- Page 2 How to install Tooway A guide to installing Tooway services...
- Page 3 INDEX 1. Equipment required 2. Identifying geographical position for pointing 3. Assembly Kit 4. Preparation for pointing 5. Pointing (phase I) 6. Pointing (phase II) 7. Activating the service Cost-effective two- way satellite service...
-
Page 4: Equipment Required
1. Equipment required • Notebook or laptop with updated browser (Firefox , Chrome) • 66 mm mount If you already have a mount, make sure it can support the weight of the new kit too. Position the mount facing south. Ensure there are no obstacles in the line of sight. - Page 5 1. Equipment The Tooway Kit comprises: TRIA TRIA MOUNT Bracket Ground cable Fixing Plus the modem, power supply, devices dish and network cable .
- Page 6 2. Identifying geographical position for pointing To identify the spot configuration, go to http://finder.tooway-instal.com click on Coordinates.
- Page 7 The spot number (which you can see in the coloured area under the image of the satellite) • The elevation and geographical azimuth You should print a copy of the page for reference during installation. Remember to refer to the Broadsat technical support in order to have the correct parameters.
-
Page 8: Assembly Kit
3. Assembly kit You need the following tools: • Socket wrench set (8mm and 13mm) • Phillips screwdriver • Spanner of 8mm and 13mm Follow the instructions supplied with the kit for assembly. - Page 9 The fixing screw for the azimuth should only be tightened half way. Raise the dish to the correct position according to the pointing data identified on the site: http://finder.tooway-instal.com The values s hown apply to a dish positioned perpendicular to the ground.
- Page 10 4. Preparation for pointing Before connecting the modem, it is important to check that your computer is configured to obtain network settings automatically.
- Page 11 4. Preparation for pointing • connect the modem • connect the TX output of the Tria with the input at the back of the modem • plug the modem into the power supply and switch it on • connect the network cable to your computer...
- Page 12 4. Preparation for pointing • open your browser and type in: http://192.168.100.1 • check that the single light is still yellow and the other two are green. Eg in this picture the modem has a yellow light, the BUC receiver has a green light and the cabling a red one.
- Page 13 4. Preparation for pointing • open your browser and type in : http://192.168.100.1/install • choose the beam color you have received in the activation email from Broadsat...
- Page 14 4. Preparation for pointing • Stay on the same page and proceed to Pointing. Make sure you don’t change the page during the pointing phase. When pointing is complete, a NEXT button will appear.
- Page 15 5. Pointing (phase I) Set up the elevation acquired on page 7, using the back of the support as a reference, indicated by the red mark in the picture opposite. In the example the elevation is set at approximately 38 degrees Position your hands at 3 and 9 o'clock on the disc and turn it either right or left using the bracket as a pivot.
- Page 16 5. Pointing (phase I) When the correct signal is identified, you need to attach the mount permanently, while keeping it at the same elevation. When the dish is fixed, it is possible to adjust the elevation, by gently pushing the dish upwards. Tighten the bolts in the order shown in the picture below:...
- Page 17 5. Pointing (phase 2) In the second pointing phase (fine pointing), you must adjust the geographical azimuth and elevation using only a spanner. As you approach the maximum satellite signal, you will hear the tone more and more frequently. It is important to pass through the maximum signal several times in order to locate the best possible pointing position.
- Page 18 5. Pointing (phase 2) As soon as you obtain the maximum value of the azimuth pointing, secure the dish.
- Page 19 5. Pointing (phase 2) Repeat the procedure for the elevation...
- Page 20 5. Pointing (phase 2) The symbol for operation successfully completed will appear in the same browser window (see page 12). Current Rx must be higher than 10db. Peak Rx must differ from Current Rx by a max of 0.4db. IMPORTANT: depending on the oscillation of the power signal, the green light may switch on and off. In any case, when 10 db is reached, proceed with the activation by clicking on the right arrow.
- Page 21 5. Activation After clicking NEXT, it is possible to check the status of synchronizing the modem. If the pointing is completed, the 4 lights will turn green and then within the next 10 minutes, the Tooway status will become online.
- Page 22 5. Activation Check on the computer that the 4 LEDs are green. Make sure that the signal is at least 10db. Otherwise adjust the pointing.
- Page 23 If the page does not automatically open, type in the browser: http://selfact.skylogic.com or http://95.210.254.219 You can request the activation code either over the telephone on +39 050 3870888 or by email at tech.support@broadsat.com Just type in the code, and the terminal is ready to start.
- Page 24 CONTACTS Email sales.support@broadsat.com +39 050 3870888 +39 050 3870808 WWW.BROADSAT.COM...
