PRODUCT DATA SHEET
IMZ121H - Lighting Module Dimmer
Dim your lights to create mood and ambience
Technical Specification
RF Frequency
Transmission Range
Loading Type
Loading Table
Input Power
Number of Cables
Support Local Panel
Indicator
Width
Height
Depth
Weight
Accessory
Operation Temperature
Relative Humidity
Standards
Environmental Characteristic IP20 indoor use only
Insert module dimmer is designed to operate
without neutral wire. It operates with different
loads, including Incandescent lamps, halogen
lamps, dimmable LED, other dimmable loadings.
This device is compatible with standard Z-Wave
gateway or devices for remote control
919.80 MHz (HK), 868.40 MHz (EU/CN)
Up to 40 m Indoor
Incandescent lamp ; Halogen lamp ; dimmable LED ;
other dimmable loadings
Incandescent Lamp
Halogen lamp
Dimmable LED
Other dimmable loadings : 20W(Min. Load) / 240W(Max. Load)
AC 230V ; 50Hz
2 wires (RED = LIVE; WHITE = LOAD)
Yes, both rocker switch or momentary switch
Green LED
48 mm
46 mm
18 mm
35 g
2-wire connector & 4 wire connector (For local panel)
0 ~ 40 ℃
5 ~ 95 %
EN 61058
Telephone: (852)3907-9216
Description
Supports any
Supports any
dimmable light
lighting
sources
switches
: 25W (Min. Load) / 300W (Max. Load)
: 20W(Min. Load) / 240W(Max. Load)
: 12W(Min. Load) / 120W(Max. Load)
Email:
kuju@tronico.com.hk
Invisible
http://www.tronico.com.hk/
Advertisement
Table of Contents
Summary of Contents for Tronico KUJU IMZ121H
- Page 1 18 mm Weight 35 g Accessory 2-wire connector & 4 wire connector (For local panel) 0 ~ 40 ℃ Operation Temperature Relative Humidity 5 ~ 95 % Standards EN 61058 Environmental Characteristic IP20 indoor use only Telephone: (852)3907-9216 Email: kuju@tronico.com.hk http://www.tronico.com.hk/...
- Page 2 Insert module dimmer is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The full test of the EU declaration of conformity is available at the following internet address: www.tronico.com.hk www.tronico.com.hk Tronico Technology Company Ltd. Office： Unit213,ICDevelopmentCenter,SciencePark, Shatin,HongKong Tel：(852)3907-9216...
