High-Desert DELUXE GAME CART Manual

DELUXE GAME CART

*Actual product may vary slightly

Please carefully read and save these instructions before attempting to assemble, maintain, install, or operate this product.

Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property

damage and/or personal injury. Please keep instructions for future reference.

For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping.

For Customer Service, Call 1-800-348-5004

10400

01/2017

or e-mail customerservice@focus-ontools.com

Table of Contents

Need help?

Do you have a question about the DELUXE GAME CART and is the answer not in the manual?

Page 1 DELUXE GAME CART *Actual product may vary slightly Please carefully read and save these instructions before attempting to assemble, maintain, install, or operate this product. Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property damage and/or personal injury.
Page 2 SPECIFICATIONS Capacity 300 Lbs 52-3/4" L Xx 26-5/8" W x 31-3/4" H (Open) Product Size 42-3/8"L x 26-5/8" W x 15-3/4" H (Closed) Wheel Size 16" Products Weight 28 Lbs UNPACKING When unpacking, check and make sure that all the parts within the packing list are included. PACKING LIST Item Description...
Page 3 ASSEMBLY INSTRUCTION WARNING: Read the all above Important Safety Information before use the cart. 1. Open the carton, take out the Cart Body (1). (Fig.1) 2. Insert the Wheel Axle (3), assemble two Flat Washers (4) on both sides. (Fig.2) 3.
Page 4 Fig. 8 Fig. 7 COMPONENT LIST Item Description Item Description Bracket 1 Wire Lock Pin(S) Bracket 2 Hex Bolt M8*65 Flat Washer Φ8 Wheel 16" Wheel Axle Lock Nut M8 Flat Washer Φ12 Support Bar Wire Lock Pin(L) Lock Nut M12 customerservice@focus-ontools.com 1-800-348-5004...
Page 5 Limited Manufacturer Warranty FOT makes every effort to ensure that this product meets high quality and durability standards. FOT warrants to the original retail consumer a 1-year limited warranty from the date the product was purchased at retail and each product is free from defects in materials.
