- Page 1 FASTpass® P1R/P1U Fast, reliable, and compact passport reader User’s Manual Version 1.0.0 2015/02/11...
- Page 2 2 (-) 3 (-) • Although you connect USB and Power cables to FASTpass® P1R/P1U and turn on the power switch, the device’s power is not on without PC power. 12V / 2.5A •...
-
Page 3: Driver Installation (Windows 7)
1. Driver Installation (Windows 7) 1. Driver Installation (Windows 7) • Step 1) For driver installation, run an installation program from the provided CD. – Program name: FASTpass_Setup_0.0.0.0.exe – Notice: version number in FASTpass_Setup_0.0.0.0 can be changed in distribution. - Page 4 1. Driver Installation (Windows 7) • Step 2) Click [Yes] button after the installation program runs.
- Page 5 1. Driver Installation (Windows 7) • Step 3) Click [Next] button.
- Page 6 1. Driver Installation (Windows 7) • Step 4) Click [Install] button. - Select API and SDK for installation...
- Page 7 1. Driver Installation (Windows 7) • Step 5) Select [Always trust software from “SMARTCORE Inc.”] and click [Install] after Windows Security screen appears.
- Page 8 1. Driver Installation (Windows 7) • Step 6) Wait till files required for installation are copied.
- Page 9 1. Driver Installation (Windows 7) • Step 7) Driver installation is completed with [Finish] button clicked...
-
Page 10: Device Connection
2. Device Connection 2. Device Connection • Step 1) Check the backside of FASTpass® P1R/P1U for device connection USB Extension Port USB port for PC connection Power Switch Power Port... - Page 11 2. Device Connection • Step 2) Connect power cable while power switch is off (clicked to the left side)
- Page 12 2. Device Connection • Step 3) Connect USB cable while power switch is off (clicked to the left side)
- Page 13 2. Device Connection • Step 4) Plug power cable in...
- Page 14 2. Device Connection • Step 5) Connect to USB cable to a USB port...
- Page 15 2. Device Connection • Step 6) Click power switch to ON (to the right side)
- Page 16 2. Device Connection • Step 7) Check if the state LED is red – If the state LED is green, it means that the reader is automatically connect to a passport reading program (it is not an issue of trouble shooting) After power connected : red After program connected : green...
- Page 17 3. Checking Driver Installation (Windows XP) 3. Checking Driver Installation (Windows 7) • Check at device manager for whether [Microsoft Usbccid Smartcard Reader (WUDF)] and [SMARTCORE FASTpass P1 Core] is in the list...
- Page 18 4. Checking Device Operation 4. Checking Device Operation • After installing device driver and an application program, you may check device operation After power connected : red After application program opened : green...
- Page 19 Caution Caution Any changes or modifications (including the antenna) made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
