EasyDry®
Fan and Heater
Installation and Operator's Manual
This manual applies to the following models:
LP, VP, and NG fired heaters
Original Instructions
Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
INSTALLATION AND WIRING MUST BE IN
ACCORDANCE WITH CEC, NEC, AND LOCAL
Part Number: 250051 R6
Revised: February 2021
ELECTRICAL
Original Instructions

Advertisement

Table of Contents

Troubleshooting

loading
Need help?

Need help?

Do you have a question about the EASYDRY N-EZD15LP43 and is the answer not in the manual?

Questions and answers

Summary of Contents for AGI WESTEEL EASYDRY N-EZD15LP43

  • Page 1 EasyDry® Fan and Heater Installation and Operator’s Manual This manual applies to the following models: LP, VP, and NG fired heaters Original Instructions INSTALLATION AND WIRING MUST BE IN ACCORDANCE WITH CEC, NEC, AND LOCAL ELECTRICAL Read this manual before using product. Failure to Part Number: 250051 R6 follow instructions and safety precautions can Revised: February 2021...
  • Page 3 This product has been designed and manufactured to meet general engineering standards. Other local regulations may apply and must be followed by the operator. All personnel must be trained in the correct operational and safety procedures for this product. Use the sign-off sheet below to record initial and periodic reviews of this manual with all personnel.
  • Page 4 New in this Manual The following changes have been made in this revision of the manual: Description Section Burner assembly updates were made. Burner/Pressure Assembly and LP Fuel Train, 30 HP Ezee Dry Burner Controls Duct Assembly (006864) — External View, 30 HP and 15 HP Ezee Dry Burner Assembly (006864) and LP Vapor Fuel Train, Burner Assembly (N-009757)

  • Page 5: Table Of Contents

    EASYDRY® – FAN AND HEATER CONTENTS 1. Introduction ............................8 1.1 Product Information........................8 1.2 Serial Number Location......................9 1.3 Intended Use ........................... 10 1.3.1 Misuse ........................10 2. Safety..............................11 2.1 Safety Alert Symbol and Signal Words..................11 2.2 General Product Safety ......................11 2.3 Fan Safety ..........................
  • Page 6 EASYDRY® – FAN AND HEATER 6.8 Drying Considerations ......................44 6.9 Storage Instructions ........................ 45 7. Maintenance ............................46 7.1 Maintenance Safety ........................ 46 7.2 Maintenance Schedule......................46 7.3 Visually Inspect the Fan and Heater ..................47 7.4 Initial Operation / First Season Use / Yearly Maintenance ............ 47 7.5 Pressure Regulator Maintenance....................
  • Page 7 EASYDRY® – FAN AND HEATER 10.4.12 Motor Drive Assembly ..................87 10.5 Recommended Bolt Assembly ....................89 11. Limited Warranty: Westeel Grain Bin Products ................90 250051 R6...

  • Page 8: Introduction

    1. INTRODUCTION EASYDRY® – FAN AND HEATER 1. Introduction Thank you for your purchase. Follow the instructions in this manual for safe use of this fan and heater. Following proper operation and maintenance will help to keep the fan and heater running in optimal condition.

  • Page 9: Serial Number Location

    1. INTRODUCTION EASYDRY® – FAN AND HEATER 1.2. Serial Number Location The serial number location for your fan and heater is shown in the figure below. Have the serial number ready when ordering parts or requesting service or other information. Record information in the table below for easy reference.

  • Page 10: Intended Use

    1. INTRODUCTION EASYDRY® – FAN AND HEATER 1.3. Intended Use The fan and heater is intended for use as listed below and described throughout this manual. Use in any other way is considered contrary to the intended use and is not covered by the warranty. Intended use for the fan and heater: •...

  • Page 11: Safety

    2. SAFETY EASYDRY® – FAN AND HEATER 2. Safety 2.1. Safety Alert Symbol and Signal Words This safety alert symbol indicates important safety messages in this manual. When you see this symbol, be alert to the possibility of injury or death, carefully read the message that follows, and inform others.

  • Page 12: Fan Safety

    2. SAFETY EASYDRY® – FAN AND HEATER 2.3. Fan Safety • Keep away from fan impeller/blade; high suction can pull a person toward the inlet. Contact with an unguarded impeller/blade will cause severe injury. • Keep the inlet screen in place at all times. •...

  • Page 13: Gas Leak Hazards

    2. SAFETY EASYDRY® – FAN AND HEATER 2.5. Gas Leak Hazards If You Smell Gas: • Turn off gas at the source if possible. • Do not try to light or relight any appliance. • Extinguish any flames and remove any sources of ignition from the vicinity of the bin. •...

  • Page 14: Safety Equipment

    2. SAFETY EASYDRY® – FAN AND HEATER Hard Hat • Wear a hard hat to help protect your head. Steel-Toe Boots • Wear steel-toe boots to protect feet from falling debris. Work Gloves • Wear work gloves to protect your hands from sharp and rough edges. Fall Protection •...

  • Page 15: Drives And Lockout/Tagout Safety

    2. SAFETY EASYDRY® – FAN AND HEATER 2.10. Drives and Lockout/Tagout Safety Inspect the power source(s) before using and know how to shut down in an emergency. Whenever you service or adjust your equipment, make sure you shut down your power WARNING source and gas supply and follow lockout and tagout procedures to prevent inadvertent start-up and hazardous energy release.

  • Page 16: Safety Decals

    2. SAFETY EASYDRY® – FAN AND HEATER 2.11. Safety Decals • Keep safety decals clean and legible at all times. • Replace safety decals that are missing or have become illegible. See decal location figures that follow. • Replaced parts must display the same decal(s) as the original part. •...
  • Page 17 2. SAFETY EASYDRY® – FAN AND HEATER Table 1. Safety Decals Ref. Part Description Location Number Number 036725B control panel cover, inside High Voltage — Lock out before servicing 079337 (burner) access door, outer door WARNING — Close Compartment K20101 LP burner controls duct, both sides Air flow direction WARNING —...

  • Page 18: Features

    3. FEATURES EASYDRY® – FAN AND HEATER 3. Features Read this section to familiarize yourself with the basic component names and functions of the fan and heater. Figure 3. Typical Fan and Heater Assembly EASYDRY BIN STIFFENER LINE (sold with the EasyDry Bin) Reference Description Number...

  • Page 19: Preparation

    4. PREPARATION EASYDRY® – FAN AND HEATER 4. Preparation 4.1. Check Shipment Inspect the fan and heater and accessories on receipt to ensure that all items have arrived and that none are damaged. A few basic items to check: • Ensure there are no loose items or debris that can be drawn into the fan or dislodged by the fan discharge. Check the interior of the fan as well.

  • Page 20: Installation

    5. INSTALLATION EASYDRY® – FAN AND HEATER 5. Installation Before continuing, ensure you have completely read and understood this manual’s Safety section, in addition to the safety information in the section(s) below. 5.1. Installation Safety • All installation and servicing operations are to be carried out by qualified technicians. •...
  • Page 21 5. INSTALLATION EASYDRY® – FAN AND HEATER Note For wiring specifics, see Section 5.2.1 – Wiring Diagram on page Do not bypass or remove the heater/fan motor interlock that prevents the heater from starting if the fan is not running. Doing so could result in a fire and injury. Make certain the heater is wired/interlocked to the fan motor controls.
  • Page 22 5. INSTALLATION EASYDRY® – FAN AND HEATER provides the grounding needed during operation and long-life protection of control circuits in the fan and heater. Westeel does not supply or sell ground rods and wires. Please contact your local electrical parts supplier for these parts.

  • Page 23: Wiring Diagram

    5. INSTALLATION EASYDRY® – FAN AND HEATER 5.2.1 Wiring Diagram The following wiring diagram shows the correct wiring for the Fan and Heater. It also indicates how to wire this unit for stand-alone operation. However, it does not indicate how to wire the fan and heater to the EasyDry® controls.
  • Page 24 5. INSTALLATION EASYDRY® – FAN AND HEATER Figure 5. EasyDry® Fan and Heater Wiring Diagram Important For fan/heaters installed in Canada: All wiring must be done in accordance with the Canadian Electric Code, Part I, CSA C22.1. 250051 R6...

  • Page 25: Fuel Supply

    5. INSTALLATION EASYDRY® – FAN AND HEATER 5.3. Fuel Supply Important • Westeel suggests hiring a professional to plan, set up, and connect the chosen fuel supply. The system must include an emergency shut-off valve. • Refer to the fan/heater rating decal for determining the minimum gas supply pressure for obtaining the maximum gas capacity for which this fan/heater is specified.
  • Page 26 5. INSTALLATION EASYDRY® – FAN AND HEATER Important Required: Make sure the supply tank has a properly sized relief valve, a vapor tap, and a liquid tap with a rapid flow shutoff valve to stop the flow of propane in case of a break in the gas line. The liquid tap should have a rapid flow shutoff valve to stop the flow of propane if a fuel line breaks.
  • Page 27 5. INSTALLATION EASYDRY® – FAN AND HEATER Table 3. Line Sizing Chart — Liquid Propane (LP) Gas Liquid — Copper Tubing Line Length Copper Tubing — Type K Liquid Propane Flow Rate Outside Diameter 3/8” (9.5 mm) 1/2” (12.7 mm) 5/8”...

  • Page 28: Pre-Assemble The Ductwork Sections

    5. INSTALLATION EASYDRY® – FAN AND HEATER Vapor Propane (VP) Fuel • Refer to Liquid Propane (LP) Fuel on page 25. This manual section contains important information pertaining to propane fuel. • The heater must be connected to the vapor valve of a supply tank or an external vaporizer. Natural Gas (NG) Fuel •...
  • Page 29 5. INSTALLATION EASYDRY® – FAN AND HEATER Assemble the 36” (914 mm) Air Duct Spacer Section (PN 008421) 008419 SPACER SIDE 36” 008420 SPACER END 36” 008415 AIR DUCT MOUNT BRACKET 008419 SPACER BACK 36” 008419 SPACER SIDE 36” 008415 AIR DUCT MOUNT BRACKET Note •...
  • Page 30 5. INSTALLATION EASYDRY® – FAN AND HEATER Assemble the 44” (1,118 mm) Air Duct Intermediate Section (PN 008416) 008411 INTERMEDIATE 008412 INTERMEDIATE END 44" SIDE 44" 008415 AIR DUCT MOUNT BRACKET 008412 INTERMEDIATE END 44" 008411 INTERMEDIATE 008415 AIR DUCT SIDE 44"...

  • Page 31: Install The Ductwork Sections And Fan/Heater To The Easydry® Bin

    5. INSTALLATION EASYDRY® – FAN AND HEATER 5.5. Install the Ductwork Sections and Fan/Heater to the EasyDry® Install the ductwork sections, the heater and the fan to the bin sidewall at the same time the bin is raised. Assembling the EasyDry® Fan and Heater and ductwork sections to the bin after the bin is raised and constructed is not recommended.
  • Page 32 5. INSTALLATION EASYDRY® – FAN AND HEATER Table 5. One Fan Entrance Ductwork Quantities PART NUMBERS & QUANTITIES NUMBER OF TIERS 006530 008421 008416 Table 6. Two Fan Entrance Ductwork Quantities PART NUMBERS & QUANTITIES NUMBER OF TIERS 006530 008421 008416 Install the Air Duct Hood and Air Duct Spacer Refer to...
  • Page 33 5. INSTALLATION EASYDRY® – FAN AND HEATER Figure 8. Installing the Air Duct Hood and Air Duct Spacer FAN ENTRANCE COLLAR SIDE WALL STIFFENERS AIR DUCT HOOD ASSEMBLY 006530 AIR DUCT MOUNT BRACKET 008415 AIR DUCT SPACER ASSEMBLY 008421 250051 R6...
  • Page 34 5. INSTALLATION EASYDRY® – FAN AND HEATER Install the Air Duct Intermediate Sections 1. Install the air duct intermediate sections to the bin by nesting the air duct mount brackets inside the middle of the stiffeners. Use 3/8” x 1” bin bolts with seal washers and 3/8” hex nuts. Fill all mating holes. 2.
  • Page 35 5. INSTALLATION EASYDRY® – FAN AND HEATER a. Use 5/16” x 1” hex bolts and 5/16” flanged hex nuts. 2. Install the LP vaporizer duct assembly / LP burner controls duct assembly to the bin by nesting the heater transition mount brackets inside the middle of the stiffeners. a.

  • Page 36: Equipment Inspection

    5. INSTALLATION EASYDRY® – FAN AND HEATER 5.6. Equipment Inspection After fan/heater delivery and/or assembly completion, before each use, and at the end of the season inspecting this equipment is mandatory. 1. Shut off, lockout, and tagout all power sources to the equipment before any inspection, service, or maintenance.

  • Page 37: Operation

    6. OPERATION EASYDRY® – FAN AND HEATER 6. Operation Before continuing, ensure you have completely read and understood this manual’s Safety section, in addition to the safety information in the section(s) below. 6.1. Operation Safety • Ensure appropriate safety accessories are installed. Selection and use of safety accessories for the specific installation is the responsibility of the customer.

  • Page 38: Pre-Start Check

    6. OPERATION EASYDRY® – FAN AND HEATER Proper combustion requires an ideal fuel-to-air ratio. As static pressure under the drying floor increases the airflow encounters resistance and is diminished. As airflow decreases, the amount of fuel being delivered to the burner should be decreased accordingly.

  • Page 39: Initial/Seasonal Equipment Check

    6. OPERATION EASYDRY® – FAN AND HEATER a. Make certain the transition is free of debris and holes. 4. Make certain the thermostat and/or other controls are in place and in working order. Note Occasionally a high limit switch will trip due to vibration or during shipment. Push the red RESET button if necessary.

  • Page 40: Multiple Fans

    6. OPERATION EASYDRY® – FAN AND HEATER Figure 11. Positive Pressure Airflow 6.5.2 Multiple Fans When using multiple fans in one bin, you must prevent reverse rotation of idle fans by making certain fans start-up simultaneously or by employing shutters that shield blades from moving air. Reverse rotation of idle fans pose concerns for the worker safety and fan/motor wear and tear.
  • Page 41 6. OPERATION EASYDRY® – FAN AND HEATER Figure 12. Emergency Stop Button Location STGI-0843 “PUSH” the emergency stop on the EMERGENC EMERGENCY EMERGENCY STOP PLC/HMI to completely from running STOP ST STOP and shut off power to any equipment controlled by the Ezee Dry Controls! After the safety concern is resolved, “twist to release”...

  • Page 42: Start-Up And Operation

    6. OPERATION EASYDRY® – FAN AND HEATER 6.7. Start-Up and Operation Important • During initial heater startup, qualified gas service personnel must perform a gas leak check to verify the gas tightness of the heater’s components and piping under normal operating conditions. •...

  • Page 43: Natural Gas Startup

    6. OPERATION EASYDRY® – FAN AND HEATER b. Very slowly open the liquid tap allowing just enough propane to vaporize naturally and build up a few pounds of pressure. c. Start the heater. This process may include some trial-and-error due to varying ambient temperature conditions. Be careful to allow only a small amount of liquid to vaporize.

  • Page 44: Drying Considerations

    6. OPERATION EASYDRY® – FAN AND HEATER 6.8. Drying Considerations Requirements Drying grain involves two primary components: 1. Heat — as measured in British Thermal Units (BTU) 2. Airflow — as measured in cubic feet per minute (CFM) Combustion Proper combustion requires an ideal fuel-to-air ratio: 1.

  • Page 45: Storage Instructions

    6. OPERATION EASYDRY® – FAN AND HEATER 6.9. Storage Instructions If the fan/heater is not to be used for an extended period of time: 1. Close the propane/natural gas valve at the tank. 2. Allow the heater unit to run until the flame burns out. This purges the gas out of the heater plumbing and supply lines.

  • Page 46: Maintenance

    7. MAINTENANCE EASYDRY® – FAN AND HEATER 7. Maintenance Before continuing, ensure you have completely read and understood this manual’s Safety section, in addition to the safety information in the section(s) below. 7.1. Maintenance Safety • Keep components in good condition. Follow the maintenance procedures. •...

  • Page 47: Visually Inspect The Fan And Heater

    7. MAINTENANCE EASYDRY® – FAN AND HEATER 7.3. Visually Inspect the Fan and Heater Check the following during a visual inspection: 1. Ensure all guards are in place and in good working order. 2. Examine the fan and heater for damage or unusual wear. Make sure the impeller is clean, undamaged, and rotates freely.

  • Page 48: Pressure Regulator Maintenance

    7. MAINTENANCE EASYDRY® – FAN AND HEATER 7.5. Pressure Regulator Maintenance This heater contains a (gas) pressure regulator on top of the unit. (See Section 10.2.4 – Burner/Pressure Assembly and LP Fuel Train on page 65.) Make certain the vent screen is clear at all times. Important •...

  • Page 49: Fuel Train And Supply Gas Leak Check

    7. MAINTENANCE EASYDRY® – FAN AND HEATER 7.9. Fuel Train and Supply Gas Leak Check After the plumbing is connected check all connections and pipes for leaks because pipe connections can loosen due to vibrations encountered during shipping. It may be necessary to reseal the pipes.

  • Page 50: Troubleshooting

    8. TROUBLESHOOTING EASYDRY® – FAN AND HEATER 8. Troubleshooting Shut down and lock out all power sources before diagnosing any of the causes or attempting any of the solutions below. In the following section, we have listed some causes and solutions to some of the problems you may encounter.
  • Page 51 8. TROUBLESHOOTING EASYDRY® – FAN AND HEATER Table 7 Fan Related Problems (continued) Cause Problem Solution the overload to match the FLA of the motor if they are not the same. Defective magnetic contactor. Replace the contactor. Defective start/stop switch. Replace switch.

  • Page 52: Heater

    8. TROUBLESHOOTING EASYDRY® – FAN AND HEATER 8.2. Heater 8.2.1 General Troubleshooting 1. Make certain the aeration system is covered with grain. 2. Examine the following figure. Move the toggle switch to the ON position. 3. After a 15 second delay (pre-purge period), the yellow LED light on the solenoid should come on, the solenoid valve clicks open and the ignitor inside the burner should start to spark.

  • Page 53: Heater Diagnostic

    8. TROUBLESHOOTING EASYDRY® – FAN AND HEATER Note This is done by removing the high limit switch circular cover located on the heater housing just above the heater (location shown on Section 10.2.1 – LP Burner Controls Duct Assembly and Vaporizer Duct Assembly on page 61).

  • Page 54: Symptoms/Causes/Solutions

    8. TROUBLESHOOTING EASYDRY® – FAN AND HEATER 8.2.3 Symptoms/Causes/Solutions Never check for a spark without first shutting off the fuel supply and purging all fuel from the system. Purge the fuel system by shutting off the fuel supply, starting the fan, and cycling the burner ignition sequence 2 to 3 times.
  • Page 55 8. TROUBLESHOOTING EASYDRY® – FAN AND HEATER Table 8 Symptoms, Causes and Solutions (continued) Symptoms Check... Possible Cause Solution Flame tripping high Gas pressure Reduce gas pressure limit Vaporizer tripping Vaporizer location Adjust vaporizer away from flame; high limit and gas pressure reduce gas pressure Igniter gap Incorrect gap...

  • Page 56: Fenwal-Related Issues

    8. TROUBLESHOOTING EASYDRY® – FAN AND HEATER Table 8 Symptoms, Causes and Solutions (continued) Symptoms Check... Possible Cause Solution Check voltage with voltmeter; check Low amps and amps with clamp-on ammeter. Amps/voltage voltage Check with power utility. Fan does not come Faulty starter up to speed in 10 Replace starter capacitor...
  • Page 57 8. TROUBLESHOOTING EASYDRY® – FAN AND HEATER Valve Malfunction Check the 1 amp fuse. If the fuse continues to blow, replace at least one of the solenoid valves (or its coil). If the valve will not open even though there is a spark during the ignition trial, check the valve for an open coil or broken wire.
  • Page 58 8. TROUBLESHOOTING EASYDRY® – FAN AND HEATER Fenwal Troubleshooting Table 9. Troubleshooting Guide Symptom Recommended Actions Miswired No 120 VAC at L1 Control does not start Fuse or circuit breaker fault Faulty control, check LED for fault codes Miswired Faulty thermostat, no voltage at terminal L1 Thermostat on —...

  • Page 59: Specifications

    9. SPECIFICATIONS EASYDRY® – FAN AND HEATER 9. Specifications 9.1. Fan/Heater Model Numbers Key The following tables provide a fan/heater model number description and can be used to decipher the model number of this fan/heater. For example, using the model numbering system shown, the model number for a natural gas EasyDry® Fan and Heater with a 30 HP, 230 VAC, 3–phase blower motor would be N-EZD30NG23 N-EZD Category...

  • Page 60: Appendix

    10. APPENDIX EASYDRY® – FAN AND HEATER 10. Appendix 10.1. Control Components Identification Figure 13. Control Components Diagram (drawing not to scale) TRANSPORT 2 GRAIN TEMPERATURE TOP FILL PROBES (4 PROBES) SWITCH STORAGE PLENUM TEMPERATURE WET BIN SENSOR EMPTY SENSOR TRANSPORT 1 PLENUM (optional)

  • Page 61: Parts Identification

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.2. Parts Identification 10.2.1 LP Burner Controls Duct Assembly and Vaporizer Duct Assembly Figure 14. LP Burner Controls Duct Assembly and Vaporizer Duct Assembly — Controls Axonometric View TRANSITION FUEL HIGH LIMIT KIT VAPORIZER high limit switch ASSEMBLY...
  • Page 62 10. APPENDIX EASYDRY® – FAN AND HEATER Figure 15. LP Burner Controls Duct Assembly and Vaporizer Duct Assembly — Access Door Axonometric View STGI-0826 VAPORIZER DUCT ASSEMBLY TRANSITION MOUNT BRACKET 006843 SERVICE PANEL 006840 TRANSITION MOUNT BRACKET 006843 BURNER CONTROLS DUCT ASSEMBLY (BURNER) ACCESS DOOR...

  • Page 63: Lp Fuel Tank Supply Assembly

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.2.2 LP Fuel Tank Supply Assembly Note In the following figures A connects with A, and B connects with B. Figure 16. LP Fuel Tank Supply Assembly STGI-0801 1/2” SOLENOID VALVE WITH DIN CONNECTOR N-084673 [R] 1/2”...

  • Page 64: Lp Fuel Vaporizer Assembly

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.2.3 LP Fuel Vaporizer Assembly Figure 17. LP Fuel Vaporizer Assembly STGI-0825 5-RING VAPORIZER COIL N-009576 VAPOR LIMIT BOX, 24 & 28 HEATER N-040810 3/4” (150 lb) 160° HI-LIMIT SWITCH PIPE UNION N-040673 N-040649 250051 R6...

  • Page 65: Burner/Pressure Assembly And Lp Fuel Train

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.2.4 Burner/Pressure Assembly and LP Fuel Train Figure 18. Burner/Pressure Assembly and LP Fuel Train BURNER END PLATE 1/4” PIPE SS METAL EZEE DRY BURNER (U OPENNING) COUPLING SPARK PLUG CAP BURNER ASSEMBLY END PLATE N-009755 150LB 304...

  • Page 66: Vp (Vapor Propane) Fuel Train

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.2.5 VP (Vapor Propane) Fuel Train Figure 19. VP Fuel Train ORIFICE PLUG INSIDE RELIEF VALVE HI/LO SOLENOID VALVE ORIFICE PIPE HOLDER N-084688 PRESSURE GAUGE SOLENOID VALVE RELIEF VALVE SOLENOID VALVE REGULATOR 1/2” X 1584VN REGO N-F048404 Y-STRAINER...

  • Page 67: Ng (Natural Gas) Fuel Train

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.2.6 NG (Natural Gas) Fuel Train Figure 20. NG Fuel Train ORIFICE ORIFICE PIPE HOLDER PLUG N-084688 INSIDE 1” HI/LO SOLENOID VALVE SOLENOID VALVE SOLENOID VALVE RELIEF VALVE 1/4” PRESSURE GAUGE 0-15 PSI FUEL REGULATOR FUEL...

  • Page 68: Control Box Assembly

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.2.7 Control Box Assembly Figure 21. Control Box Assembly TRANSITION HIGH LIMIT KIT N-F048410 high limit switch manual reset button located underneath circular cover CABLE EZEE DRY HEATER CONTROL BOX N-084768 FENWAL CONTROL BOARD WAGO TERMINAL...

  • Page 69: Expanded Part Descriptions

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.3. Expanded Part Descriptions Table 11. Heater Control Box — Select Components Type Description Part Part # AVC-3 A 3.0 amp fast-acting fuse is mounted on the front of the control housing Bussmann 3 A / to protect the heater’s electrical components.
  • Page 70 10. APPENDIX EASYDRY® – FAN AND HEATER Table 12. LP Fuel Tank Supply — Select Components Type Description Part Part # Fuel shutoff Used to manually turn ON of OFF the fuel supply. N-044228 ball valve Traps contaminants coming from the supply tank or supply line. Remove Y-strainer the plug and screen periodically to clean out.
  • Page 71 10. APPENDIX EASYDRY® – FAN AND HEATER Table 13. Natural Gas Burner/Pressure Assembly — Select Components Type Description Part Part # Dual valve system — primary valve controls main ON/OFF of fuel to the Primary burner. It opens during the ignition sequence and remains open during solenoid 7712213 operation.
  • Page 72 10. APPENDIX EASYDRY® – FAN AND HEATER Table 14. Burner Assembly — Select Components Type Description Part Part # Burner Mechanism where fuel is mixed with air and ignited. N-606702 Stainless Steel assembly Provides a spark during the 10–second trial for ignition to the air-gas Auburn E5–I-31–...

  • Page 73: Parts List

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.4. Parts List 10.4.1 EasyDry® Fan Heater LP Example Assembly EASYDRY BIN STIFFENER LINE (sold with the EasyDry Bin) Reference Quantity Description Part Number Number 006530 AIR DUCT HOOD ASSEMBLY 36” (914 mm) AIR DUCT SPACER ASSEMBLY 008421 varries per 44”...

  • Page 74: Easydry® Fan/Heater - 20 Hp Blower And Frame Assembly (007248)

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.4.2 EasyDry® Fan/Heater — 20 HP Blower and Frame Assembly (007248) Right Side View 43 44 53 STGI-0855 Left Side View STGI-0856 Quantity Description Reference Number Part Number 5/16”-18 x 1” Hex Bolt, Grade 5 N-003046 N-003057 3/8”...
  • Page 75 10. APPENDIX EASYDRY® – FAN AND HEATER Quantity Description Reference Number Part Number 1/4” X 1 1/2” Roll Pin N-003217 5/16” X 1 1/4” bin bolt with plastic seal washer N-003360 3/8” Flanged Hex Nut N-003382 Ezee Dry Fan / Motor Mount Angle RH N–006503 Ezee Dry Fan / Motor Mount Angle LH N–006504...

  • Page 76: Easydry® Fan/Heater -30 Hp Blower And Frame Assembly (006863)

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.4.3 EasyDry® Fan/Heater –30 HP Blower and Frame Assembly (006863) Right Side View STGI-0861 Left Side View STGI-0862 250051 R6...
  • Page 77 10. APPENDIX EASYDRY® – FAN AND HEATER Quantity Description Reference Number Part Number DRIER PACKAGE BLOWER WITH SHAFT AND BEARING; A30-27H 078522 EasyDry® FAN / HEATER / DUCT MOUNT ANGLE, RIGHT HAND N–006819 EasyDry® FAN / MOTOR MOUNT ANGLE, RIGHT HAND N–006503 N–006504 EasyDry®...

  • Page 78: Hp Easydry® Lp Burner Controls Duct Assembly (006864) - External View

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.4.4 30 HP EasyDry® LP Burner Controls Duct Assembly (006864) — External View STGI-1123 250051 R6...

  • Page 79: Hp And 15 Hp Easydry® Burner Assembly (N-009757) And Lp Vapor Fuel Train (No Assembly Number)

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.4.5 30 HP and 15 HP EasyDry® Burner Assembly (N-009757) and LP Vapor Fuel Train (No Assembly Number) STGI-1122 7, 56 Reference Quantity Description Part Number Number Ezee Dry Heater Box Transition Assembly N–006836 Ezee Dry BURNER ASSEMBLY N-009757...
  • Page 80 10. APPENDIX EASYDRY® – FAN AND HEATER Reference Quantity Description Part Number Number N-1-215568 Jiffy Clip 3/8" Conduit Aluminum Flex 3/8" N-2203001 Connector Street 3/8 Flex Set Screw C1 N-2206181 Spark Plug Boot Street #SPP10 N-045893 5/16" x 1" Bolt Hex Head Cap Screw ZP N–018916 Hex Nut Flanged .313 ZP 028002...

  • Page 81: Hp Easydry® Heater Box Transition Assembly (006836)

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.4.6 30 HP EasyDry® Heater Box Transition Assembly (006836) Quantity Description Reference Number Part Number EasyDry® HEATER BOX TRANSITION FRONT N–006832 EasyDry® HEATER BOX TRANSITION BACK N–006833 EasyDry® HEATER BOX TRANSITION SIDE - RIGHT HAND N–006834 EasyDry®...

  • Page 82: Burner Assembly (N-009757)

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.4.7 Burner Assembly (N–009757) Detail A 9 15/16 ʺ 4,14 STGI-1121 Reference Quantity Description Part Number Number N-606701 DSH2 Burner Tube Threaded Pipe Red Bell 1-1/2" x 3/4" N-084742 N-7712641 Pipe Cap 1/2" Black 150lb Cap Screw 1/4-20 X 2-1/2 Grade 5 HEX ZN N-043208 N-003160...

  • Page 83: Easydry® Lp Vaporizer Duct Assembly (006865)

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.4.8 EasyDry® LP Vaporizer Duct Assembly (006865) 25, 26 4, 5, 6 STGI-0798 Reference Quantity Description Part Number Number Ezee Dry Duct Transition Assembly 30hp 006842 N-040908 U-BOLT 1/4-20X1-1/8X2, #408 Transition High Limit Kit N-1-216722 N-040818 Vapor Limit Cvr 3/4"...
  • Page 84 10. APPENDIX EASYDRY® – FAN AND HEATER 4, 5, 6, 7 3, 12, 24 DETAIL A STGI-0799 250051 R6...

  • Page 85: 44" (1,118 Mm) Easydry® Air Duct Intermediate Assembly (008416)

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.4.9 44” (1,118 mm) EasyDry® Air Duct Intermediate Assembly (008416) Quantity Description Reference Number Part Number 44” EasyDry® AIR DUCT INTERMEDIATE END 008412 44” EasyDry® AIR DUCT INTERMEDIATE SIDE 008411 018916 5/16” X 1” HEX BOLT 5/16”...

  • Page 86: 36" (914 Mm) Easydry® Air Duct Spacer Assembly (008421)

    10. APPENDIX EASYDRY® – FAN AND HEATER 10.4.10 36” (914 mm) EasyDry® Air Duct Spacer Assembly (008421) Quantity Description Reference Number Part Number EasyDry® AIR DUCT SPACER SIDE 008419 EasyDry® AIR DUCT SPACER END 008420 EasyDry® AIR DUCT SPACER BACK 008422 028002 5/16”...
  • Page 87 10. APPENDIX EASYDRY® – FAN AND HEATER Quantity Description Reference Number Part Number EasyDry® AIR DUCT HOOD SIDE, RIGHT HAND 006526 EasyDry® AIR DUCT HOOD SIDE, LEFT HAND 006527 EasyDry® AIR DUCT HOOD BAND, RIGHT HAND 006528 EasyDry® AIR DUCT HOOD BAND, LEFT HAND 006529 EasyDry®...
  • Page 88 10. APPENDIX EASYDRY® – FAN AND HEATER Table 17. 30 HP Three Phase Motor Description Part Number N-085377–230–3–EZD 30 HP 3 PHASE MOTOR — 230 VOLT N-085377–460–3–EZD 30 HP 3 PHASE MOTOR — 460 VOLT N-085397–575-3-EZD 30 HP 3 PHASE MOTOR — 575 VOLT N-085255 30 HP 230 VOLT STARTER N-085451...
  • Page 89 10. APPENDIX EASYDRY® – FAN AND HEATER 10.5. Recommended Bolt Assembly When tightening bolts, tighten the nut on the bolt until a “snug-tightened condition” has been achieved. A “snug-tightened condition” is defined in Specification for Structural Joints Using ASTM A325 or A490 Bolts (Research Council on Structural Connections: June 2004), which states: “The snug-tightened condition is the tightness that is attained with a few impacts of an impact wrench or the full effort of an ironworker using an ordinary spud wrench to bring the connected plies into firm contact.”...
  • Page 90 11. LIMITED WARRANTY: WESTEEL GRAIN BIN EASYDRY® – FAN AND HEATER PRODUCTS 11. Limited Warranty: Westeel Grain Bin Products Westeel – Ag Growth International ("Westeel") warrants products that it has manufactured and/or that are branded with its name (the "goods") subject to the following terms and limitations, (the "warranty"): Duration of Warranty This warranty will run from the date of purchase from the dealer or distributor, authorized by Westeel.
  • Page 91 11. LIMITED WARRANTY: EASYDRY® – FAN AND HEATER WESTEEL GRAIN BIN PRODUCTS Procedure for Obtaining Service In the event of a warranty claim, the purchaser must complete any and all information required by Westeel in order to properly assess or investigate the claim. Westeel will not be responsible for the removal of any of the goods found to be defective, or transportation charges to and from Westeel's authorized dealer or distributor, or for installation of any replacement goods and/or parts furnished under the warranty.
  • Page 92 11. LIMITED WARRANTY: WESTEEL GRAIN BIN EASYDRY® – FAN AND HEATER PRODUCTS competent jurisdiction to be void or unenforceable, in whole or in part, such provision shall be deemed severable and will not affect or impair the legal validity of any other provision of the warranty.
  • Page 93 11. LIMITED WARRANTY: EASYDRY® – FAN AND HEATER WESTEEL GRAIN BIN PRODUCTS 250051 R6...
  • Page 94 450 Desautels Street P.O. Box 792 Winnipeg, Manitoba, R3C 2N5 Canada Phone: 1-888-937-8335 Website: www.aggrowth.com Email: customerservice.winnipeg@westeel.com ©Ag Growth International Inc. 2021 Printed in Canada If you have any comments or questions on this manual, or find an error, email us at comments@aggrowth.com. Please include the part number listed on the cover page in your message.
