Summary of Contents for Fruitdock DoBox
- Page 1 DoBox User Manual The latest versions are: App version: 1.5.4 DoBox version 1.3.2 DoBox ® i s a brand of Fruitdock Ltd. All rights reserved. 2020...
-
Page 2: Table Of Contents
8.4 HDMI resolution 8.5 General 8.5.1 About 8.5.2 Software update 8.5.3 Reset content, settings, registration 9. File sharing 10. Multimedia player 11. Notepad 12. Browser DoBox ® i s a brand of Fruitdock Ltd. All rights reserved. 2020... -
Page 3: First Time Setup
First time setup Make sure to first charge the battery for at least 10 hours while the DoBox is turned off (not showing a continuous white light but rather pulsating), otherwise it won’t function properly! If it doesn’t light up, please reset on the DoBox with a pin or paperclip in that little hole under the audio output. - Page 4 2.) Follow the instructions on the screen to wake up and turn on your DoBox: 3.) After 1 minute go to your iPhone / iPad Wi-Fi settings and connect to the DoBox’s hotspot. DoBox ® i ...
-
Page 5: Charging The Dobox
8 characters. Charging the DoBox DoBox can be charged through its USB-C port on the left side. The cable in the box can be used for charging only. Use with standard USB chargers at least 1000mA (1A) capacity, for e.g. iPhone / iPad chargers. -
Page 6: Switch On, Connection And Switch Off
If the DoBox turned on successfully, it will show up in 40 seconds among the Wi-Fi networks on your iPhone. T he default SSID is: DoBox. I f the signal doesn’t show up after 40 seconds, turn the Wi-Fi off and on again on your device. -
Page 7: Usb-C Hub Mode
When DoBox is switched off, and connected with the new MacBook Pro via a USB-C to USB-C cable, the two standard USB ports of the DoBox can be used natively on the new MacBook Pro. In this mode, the MacBook Pro is simultaneously charging the battery of the DoBox. -
Page 8: The Functions Of The App
External storage devices like USB sticks or micro SD cards will also show up here. 2. Wi-Fi With this connection, the DoBox is able to connect to the internet. You can select here the Wi-Fi network that you want to use. The DoBox can connect only to 2.4GHz Wi-Fi networks. - Page 9 To copy a file to the DoBox’s storage, select the desired folder, click on New File, and choose from the options. Select Photos or Videos button on the bottom of the screen. Select what you want to upload to the storage and tap on it once then choose Done.
-
Page 10: Bluetooth
4. Bluetooth 4.1 Connect to a Bluetooth speaker The DoBox can connect to Bluetooth speakers so you can send the audio from the DoBox to the Bluetooth speaker. Turn on your speaker just tap on the speaker name here. 4.2 Bluetooth Bridge Mode Thanks to the new iOS 13 and iPad OS, you can now connect a standard mouse and keyboard, and use them system-wide on your iPhone or iPad. - Page 11 5.) Plug in a mouse and a keyboard to DoBox 6.) Turn on your DoBox 7.) Connect to the DoBox’s Hotspot 8.) Open the DoBox app 9.) In the app go to Bluetooth menu 10.) Enable Bluetooth Bridge Mode 11.) From then, DoBox is discoverable for 3 minutes...
-
Page 12: Dobox Connect - Screen Sharing Client
5. DoBox Connect - Screen sharing client DoBox Connect is an app for MacOS devices that lets you control your Mac remotely with your iPad/iPhone and with the DoBox. Enable Screen sharing on your Mac: ● Open System preferences — Sharing and enable Screen sharing ●... - Page 13 ● Click on the DoBox icon in the status bar ● Login with registered email and password Open the the DoBox app on your iPhone/iPad ● Plug in a mouse and a keyboard ● Tap on Screen sharing client menu ●...
-
Page 14: Local Network
Colors can be changed according to the RGB scale. If you want blue light for example, then slide the red and green dots to the left. Changing the color here affects the background of the app too. DoBox ® i s a brand of Fruitdock Ltd. All rights reserved. 2020... -
Page 15: Settings
You can change the HDMI resolution here. After the change a restart is needed. The default resolution is 1920x1080. To use the HDMI port, you have to plug in the cable while the DoBox is switched off. After that turn on the DoBox and you’ll see the DoBox logo on the screen. -
Page 16: General
8.5 General You can find here general info about the DoBox, search for updates, or reset the settings to default. 8.5.1 About You can check the current app and firmware versions here. The latest versions are: App version: 1.5.4 ; DoBox version 1.3.2 WARNING: We support only the latest versions. -
Page 17: Software Update
You can reset not only the content, but your user profile, registration and all settings, as well. This function can be found inside the DoBox app, under “ Settings > General > Reset content, settings, registration” It will ask for confirmation before applying the operation. This method is useful when you want to sell your device to somebody else. -
Page 18: File Sharing
To browse the Shared folder on your Mac f rom the Finder menu click on G o and C onnect to server... and type this to server address: s mb://dobox than click to C onnect and choose a s Guest... -
Page 19: Multimedia Player
10. Multimedia player To use the HDMI port, you have to plug in the cable while the DoBox is switched off. After that turn on the DoBox and you’ll see the DoBox logo on the screen. The Multimedia player lists all the media files found on the internal storage and the external devices.
