Demount First Bead
Break and lube both beads.
Lay tire on floor with short side
of wheel up.
Lift large end. (Improper lifting
will cause the tool to roll)
Demount Second Bead
Fully insert large end into gap
between wheel and tire until
you feel bottom bead.
768 E. North Street • P.O. Box 9320 • Akron, Ohio 44305
Website: www.kentool.com
Instruction Manual
T2001 #35449 Demount Tool
Hold curved part of large end,
with the tip facing up, behind
you.
Step through the wheel and
pull tool across center of wheel.
Lift small end, step through
the wheel and pull tool across
center of wheel.
E-mail: sales@kentool.com
Keeping fingers out of the area
between tool and tire/wheel,
fully insert small end, between
rim and tire bead nearest you,
in top bead of tire.
Push tool down to opposite
side. First bead is now
demounted. Remove tool from
wheel. Do not pick up
tire/wheel.
Push tool down to opposite
side. Tire is now fully
demounted.
Phone: 330-535-7177
Fax: 330-535-1345
Copyright 6/00
