For maximum effectiveness and safety, please read these
instructions completely before proceeding with installation.
Alernatively you may also watch the RC Pro install video.
Failure to follow these instructions or those provided in install
video can result in incorrect installation, damage to RC
Hardware, and or damage to vehicle and accessories wired
into the RC hardware.
Installation Guide
- RC Pro
Page 1
Advertisement
Summary of Contents for RideController RC Pro
- Page 1 For maximum effectiveness and safety, please read these instructions completely before proceeding with installation. Alernatively you may also watch the RC Pro install video. Failure to follow these instructions or those provided in install video can result in incorrect installation, damage to RC Hardware, and or damage to vehicle and accessories wired into the RC hardware.
- Page 2 Installation Guide - RC Pro TABLE OF CONTENTS (not yet complete) Quick Start ……………………………………………………………………….. 3 Hardware List ……………………………………………………………………….. 5 Intro ………………………………………………………………………. 6 PowerPack ………………………………………………………………………. 7 Core ………………………………………………………………………. 9 Wiring ………………………………………………………………………. 5 Installation Diagram ………………………………………………………………………. 5 Setup Via RC Application ………………………………………………………………………. 12 Limited Warranty &...
- Page 3 The hardware is water resistant but not rated for full submersion. 2. Feed PowerPack hot (larger 2 gauge wire) & ground (smaller 16 gauge wire). 3. Download Free RC app. www.RideController.com 4. Connect via Bluetooth by pressing the top left hand corner wireless connection icon.
- Page 4 (12 volt) accessories wired into it. Download the RideController application for FREE to give you complete control of your RC Pro system. The application will keep you up to date with the latest and greates features offered by RC.
- Page 5 Installation Guide - RC Pro Hardware List Item A - RC Core Item B - RC PowerPack Item C - RC PowerPack Hot - 175AMP Tiny Fuse Item D - RC PowerPack 18Ground Tiny Fuse PowerPack Hot RC Core RC PowerPack...
- Page 6 Installation Guide - RC Pro Introduction The RC Pro is a modular network that has 8 (max 64 with 8 PowerPacks) powered outputs rated @ 30AMPs each along with integrated self healing fuses. The RC Pro modular system is controlled via the RC Pro - Core (smart controller) and up to 8 daisy chained RC - PowerPacks which handle all the power distribution.
- Page 7 The RC SwitchPack communicates via a wired CANBUS communication network. This allows the end user to control outputs on a RC Pro - PowerPack via any 12 volt hot input. This hot input could come from many 3rd party physical switches or even factory Up Fitters on OEM vehicles for example Ford SuperDuty and Ford Raptors.
- Page 8 1-8 Hot Outputs Rated @ 30AMPs Max Current Draw 160AMPs Max Current Draw Per PowerPack Strobe / Dimming Support Controlled Via RideController App Momentary Output Support - Latched Output Support Daisy Chainable - Daisy Chain Up To 8 PowerPacks For 64 Outputs Chassis Ground All Accessories &...
- Page 9 CANbus Network Communication Between Core & PowerPack(s) Remote Mount Bluetooth Antenna Option with 75-150FT Range Low Voltage Accessory Shutdown & Battery Maintainer Custom Security Pin Code - Only You Can Control Your RC Pro Custom App Layout Is Stored Locally On The RC Core Page 8...
- Page 10 Installation Guide - RC Pro SwitchPack - Features 8 External 12V+ Input Triggers CANbus Network Communication Between Core & PowerPack(s) BYOS (Bring Your Own Switches) - Allows Users Complete Control Integrates With Factory Physical Swithces (Example Ford Upfitters) Page 8...
- Page 11 Installation Guide - RC Pro SwitchPack - Pigtail Pinout - Backside 12V + Input 4 Input 3 Input 2 Input 1 (optional) 12V - Input 8 Input 7 Input 6 Input 5 (optional) Optional: 12V + & 12V - larger red and larger black wires on pigtail can be used to power your BYOS Switch Backlights.
- Page 12 Installation Guide - RC Pro Real World Layout Page 11...
- Page 13 Installation Guide - RC Pro Core Dimensions *increments are in inches 2.720 4.193 4.713 1.048 Page 12...
- Page 14 Installation Guide - RC Pro PowerPack Dimensions *increments are in inches 8.116 1 2 3 4 5 6 7 8 3.938 2.250 4.313 7.625 1.255 Page 13...
