INSTRUCTION
MANUAL
HIGHBAY 200W
9992051
DIRHB200LEDDL
INSTALLATION INSTRUCTIONS
Installation Instructions using eye bolt:
1.
Ensure that the power has been isolated before
attempting installation
2.
Ensure the desired location is suitable and clear of
all obstruction
3.
Install a suitable standard three pin socket (240V
10A) adjacent to the mounting point
Note: Highbay light has a 2m flex and plug
provided
4.
Ensure mounting hook is suitable to carry the weight
of the Highbay light
5.
Using all appropriate safety measures, hang Highbay
light on mounting hook and ensure it is secure
6.
Plug Highbay light into 3 pin socket
7.
Energise and test luminaire
Installation Instructions using wall bracket:
1.
Ensure that the power has been isolated before
attempting installation
2.
Ensure the desired location is suitable and clear of all
obstruction
3.
Install a suitable standard three pin socket (240V 10A)
adjacent to the mounting point
Note: Highbay light has a 2m flex and plug provided
4.
Use the wall bracket to mark the hole centres for
fixing. Drill holes suitable to accept wall plugs
5.
Insert wall plugs
6.
Fix Bracket to wall using appropriate screws
7.
Fit the luminaire to the wall bracket
8.
Terminate supply wiring to the luminaire in an
approved manner. Ensure that IP rating is maintained
9.
Check seals, gaskets and cable gland operation
SPECIFICATIONS
Rated Power
Input Votage
Power Factor
CRI (Ra)
Lumen Output
Colour Temperature
Ingress Protection Rating IP65
Beam Angle
Product Dimensions
Warranty
before testing the luminaire
10.
Energise and test luminaire
WARNING: RISK OF ELECTRIC SHOCK
This product shall be installed by a licenced electrician
in compliance with the requirements set out in AS/NZS
3000 (current edition) and other relevant Standards and
Regulations pertaining to the installation.
This product must only be used for the purpose outlined in
this instruction manual.
Failure to follow these instructions may result in serious
injury or death.
Prior to installing this product, check whether the product
has been damaged during transport. Do not operate/
install the product if damaged in any way. Return complete
product to the place of purchase for inspection, repair or
replacement.
200W
240VAC, 50Hz
0.9
>80
24000Lm
5000K
110°
430x157mm
3 years
