Armera BW.223 Installation Instructions

Bath waste with twist handle plug operation

Please Note

Please follow all instructions carefully. Failure to do so could invalidate your guarantee. As with

the installation of any water bearing product, you must make sure that any laws prevalent to your

area are followed. Such laws may include Local & National Water Supply Authority Regulations

or Byelaws and Building and Plumbing Regulations. We recommend that a qualified registered

plumber is used to install your product. Please ensure that when fitted, the product is easily

accessed for service and maintenance requirements. Armera cannot be held liable for costs

associated with accessing the product after it is fitted.

Should you need any assistance, please e-mail us at info@armera.co.uk or call 01225 251 204.

We recommend only cleaning your product with a soft damp cloth. Please do not use any other

cleaning products as they may damage the high quality finish of this product.

This Armera product is guaranteed against manufacturing defects. The cover period is from date

of supply to the Armea customer and will last for 2 years for parts and labour. The parts guarantee

can be extended to 15 years by registering your guarantee. To register your guarantee and review

all guarantee conditions, please go to www.armera.co.uk

Installation Instructions

BW.223 Bath waste with twist handle plug operation

Table of Contents

Do you have a question about the BW.223 and is the answer not in the manual?

Page 1 Contact Us Should you need any assistance, please e-mail us at info@armera.co.uk or call 01225 251 204. Caring for your Armera product We recommend only cleaning your product with a soft damp cloth. Please do not use any other cleaning products as they may damage the high quality finish of this product.
Page 2 Overflow body Installation Rubber washer 1. Remove the indice from the overflow cowling and use the allen key provided to loosen Splined stem the grub screw. Bath overflow hole 2. Remove the overflow cowling. 3. Unscrew the fixing ring from the overflow body and remove the chrome collar. Chrome collar 4.
