Schonbek Geometrix DVT1012A Trim Diagram

Da vinci lamp

Trim Diagram

Da Vinci Lamp DVT1012A

6 Lights

Diameter: 10"

Height: 11-1/2"

™

Geometrix

is designed by Schonbek

with Swarovski Spectra

crystal.

This design is the proprietary trade

dress/trademark of Schonbek Worldwide Lighting Inc.

Please save your trim diagram for future reference.

Schonbek Worldwide Lighting Inc., 61 Industrial Blvd., Plattsburgh NY 12901-1908

IMPORTANT: Label on back contains important

Tel: 800.836.1892 or 518.563.7500 www.schonbek.com or www.geometrix-lighting.com

information on your crystal. Please save in case you

For cleaning instructions, visit www.schonbek.com or www.geometrix-lighting.com

ever need to order matching crystal.

US UTILITY PATENT #5,906,430, D560,019 & D558,390

CANADIAN DESIGN

#116775

Table of Contents

Need help?

Do you have a question about the Geometrix DVT1012A and is the answer not in the manual?

Page 1 Please save in case you For cleaning instructions, visit www.schonbek.com or www.geometrix-lighting.com ever need to order matching crystal. © 2006 SCHONBEK WORLDWIDE LIGHTING INC., A. SCHONBEK & CO. LTD. WORLDWIDE COPYRIGHT RESERVED US UTILITY PATENT #5,906,430, D560,019 & D558,390 CANADIAN DESIGN...
Page 2 NOTES: Frequency of cleaning crystal We know people who clean their crystal every few months, because they love handling the crystals and admiring them close up. Others do a cleaning every six or nine months. To stretch the time between cleanings, dust lightly every two or three months with a feather duster, lambswool duster or make-up brush.
Page 3 CRYSTAL IDENTIFICATION SHEET REPLACING CRYSTAL: BOTTOM LARGE TOP If a crystal breaks, you'll see a bare spot in the framework. You will OCTAGON need a set of needlenose pliers to replace the crystal. Make sure 8002/10 8002/10 when placing pliers onto the metal tab that the ends of the pliers 8002/16 8002/16 do not go beyond and scratch the crystal.
Page 4 How to take apart your Da Vinci for changing bulbs or washing: 6 - G9 JCD (Supplied - Schonbek #JCD-G9-40) Remove top crystal circle. 40 Watts Max Install bulbs and be sure to test #11068 Remove bottom by unscrewing large bottom fixture BEFORE assembly.
