Aqila Securehub User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Aqila Home
Security System,
Protects
your Family
Anytime
Anywhere
Smart Security Kit
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Securehub and is the answer not in the manual?

Questions and answers

Related Manuals for Aqila Securehub

Summary of Contents for Aqila Securehub

  • Page 1 Aqila Home Security System, Protects your Family Anytime Anywhere Smart Security Kit User Guide...
  • Page 2 Untuk versi bahasa Indonesia silahkan unduh pada website, www.getaqila.com/download...

  • Page 3: Table Of Contents

    Table of Contents Product List Feature Aqila Securehub™ Device LED Light Indicator QUICK START GUIDE Aqila Securehub™ Installation ACCESSORIES INCLUDED Motion Sensor Door/ Window Sensor SETTINGS Aqila Smart App Setting Add Device Quick Alarm Operation Electrical Facility Control Alarm Notification...

  • Page 5: Product List

    AQILA With a dual network (WIFI & GSM), Aqila Smart Home Security System was created to provide comfort and Home a sense of security, enable you to do real-time and direct monitoring on all security aspects of your home. Security Protects your house 24/7.

  • Page 6: Feature

    Smart Security PANDUAN PENGGUNA Features Wireless 105dB Siren Technology, DIY Installation 24 Hours Entry/ Exit Delay Protection Dual Network FHSS, Frequency Wi-Fi + GSM Hopping Spread Spectrum Instant 3 Groups of SMS, Notification 5 Groups of Phone Call 1000mA Battery Connects up to Backup 10 Remote Control...

  • Page 7: Aqila Securehub™ Device

    AQILA White LED: Arming (Aktif) / Disarming Securehub™ Red LED: Aqila Securehub™ Status Device Green LED: AC Power LED Yellow/ Red: GSM Signal Indicator Temper Switch SIM Card Slot Bracket Hole Loudspeaker Power Switch Adapter Interface Wired Accessories Connection Button Interface www.getaqila.com...

  • Page 8: Led Light Indicator

    Connection Button) Connection Button: Press once: Initiates sensors connections Press and hold for 5 seconds until one beep sounds: Start setting on Aqila Smart App Press 7 times: Clears all connected sensors Press 5 times: Restores the system to default settings.

  • Page 9: Quick Start Guide

    The SIM card that you purchased may not ask for a PIN number. However, if your SIM card required a pin number, please first deactivate the PINT on your mobile phone and then re-insert the SIM card in Aqila Securehub™. www.getaqila.com...
  • Page 10 Then alarm tone and Testing will immediately sound and the large LED light on the Aqila Securehub™ will flash red. Turn off the alarm by pressing the “Disarm” (image of an open padlock) on your remote control.
  • Page 11 “Away Arm” button (closed padlock) on your remote control. Press the connection button on the back of the motion sensor. Turn off the alarm by pressing the “Disarm” (image of an open padlock) on your remote control. Congratulations! Your AQILA Motion Sensor is working properly! www.getaqila.com...

  • Page 12: Motion Sensor

    Smart Security PANDUAN PENGGUNA MOTION SENSOR Feature Motion Sensor embedded with Infrared technology, designed with a modern, elegant design and can be easily installed. This sensor adopts fuzzy logic technology, designed to detect human movement in the room. The small alarm inside will notify you whenever the battery level is low or there is an attempt to damage it by triggering a tamper alarm.
  • Page 13 Status Indicator LED flashes one time: Movement is detected. The LED flashes 5 times and the buzzer beeps 5 times : Sensor activated, tamper alarm activated or indicates low battery level. Replace the battery immediately if the battery level is low. Test Mode &...
  • Page 14 Smart Security PANDUAN PENGGUNA Warning Avoid installing the sensor close to places with high temperatures that frequently changed or places with strong airflow (ie. air conditioner, tube lights, ovens, refrigerator, etc.). Avoid areas which face directly to the window. Sensor’s performance can be affected by enviromental factors (such as direct sunlight, crowded place, passing cars, etc.).

  • Page 15: Door/ Window Sensor

    Transmitter Sensor Open/ Close Magnet Tamper Switch Battery Compartment Tamper Alarm: When someone attempts to damage or move the sensor, it will trigger the alarm. Then Aqila Securehub will immediately send an alarm notification to the home owner. Working Status:...
  • Page 16 Smart Security PANDUAN PENGGUNA Installation • Open the sensor case and insert the battery properly. • Sensor can be attached to doors or windows that can be opened and closed. Make sure door/ window surface are clean. • Place double-sided adhesive tape on the back of the transmitter and magnet sensor.

  • Page 17: Aqila Smart App Setting

    Aqila Smart App Download the App Settings Enter the keyword “Aqila Smart” in the App Store or Google Play. The Aqila system use Wi-Fi network: 2.4GHz (802.11 b/g/n). Supported operating system specifications: iOS: iOS 8 or later. Android: Android 4.0 or later.

  • Page 18: Add Device

    Smart Security PANDUAN PENGGUNA ADD DEVICE Connect Aqila Securehub™ to the App with “Smart Mode” Tap “Add Device” or “+”. Then choose “Aquila Securehub ”. Turn on the Aqila Securehub and confirm that the big red LED light flashing quickly.
  • Page 19 Connect Aqila Securehub™ to the application with “AP Mode (Access Point)” • If the connection via Smart Mode is not successful, the alternative option will appear. Tap “Switch Pairing Mode” • Press and hold the Connection button for 5 seconds until the red LED light flashes SLOWLY.

  • Page 20: Quick Alarm Operation

    Zona Normal akan aktif, sedangkan sensor yang diset pada Zona Rumah akan tidak aktif. are set in Normal Zone will be Away Arm Mode mengaktifkan seluruh sensor alarm. Aqila Securehub™ akan mengirimkan Notifikasi/ S ms/Telp ket ika sensor terpicu. active, sensors which are set in Disarm the Stay Zone will be inactive.

  • Page 21: Electrical Facility Control

    Nyalakan sirine pada keadaan darurat The alarm system monitors activity in your home. When the sensor is triggered, it will send notifications to Aqila Smart App, SMS or a phone call. All events can be viewed by choosing “Message Center” tab on the Aqila Smart App home screen.
  • Page 22 PENGGUNA AQILA When the alarm is triggered, the system will perform a phone call to preset phone number. SECUREHUB™ OPERATION The user can receive the phone call, listen and monitor THROUGH the situation at home and also remotely control the...
  • Page 23 “Sensor” menu there is a list of all sensors and remote controls that are connected to Aqila Securehub™, you can turn on/ off the sensor, add/ remove sensors, set zone names, as well as view battery level of each sensor. It is highly recommended to set a name zone to identify the precise location whenever alarm occurred.

  • Page 24: Add/ Delete Sensor

    The sensors can be removed individually via Aqila Smart App. To remove the entire sensor connection, you can do this via Aqila Securehub™ by pressing the Connection button 7 times until you hear a beep, then all sensors and wireless accessories that connected to Aqila Securehub™...

  • Page 25: Device Settings

    Aqila Securehub™ To set up Aqila Securehub™. Go to Aqila Smart App and select “Settings” Setting Google Home Password Setting Set up a password to control the alarm system via Google Home. Note: Aqila connection to Google Home still in development.
  • Page 26 Smart Security PANDUAN PENGGUNA Alarm Monitoring Center/ Central Monitoring Station Setup Set User ID for CMS (Central Monitoring System) / Alarm Monitoring Center User ID is the CMS account number, which must consist of 4-digit number between 0 and 9. Note: The CMS feature is still under development.
  • Page 27 Aqila Securehub™ will beep once every second. However, if the delay time is more than 10 seconds, the Aqila Securehub™ panel will beep every 2 seconds with an increasing tempo in the last 10 seconds as a notification for you to entering or leaving the house as soon as possible.
  • Page 28 Door/ window status can be seen on sensor section in Aqila Smart App. Local Siren When the siren is turned on, the Aqila Securehub™ panel will immediately activate the alarm. Sim Card Balance Currently, we are still improving this feature, to check the sim card balance, take out the sim card and put it another your mobile phone.

  • Page 29: Other App Settings

    Tambah / Hapus / Ubah Ruangan Home Location Setting SMART Select “Smart” to create automation/ smart scenario of devices that are connected to the Aqila Smart App. There are 2 types of functions on the “Smart” feature: Scene/Tap-to Run This feature manages multiple devices at once with just a click of a button.
  • Page 30 Services) including the alarm. Aqila Securehub™ : System Disarmed Aqila Securehub™ in Away Arm Mode ! From the Setting feature, users can adjust the sound and notification settings that will be accepted by the App.

  • Page 31: Connecting Wired Sensor

    Connecting wired Sensor & Electrical Facilities Interface Cable 1 Interface Cable 2 Grounding General Port Normal Open (NO) Normal Closed (NC) Power Output for wired sensors/ accessories Grounding Wired Sensors/ Accessories: It supports 2 groups of wired sensor/accessories. Please choose the wired sensor type after connected. Connect Wired Sensors to Wired Zone 1 Connect N.C.
  • Page 32 To operate alarm system via SMS, send SMS message to phone number of your Aqila Securehub™ with text format below: Note! Code 1234 below is the standard SMS access code, if you change the code, use your new code.

  • Page 33: Aqila Securehub™ Specification

    Aqila Securehub™ Product Name: Aqila Securehub™ Specifications (Wi-Fi/GSM) Control Panel Power Supply: Input: AC110~240V/50~60Hz Output: DC 12V/1000mA GSM Working Frequency: 2G: GSM 850/900/1800/1900; Standby Current: 200 mA without power source 150 mA when power is Alarm Maximum Current: ≥350mA Internal Battery Backup: Lithium Battery: 3.7V/900mAh...
  • Page 34 Smart Security PANDUAN PENGGUNA Door/ Window Power Supply: DC 1.5V Sensor Specifications (x1 AA 1.5V Lr6 Battery) Standby Current: ≤20uA Transmission Current: ≤70mA Wireless Transmission ≤80 m Distance: (in Open Area) Wireless RF Frequency: 433 MHz FHSS Frequency Hopping Temperature/ Humidity: C-55 C/≤80% (No Condensation)
  • Page 35 Remote Control Power Supply: DC 3V (2pcs CR 2032 Specifications button cell battery) Transmission Current: ≤25mA Transmission Distance: ≤80 m (in Open Area) Transmission Frequency: 433 MHz FHSS Frequency Hopping Product Material: ABS plastic Working Temperature: C-55 Humidity: Up to 80% (non-condensing) Dimensions (L x W x H): 35 x 70 x 12mm...

  • Page 36: Q&A

    Do I have to pay for The Aqila Smart App is available for free, but there are the application? several additional paid features that can be selected as needed, such as the smart camera cloud storage feature.
  • Page 37 The SIM card must be activated, not use a PIN and make sure there is sufficient credit balance. After the power goes out and the internet is cut off, Aqila What will happen when the Home Security System will continue to work because...
  • Page 38 Why doesn’t the motion • Please make sure the Aqila Securehub™ panel is in sensor detect motion? Arm mode, not in stay Arm mode or Disarm mode. • Make sure the motion sensor LED lights up when you walk in the detection area.
  • Page 39 www.getaqila.com...
  • Page 40 www.getaqila.com...
