Superior Lighting SOL-DTD-15W-60K-PIR Quick Start Manual

Programable LED Solar Street Light
3
SOLAR
Features
LED solar light uses no electricity and is
eco friendly. No wiring needed.
LED solar light includes a dusk-to-dawn
and motion sensor to preserve the battery
and extend solar light output.
Includes a remote to program / override
default motion and brightness settings.
(Except 15W)
Multiple working / brightness settings
available for a wide variety of applications
including "Always On" or multiple bright-
ness levels. (Except 15W)
Can be installed on a Straight 2.5 diameter
Pole, Curved Pole, or Wall Mounted.
(Pole / Arm Not Included)
100% IP65 Waterproof.
3-year warranty.
Working Temp: 0 -113 F
Must be charged in direct sunlight.
Fixture cannot be covered in snow or
shade.
15W
(Remote Not Available With 15W)
Programmable LED Solar Street Light
Quick Search Code:
Product No
SOL-DTD-15W-60K-PIR
SOL-DTD-40W-60K-REMOTE
SOL-DTD-80W-60K-REMOTE
SOL-DTD-120W-60K-REMOTE
Superior Lighting | 3530 NW 53rd St Fort Lauderdale, FL 33309 | 1-800-545-7778
Application
Garden
Deck
Yard
Patio
Driveway
Parking lot
Small Roadway
40W
3
SOLAR
Watts Lumens Color Temp Mounting Height Dimensions
15W 1600LM 6000K
40W 4800LM 6000K
80W 12000LM 6000K
120W 18000LM 6000K
80W
10ft – 12ft 19.5"x8.75"x2.25"
12ft -16ft 28"x11"x3"
16ft - 20ft 45" x 16" x 3.5"
20ft - 26ft 64" x 17" x 3.5"
Working Time
3 nights after a full charge with factory
default motion sensor settings.
(Working time data is based on charging 8 hours in the
summer, measured in north latitude 22 , east diameter 13 .
Working time may change depending on installation areas,
seasons, environments, and lighting mounting direction)
PIR sensor angle 120
Detection area 26 feet - 39 feet
120W
Battery
7.4V 5400mAh
32650/9.6V
32AH 14.8V
48AH 14.8V
