46SVB

Steam/Vacuum Board

46SVBA

46SVBA-120 & 46SVBA-230 included

Steam/Vacuum Board

w/Up-Air Finishing

INSTRUCTION HANDBOOK

MADE IN THE USA

Table of Contents

Need help?

Do you have a question about the 46SVB and is the answer not in the manual?

Questions and answers

Summary of Contents for Forenta 46SVB

Page 1 46SVB Steam/Vacuum Board & 46SVBA 46SVBA-120 & 46SVBA-230 included Steam/Vacuum Board w/Up-Air Finishing INSTRUCTION HANDBOOK MADE IN THE USA...
Page 2 Forenta recommends that purchasers of this equipment review ANSI Z8.1 and any other applicable standards since some of these standards place specific requirements responsibilities owner/user this equipment. If assistance is needed in identifying and/or obtaining standards, contact the Forenta service department. Phone (423)586-5370.
Page 3: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS………………………………………………………………………………….. 2 WARRANTY………………………………………………………………………………….…………..3 SPECIFICATIONS………………………………………………………………………………….…..… 4 SAFETY SUMMARY……………………………………………………………………………………... 5 INSTALLATION INSTRUCTIONS……………………………………………………………………….6-9 MAINTENANCE…..........................10 PARTS ILLUTRATION…………………………………………………………………………………..11-18 PADDING LIST…………………………………………………………………………………………...19 PART NO. 22768 DATE: 11-2007...
Page 4: Warranty
Forenta does not warranty service labor in the replacement of parts covered under this warranty. In certain applications, Forenta, at its discretion, recognizing that a defect is present and at an agreed to cost prior to service labor being performed, will reimburse a distributor or local service company to repair the defect or replace the defective part.
Page 5: Specifications
SPECIFICATIONS Models 46SVB, 46SVBA, 46SVBA-120 & 46SVBA-230 46SVBA 46SVB Electrical connections Voltage: Optional Iron Attachement: Voltage 120V 1PH 50/60Hz 1000watts Ironing Board Surface Approx. Consumptiom/hour Voltage 230V 1PH 50/60Hz 1000watts Approx. Consumptiom/hour Steam Inlet 1/2" 1/2" 1/2" Steam Outlet 1/2"...
Page 6: Safety Summary
Should situations arise that are not covered in this manual, it is advisable to contact a Forenta Factory Service Technician. 6. Under no circumstance should repair or adjustments of energized equipment be attempted alone. The immediate presence of someone capable of rendering aid is required 7.
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS Uncrating and locating the press Uncrate the press and check for shipping damage. If any is found, it should be reported to the transportation company and a claim filed by you. Remove the press from its shipping base and move it to its installation location. On the 46SVBA model, the up-air blower assembly can be unbolted from the finishing board frame and set aside until the press is moved to its final location.
Page 8 WITH THE REQUIREMENTS OF THE NATIONAL ELECTRICAL CODE AND LOCAL CODES AND ORDINANCES. NOTICE IF AT ANY TIME YOU HAVE QUESTIONS OR FIND SOMETHING THAT IS NOT OPERATING PROPERLY, YOU MAY CONTACT A FORENTA FACTORY SERVICE TECHNICIAN: PHONE (423)586-5370, FAX (423)586-3470. Manual Motor Starter Blower On/Off Switch Located in Disconnect Switch Box.
Page 9 INSTALLATION INSTRUCTIONS Steam Supply Connect the steam inlet to a steam source with a minimum pressure of 75 p.s.i. and a maximum pressure of 85 p.s.i. The pipe size of the connection should be ½” NPT. The connection shall include a cutoff valve and pipe union. Condensate Return The condensate connection requires a steam trap.
Page 10 INSTALLATION INSTRUCTIONS NOTICE FAILURE TO FOLLOW THESE INSTRUCTIONS AND THE RECOMMENDED STEAM PIPING ILLUSTRATION, MAY RESULT IN LESS THAN OPTIMUM QUALITY AND PRODUCTION AS WELL AS UNECESSARY STEAM LOSS. WARNING PRECAUTIONS MUST BE TAKEN WHEN WORKING WITH STEAM SYSTEMS. THE STEAM SHOULD BE TURNED OFF, THE SYSTEM DRAINED OF STEAM, HOT WATER AND PRESSURE, AND THE STEAM PIPING COOL BEFORE MAKING ANY REPAIRS.
Page 11: Maintenance
MAINTENANCE CAUTION THIS IS A RECOMMENDED PREVENTIVE MAINTENANCE SCHEDULE. FOR A SAFE AND EXTENDED SERVICE LIFE, A MAINTENANCE SCHEDULE MUST BE ESTABLISHED. EXPERIENCE MAY MODIFY THE FREQUENCY OF INSPECTIONS OR ADD ADDITIONAL INSPECTIONS. Weekly Check condition of padding. Replace when worn. Clean lint, dust and debris from around the machine.
Page 12: Parts Illutration
However, if the parts are not available from your distributor or are not listed in the following pages, you may order them directly from Forenta by phone, fax, mail or e-mail. When ordering parts, always provide the following information: •...
Page 13 Steam valve 25935 Clevis 15767-39 Bushing 25703-9 Clevis pin 17090-5 ½”locking collar 18160 ¼”-20 Threaded rod 33810 Catch rack cover 17090-7 ¾”locking collar Model 46SVBA displayed in this illustration. Parts will be similar for a 46SVB. Specify length when ordering-...
Page 14 PARTS ILLUSTRATIONS Up-Air Blower Assembly (Models 46SVBA, 46SVBA-120 & 46SVBA-230) Ref. No. Part No. Description No. Req. 22744 Switch enclosure (for 3Phase only) 22746 Manual motor starter(for 3Phase only) 22812 On/Off Switch (for Single phase only) 22745 Thread adapter 22743 Air intake filter 22742 3Phase blower 230v.
Page 15 PARTS ILLUSTRATIONS Valve Assemblies Buck Steam Valve Part No. 25649 25649 Vacuum Valve Part No. 25650 VACUUM VALVE 25650...
Page 16 PARTS ILLUSTRATIONS Water Spray Attachment Kit Part No. K-566 ____________________________________________________________ Garment Hanger Attachment Kit Part No. K-569...
Page 17 PARTS ILLUSTRATIONS Iron Attachments Steam/Electric Iron Attachment Kit Part No. K-564 For 120volt K-565 For 230volt __________________________________________________________________ All Steam Iron Attachment Kit Part No. K-563 Supply on Iron Return(valve) on Iron...
Page 18 PARTS ILLUSTRATIONS Sleeve Board Attachment Sleeve Board Attachment Kit Part No. K-570...
Page 19 IRON ATTACHMENT ELECTRICAL WIRING DIAGRAM Forenta Iron Wiring for 100/120V. Iron _______________________________________________________________________________ Forenta Iron Wiring for 220/240V. Iron ________________________________________________________________________________ Solenoid Valve Part No. 25903...
Page 20: Padding List
PADDING LIST Model 46SVB Part No. Description Quantity 33811 Iron Board Padding 33810 Catch Rack Cover 22762 Small Pleater Pad 22763 Large Pleater Pad 25839 Sleeve Board Cotton Pad 17411 Sleeve Board Cover Model 46SVBA, 46SVBA-120 & 46SVBA-230 Part No.
