Page 1 User Manual Gemini 90 Extraction System...
Page 2: Table Of Contents
User Manual Contents Introduction Page 3-7 Precautions Page 3 Introduction Page 4 Product Breakdown Page 4 Specification Page 5 Online Resources Page 7 How To Use Page 7-11 How To Assemble Page 7 Page 7 Packing The Column Page 8 Pulling A Vacuum Cooling The Column Page 9...
Page 3: Introduction
Introduction Precautions - Never put butane filled tubes in the freezer. - Always use in extremely well-ventilated OUTDOOR Areas. - Never operate near/around Open flames or other ignition sources or risk fiery, explosive death. - When using large amounts of dry ice, oxygen deprivation can occur.
Page 4: Introduction
Introduction Introducing BHO Hardware’s exclusive open column material system, the Gemini 90. Part of our Gemini series, the 90 is capable of holding and processing between 53-91g of material. The user Can develop solvent pressure by closing the valve at the bottom of the Gemini 90 and packing it with material.
Page 5: Product Breakdown
Introduction Product Breakdown Mb Non-Return Valve End Cap Gasket Tri Clamp Column Gasket Filter Quadpod / 4 Prong Stand Gas Outlet Ball Valve Male Hose Tail Connector...
Page 6: Specification
User Manual Specifications Name, Index, Type Gemini 45 Gemini 90 Gemini 130 Different Accessories Can be added to the equipment to suit your needs.
Page 7: Online Resources
How To Use Online Resources 1. For more information including a full walkthrough of the Gemini 45 Extraction System, please visit: www.bhohardware.com and search ‘Guides and How To’...
Page 8: How To Use
How To Use How to Assemble 1.For instructions on assembly please see the complete video walkthrough How To Use Packing The Column 1.Firstly, remove the clamp at the top of the column. Then begin to pour in your material. (Tip: use a packing rod to compress the material, this will result in better absorption and a cleaner, higher yield).
Page 9: Pulling A Vacuum
How To Use Pulling a Vacuum 1.Once the column is full you can pressurize the column to remove excess oxygen and moisture. To do this, ensure that the bottom valve is in the “closed” position. Then attach a hose to the bottom of the column and open the valve. Next, ensuring the hose is connected to a pump, turn on the pump and begin to remove the oxygen and moisture from within the column.
Page 10: Administering Butane
How To Use Administering Butane 1. Once the tube has been frozen, simply insert the butane into the port on the top and fill it to the necessary capacity 2. Once you have administered the necessary amount, let the tube sit for between 10-30 minutes.
Page 11: Removing Your Solvent Page 1
How To Use Removing Your Solvent 1.Now you have your oil/solvent soulution, the solvent can be removed. Place the container into a warm water (Aprox 40-60°C). This will cause the majority of the solvent to evaporate out of you oil. Once the solution begins to stop bubbling, enough butane has been removed to go on to the final process.
Page 12: Troubleshooting
User Manual TroubleShooting Possible Reason Problem Solution...
Page 13 Thank you for buying with BHO Hardware. We hope your newly-assembled hardware suits your requirements. If any problems arise with our equipment, contact our team via the following: orders@bhohardware.com www.bhohardware.com 0114 229 1807...
Page 14 Thank you. Orders@bhohardware.com www.bhohardware.com 01 14 229 1807...
