600-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 70: Installation Of The Front Sprocket

    6.4 INSTALLATION OF THE FRONT SPROCKET 1. Install sprocket adaptor assembly (1) to hub with OEM nuts. ITEM PART# ITEM PART# 8033001-0620-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 71 [ 91mm ] 5 3/8" 2 7/8" [ 136mm ] [ 73mm ] ITEM DESCRIPTION FRONT SPROCKET — NARROW POSITION FRONT SPROCKET — WIDE POSITION SPROCKET ADAPTOR MAY DIFFER ITEM PART# ITEM PART# 8033001-0210-1 8033001-0400-1 8033001-0160-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 72 3. Install sprocket sections (1) on the sprocket adaptor (A) with washers (2) and bolts (3). Torque bolts. 4. Repeat previous steps for opposite side. ITEM DESCRIPTION IMAGE OF SPROCKET ADAPTOR MAY DIFFER ITEM PART# ITEM PART# 8033001-0160-1 S1111-16060-0F1 S4515-M160G-0DC SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 73: Installation Of The Front Track And Remaining Sprocket

    1. Loosen track tensioner (bolts 2 and 1) 2. Apply soapy water or silicon/Teflon base lubricant to internal face of track folds before installing track. This will ease installation of track. NOTE Put track folds on idler ends to ease installation. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 74 NOTE A = Direction of rotation of track NOTE A 3. Use a fork lift to put inner lug of track over sprocket mount. If there is not enough room, put lug against mount. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 75 4. Move only one row of track lugs at a time over wheels. 5. Remove jacks and engage transmission in 4WD and very slowly move tractor to bring sprocket section on top to ease track installation. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 76 6. Install sprocket (1) on the sprocket adaptor with washers (2) and bolts (3). Torque bolts . 7. Repeat previous step to install the third sprocket (4). 8. Repeat previous steps for the opposite side. 283 Nm (209 Lb−ft) ITEM PART# ITEM PART# 8033001-0160-1 S1111-16060-0F1 S4515-M160G-0DC 8033001-0400-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 77: Rear Components Removal

    1. Raise the rear of the tractor off the and remove the rear wheels. (Keep the nuts to install the sprocket adaptor). 2. If required, place a wedge block between the front differential and the frame to improve stability. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 78 3. Remove pin fastener (A). 4. Remove drawbar (B). 5. Remove drawbar support plate screws (C). 6. Remove drawbar support plate (D). Keep items (A and B), they will be reinstalled later. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 79 7. Remove bolts (A). 8. Remove stabilizer bracket (B). 9. Remove pins (C), bolts (D) and frame (E). Keep items (D and E), they will be reinstalled later. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 80 10. Remove fuel tank protector (A) 11. Cut a part of the fuel tank protector (C). If you wish NOT cutting the protector, it can not be reinstalled. ITEM DESCRIPTION CUT AT THIS POINT SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 81: Installation Of The Rear Bracket

    6.7 INSTALLATION OF THE REAR BRACKET NOTICE MODELS T7.170 - T7.185 – T6030 - T6050 - T6070 – PUMA 115 - PUMA 125 - PUMA 130 - PUMA 140 - PUMA 145 1. Install dowel pin (1) in beam (2). (use a soft face hammer).
  • Page 82 4. Install rear reinforcement (1) on rear beam (2) with washers (3) and bolts (4). Hand tight only. ITEM PART# ITEM PART# 8031004-0250-1 S4515-M200H-0EC 8031004-0020-1 S1111-20050-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 83 6. Install right stabilizer bracket (2) on rear right axle housing (6) with bolts (7) and nylon nuts (4). 283 Nm (209 Lb−ft) 283 Nm (209 Lb−ft) ITEM ITEM PART# PART# 8031004-0170-1 8031004-0860-1 8031004-0690-1 8031004-0960-1 S1111-16090-0F1 S1111-16070-0F1 S4186-M160Q-051 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 84 11. Gap (B) between housing support (C) and tractor axle housing (A) will be filled later. 12. Install rear beam assembly to tractor with bolts (5). Torque bolts. 13. Remove bolts (1). 391 Nm (288 Lb−ft) ITEM PART# ITEM PART# 8031004-1290-1 S1111-18060-0F1 8031004-0270-1 S1211-18A60-0F1 8031004-1280-1 S6701-00042-000 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 85 14. Use enough shims (1, 2, 3) to fill gap between housing support (4) and tractor axle housing (A), if necessary. ITEM ITEM PART# PART# 8031004-0310-1 8031004-0320-1 8031004-0330-1 8031004-0860-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 86 15. Install bolts (1). Torque them. 391 Nm (288 Lb−ft) ITEM PART# ITEM PART# S1111-18060-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 87 16. Install locking devices (1, 3) with bolts (2), torque bolts. 45 Nm (33 Lb−ft) ITEM PART# ITEM PART# 8031004-0300-1 8031004-1260-1 S1111-10020-0D1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 88 NEXT STEPS ARE FOR LEFT HOUSING SUPPORT ONLY. 17. Install left bracket reinforcement (1) in left housing support (2) with bolts (3, 4). Torque bolts. 283 Nm (209 Lb−ft) 283 Nm (209 Lb−ft) ITEM PART# ITEM PART# 8031004-0850-1 S1111-16210-0F1 8031004-0860-1 S1111-16060-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 89 18. Install locking devices (1) with bolts (2). Torque bolts. 65 Nm (48 Lb−ft) ITEM ITEM PART# PART# 8031002-0480-1 S1111-10020-0D1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 90 20. Make sure the rear reinforcement slotted holes (B) are aligned with frame holes (C). 21. Use shims (2, 3) if necessary. Torque bolts (4). DETAIL A ITEM PART# ITEM PART# 8031004-0220-1 8031004-0280-1 8031004-0290-1 S1111-20050-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 91 22. Use enough shims (1, 2, 3) if necessary to fill gap between rear reinforcement (4) and frame (A). 23. Install bolts (5), washers (6) and nylon nuts (7). Torque bolts. 283 Nm (209 Lb−ft) ITEM ITEM PART# PART# 8031004-1390-1 S1111-16170-0F1 8031004-1380-1 S4612-M1600-0B1 8031004-1370-1 S4186-M160Q-051 8031004-0250-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 92 24. Install stabilizer arm (A) on there brackets (1, 2). ITEM PART# ITEM PART# 8031004-0170-1 8031004-0690-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 93 25. Install drawbar (A) with OEM pins (B). SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 94 26. Install cover plate (1) on rear beam (2) with lock washers (3) and bolts (4), torque bolts. 552 Nm (407 Lb−ft) ITEM PART# ITEM PART# 8031004-0260-1 S1111-20040-0F1 (T6 – MAXXUM) 8031004-0020-1 S1111-20035-0F1 (T7 – PUMA) S4515-M200H-0EC SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 95 2. Install left housing support (3) and right housing support (4) with washers (5) and bolts (6). 3. Torque bolts. NOTE Parts and fastener in 8031004-0010-1-QUINC kit. 6 283 Nm (209 Lb−ft) ITEM PART# ITEM PART# S5361-M2050-000 8031004-0760-1 8031004-0020-1 S4515-M160G-0DC 8031004-0030-1 S1111-16060-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 96 4. Install rear reinforcement (1) on rear beam (2) with washers (3) and bolts (4). Hand tight only. ITEM PART# ITEM PART# 8031004-0250-1 S4515-M200H-0EC 8031004-0020-1 S1111-20050-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 97 6. Install right stabilizer bracket (5) on rear right axle housing (6) with bolts (7) and nylon nuts (4). 283 Nm (209 Lb−ft) 283 Nm (209 Lb−ft) ITEM PART# ITEM PART# 8031004-0170-1 8031004-0690-1 8031004-0030-1 8031004-0760-1 S1111-16090-0F1 S1111-16070-0F1 S4186-M160Q-051 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 98 10. Gap (B) between housing support (C) and tractor axle housing (A) will be filled later. 11. Install rear beam assembly to tractor with bolts (5). Torque bolts. 12. Remove bolts (1). 391 Nm (288 Lb−ft) ITEM PART# ITEM PART# 8031004-1290-1 S1111-18060-0F1 8031004-0270-1 S1211-18A60-0F1 8031004-1280-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 99 13. Use enough shims (1, 2, 3) to fill gap between housing support (4) and tractor axle housing (A), if necessary. ITEM PART# ITEM PART# 8031004-0310-1 8031004-0320-1 8031004-0330-1 8031004-0030-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 100 14. Install bolts (1). Torque them. 391 Nm (288 Lb−ft) ITEM PART# ITEM PART# S1111-18060-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 101 15. Install locking devices (1) with bolts (2). 16. Install left and right locking devices (3) with bolts (2). 65 Nm (48 Lb−ft) ITEM PART# ITEM PART# 8031004-0300-1 8031004-1260-1 S1111-10020-0D1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 102 NEXT STEPS ARE FOR LEFT HOUSING SUPPORT ONLY. 17. Install left bracket reinforcement (1) in left housing support (2) with bolts (3, 4). Torque bolts. 283 Nm (209 Lb−ft) 283 Nm (209 Lb−ft) ITEM PART# ITEM PART# 8031004-1060-1 S1111-16210-0F1 8031004-0030-1 S1111-16070-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 103 18. Install locking devices (1) with bolts (2). Torque bolts. 65 Nm (48 Lb−ft) ITEM PART# ITEM PART# 8031002-0480-1 S1111-16070-0F1 S1111-10020-0D1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 104 20. Make sure the rear reinforcement slotted holes (B) are aligned with frame holes (C). 21. Use shims (2, 3) if necessary. Torque bolts (4). DETAIL A ITEM DESCRIPTION REAR REINFORCEMENT SLOTTED HOLES FRAME HOLES ITEM PART# ITEM PART# 8031004-0220-1 8031004-0280-1 8031004-0290-1 S1111-20050-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 105 22. Use enough shims (1, 2, 3) if necessary to fill gap between rear reinforcement (4) and frame (A). 23. Install bolts (5), washers (6) and nylon nuts (7). Torque bolts. 283 Nm (209 Lb−ft) ITEM ITEM PART# PART# 8031004-1390-1 S1111-16170-0F1 8031004-1380-1 S4612-M1600-0B1 8031004-1370-1 S4186-M160Q-051 8031004-0250-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 106 24. Install stabilizer arm (A) on there brackets (1, 2). ITEM PART# ITEM PART# 8031004-0170-1 8031004-0690-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 107 25. Install drawbar (A) with OEM pins (B). SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 108 26. Install cover plate (1) on rear beam (2) with lock washers (3) and bolts (4), torque bolts. 552 Nm (407 Lb−ft) ITEM PART# ITEM PART# 8031004-0260-1 S1111-20040-0F1 (T6 – MAXXUM) 8031004-0020-1 S1111-20035-0F1 (T7 – PUMA) S4515-M200H-0EC SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 109: Installation Of The Rear Pivot Support

    WIDE POSITION: FOR STANDARD TRACK 19'' (482 mm) width front track 25'' (635 mm) width rear track) • WIDE POSITION: FOR WIDE TRACK 25'' (635 mm) width front track 32'' (813 mm) width rear track SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 110 1. Use correct configuration, see figure below. Figure 6.2 PIVOT AXLE SUPPORT CONFIGURATION P/N 8031002_0580_1 P/N 8031002_0580_1 P/N 8031002_0590_1 P/N 8031002_0590_1 P/N 8031002_0590_1 P/N 8031002_0590_1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 111 4. Repeat for the opposite side replacing pivot support #1 (8031002-0590-1) with 8031002- 0580-1 BOLTS #2 552 Nm (407 Lb−ft) 65 Nm (48 Lb−ft) ( 1/4" ) ( 6mm ) ITEM ITEM PART# PART# 8031002-0590-1 8031002-0460-1 S1111-20050-0F1 S1111-10020-0D1 8031002-0620-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 112 7. Repeat for the opposite side replacing pivot support #1 (8031002-0590-1) with 8031002- 0580-1 BOLTS #2 552 Nm (407 Lb−ft) 65 Nm (48 Lb−ft) ( 2 3/4" ( 70mm ) ITEM PART# ITEM PART# 8031002-0590-1 8031002-0460-1 S1111-20050-0F1 S1111-10020-0D1 8031002-0620-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 113: Installation Of The Rear Frame

    3. Install locking devices (6) and bolts (7). NOTE A 552 Nm (407 Lb−ft) 65 Nm (48 Lb−ft) ITEM DESCRIPTION NOTE A TENSIONER MUST POINT FORWARD. ITEM PART# ITEM PART# 8031002-0610-1 S1111-20050-0F1 8032001-0020-4 8031002-0460-1 8031002-0590-1 S1111-10020-0D1 8031002-0600-1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 114: Installation Of The Rear Sprocket

    Table 6.1 REAR SPROCKET ADAPTOR PART LIST — BAR AXLE (8033017–4030–1) DRAWING ITEM PART # QTY DESCRIPTION 8033017-4060-1 ST-600 NH T7.170-.210 CONE PAINTED REAR SPRO. ADAP. S1111-16060-0F1 HEX. B. CL10.9 ZP M16-2 X 60MM DIN 931 S4186-M160Q-051 HEX. NYLON NUT CL8.8 ZINC PLATED M16-2.0 (DIN 985) Table 6.2 REAR SPROCKET ADAPTOR PART LIST —...
  • Page 115 6.10 1. Install corresponding adaptor (A) on hub or flange with OEM nut or bolts, torque them. 2. Repeat for the opposite side. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 116 ( 226 mm ITEM DESCRIPTION REAR SPROCKET – FLANGE AXLE – NARROW POSITION REAR SPROCKET – FLANGE AXLE – WIDE POSITION REAR SPROCKET – BAR AXLE– NARROW / WIDE POSITION ITEM ITEM PART# PART# 8033001-0030-2 8033001-0080-2 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 117 3. REAR SPROCKET SHIMS CONFIGURATION (FLANGE AXLE ONLY) See configuration below. Figure 6.4 SHIMS MOUNTING – FLANGE AXLE – NARROW POSITION ITEM DESCRIPTION C, D SPROCKET LANDMARK E, F SHIM LANDMARK ITEM PART# ITEM PART# 8033001–0900–2 8033001–0080–2 8033001–0890–2 8033001–0910–1 8033001–0030–2 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 118 6.10 Figure 6.5 SHIMS MOUNTING – FLANGE AXLE – WIDE POSITION ITEM DESCRIPTION C, D SPROCKET LANDMARK E, F SHIM LANDMARK ITEM PART# ITEM PART# 8033001–0900–2 8033001–0080–2 8033001–0890–2 8033001–0910–1 8033001–0030–2 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 119 Bar axle: Adjust dual wheel hub to obtain distance. 6. Repeat previous steps for opposite side. 283 Nm (209 Lb−ft) Min 1/2’’ (13 mm) Max 5/8’’ (16 mm) ITEM PART# ITEM PART# 8033001-0080-2 S1111-16080-0F1 S4186-M160Q-051 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 120: Installation Of The Rear Track And Remaining Sprocket

    2. Apply soapy water or silicon/Teflon base lubricant to the internal face of the folding links before installing the track. to ease installation of the track. NOTE Put track folds on idler ends to ease installation. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 121 4. Use the fork lift to place the inner lug row between the inner wheel and the middle wheel on the front of the frame. Repeat for the back of the frame. Make sure the lug row is properly seated in between the sprocket inner teeth. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 122 5. Move only one row of track lugs at a time over wheels. 6. Remove jacks and place transmission in 4WD and very slowly move tractor to bring sprocket section on top to ease track installation. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 123 6.11 7. Install second sprocket section (1) on sprocket adaptor with bolts (2) and nuts (3). Torque bolts. 283 Nm (209 Lb−ft) ITEM PART# ITEM PART# 8033001-0030-2 S4186-M160Q-051 S1111-16080-0F1 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 124 6.11 8. Install reinforcement plate (1) on sprocket with bolts (2), nuts (3). Torque bolts . 9. Repeat previous steps for opposite side. 114 Nm (84 Lb−ft) ITEM PART# ITEM PART# 8033001-0020-2 S4186-M120P-021 S1114-12050-1D7 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 125: Section 7 Road Test And Final Adjustments

    (Track rubbing to fuel tank and/or fender and/or weight support, etc. See arrows). • If there is interference, contact your Soucy Track dealer. Check for interference at these points: SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 126 NOTICE SOUCY TRACK RECOMMENDS INSPECTING THE TRACK SYSTEM EVERY 250 HOURS, OR ONCE A YEAR (SEE THE MAINTENANCE SECTION). DO ANY REQUIRED ADJUSTMENTS. NOTE TOOLS NEEDED FOR THE NEXT STEPS: • Lifting device. • Standard tool set. • Measuring tape.

  • Page 127: Frame And Sprocket Alignment Procedure

    7. Once the alignment is correct, torque the attachment bolts to the required value (see APPENDIX A). 8. Do previous steps for all four corners of the vehicle. 9. Once the sprocket alignment is done on the front systems, go to Front Frames Parallelism Adjustment Procedure. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 128: Front Frames Parallelism Adjustment Procedure

    2. If the difference between the front and the back is less than 4.75 mm (3/16 in), no adjustment is required. If the difference between the front and the back is more than 4.75 mm (3/16 in), proceed as follows: SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 129 6. Tighten the steering adjusters. 7. Make sure that there is no interference between the tracks and the tractor to the left or to the right when steering. Adjust the steering limiters to avoid interference. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 130: Track Tension Adjustment Procedure

    • Soucy Track recommends the following method of measuring deflection. Other methods can be used. • For the front track system, drive the tractor forward for +/- 5 feet (1.5 m.) to release tension due to sprocket drive and stop without going backward.
  • Page 131 Use the tensioners on each side of the frame to adjust tension. Loosen or tighten the adjustment bolt by increments of 3 to 6 mm (1/8 to 1/4 in). 8. Tighten the adjustment bolt stop nut. 9. Tighten the tensioner plate bolts (2). 10. Repeat previous steps for each track. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 132: Inadequate Track Tension

    TENSION SIGNS CONSEQUENCES Too loose Ratcheting. Premature wear of track. vibration increase Loss of traction. Track derailing Too tight Loss of power and RPM Premature wear of track, bearing, sprocket teeth and planetary gearbox SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 133: Track Alignment Procedure

    • If the temperature is higher on one side but it is lower than 60 °C (140 °C), the system can be operated anyway. • Check overheating on both sides of the lug. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 134 5. After the adjustment, tighten the adjustment bolt stop nut and the tensioner plate bolts, drive the vehicle and test the temperature of the lugs again. If they are still overheating, do previous steps again. 6. Recheck track tension after alignment adjustment. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 135: Steering Limiter Adjustment Procedure

    7.7 STEERING LIMITER ADJUSTMENT PROCEDURE NOTE • Do the adjustment on a flat surface. • Note A = Steering limiter NOTE Adjust steering limiters to maximum angle without interference between the track system and the vehicle. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 136 Page Intentionally Left Blank SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 137: Section 8 Maintenance

    CAUTION > ALL TORQUES ARE AS PER APPENDIX “A” TORQUE TABLE UNLESS OTHERWISE SPECIFIED. > ALWAYS USE SOUCY TRACK APPROVED SPARE PARTS AND LUBRICANTS WHEN YOU MAINTAIN YOUR TRACK SYSTEM. > INSPECT TORQUE ON ALL BOLTS AFTER THE FIRST TWO HOURS OF USE. OPERATING WITH LOOSE BOLTS CAN LEAD TO DAMAGE TO COMPONENTS, LOSS OF TRACK SYSTEM SUB-ASSEMBLIES, AND SEVERE INJURIES OR DEATH.

  • Page 138: Axle And Wheel Lubrication

    > WIPE OFF ANY LUBRICANT THAT MAY GET ON THE TRACK. NOTE Soucy Track recommends lubricating the track system at the end of a work shift. First, hot lubricant is more efficient at getting to all the components requiring lubrication; second, this gets rid of moisture build-up.

  • Page 139: Cleaning And Storage

    Do not store track system in closed areas with electric devices that generate ozone (such as motors), or with petrol chemicals or petrol chemical vapors. • The track system is flammable. Proper fire suppression equipment is required. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 140 Page Intentionally Left Blank SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 141: Section 9 Operation

    • If accelerated scuffing should occur with high heat on the drive lugs, see the adjustment and alignment procedures or contact your Soucy Track dealer. 9.2 USE OF TALC •...

  • Page 142: Safe Operation

    • Slowly start working when operating in cold weather. • Contact your Soucy Track dealer if you have questions about operating your track system. 9.4 TRACK ROTATION • Rotate track from side to side after 1,000 hours of normal use or 500 hours of intensive use (heavy load and road travel).

  • Page 143: Road Travel Guidelines

    The combination of high speeds and heavy loads, as well as uneven road conditions, may lead to track overheating and premature damage to rubber tracks, wheels and other components. • To avoid this kind of inconvenience, Soucy Track recommends adjusting your speed on long distance trips, hot pavement or uneven road surfaces. •...
  • Page 144 Page Intentionally Left Blank SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 145: Section 10 Warranty Policy And Procedure

    This warranty policy applies to the following products only: Soucy Track Systems from Soucy International Inc. This document is a guide explaining the warranty’s limited conditions for the agricultural track system and winter trail groomer. Please note that Soucy International Inc. retains the right to make a final decision regarding repair or replacement of parts.

  • Page 146: Exclusion

    For any loss of earnings, or loss of use of an equipment part, caused by a mechanical failure; • When Soucy International Inc. is not informed by the client or authorized agent of any defect or failure within a reasonable time or during the warranty period (please refer to the "TERMS" section for more information);...

  • Page 147: Terms

    2. Only claims made by an agent authorized by Soucy International Inc. during the coverage period will be considered for warranty purposes; 3. The Claim Form of Soucy Track must be duly completed and handed in with a proof of purchase for the Soucy Track System;...
  • Page 148 Page Intentionally Left Blank SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...

  • Page 149: Section 11 Replacement Program For Rubber Tracks

    Rubber tracks from Soucy International Inc. benefit from a prorated replacement warranty program. • Soucy rubber track used for agricultural and winter-trail grooming purposes: prorated replacement coverage of up to twenty-four (24) months or two thousand (2000) hours of operation, whichever comes first, based on the end user...
  • Page 150 Repeat the measurement at 3 locations along the length of the track. d. Record each of the dimensions on a sketch of the track. SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 151 10,9 12,9 Bolt Ø (mm) Thread Coarse Fine Coarse Fine Coarse Fine Coarse Fine Coarse Fine Ptich 2,00 1,50 2,50 1,50 2,50 1,50 2,50 1,50 3,00 1,50 (mm) Class Tightening Torque (ft-lb) 10,9 12,9 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 152 Tightening Torque Nm 10,9 Bolt Ø (mm) Class Tightening Torque (ft-lb) 10,9 NOTE • Applicable to new lubricated, new unlubricated and used lubricated bolts. • Torque indicated on drawing is always prevailing. Torque Tolerance ± 5% SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 153 SOUCY TRACK SYSTEMS USER GUIDE A-8C0214-3-EN...
  • Page 154 In order to prevent any transcription and/or transmission error during registration process, We recommend using the electronic copy of this form available on the Soucy Track Data Center at: http://datacenter.soucy-track.com. Note that you must be a Soucy Track dealer to apply for a free access to this Web site TRACK SYSTEM REGISTRATION FORM Fill out the following fields and return to Soucy Track Technical Service Department at service.soucy-track@soucy-...
