Evac 910 Technical Information

Wall toilet
Hide thumbs

Advertisement

Quick Links

Download this manual
EVAC 910 WALL TOILET
TECHNICAL INFORMATION

Advertisement

loading
Need help?

Need help?

Do you have a question about the 910 and is the answer not in the manual?

Questions and answers

Summary of Contents for Evac 910

  • Page 1 EVAC 910 WALL TOILET TECHNICAL INFORMATION...
  • Page 2 Shipping volume: 0.168m P/N 6543419 Evac 910, wall model, Mosaik: Net weight: 17.7 kg Shipping weight: 19.7 kg Shipping volume: 0.168m EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 3 Materials Cover: ABS, white Button: PBT, white Bottom plate: POM, natural Connections Hose nipple Ø4 Shipping data Net weight: 0.2kg EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 4 01 white 6545828 Floor model USPH, Trevi 01 white 01 white 6545829 Floor model USPH, Open front 01 white 01 white EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 5 Bowl, seat and cover are available in white and in standard colours. Standard colours are shown in the standard colour palette. ! NOTE: Evac 910 vacuum toilets with the Mosaik, Trevi or Open front seats and covers are available only in white colour.

  • Page 6: Installation

    * The vacuum breaker air inlet must be located at a minimum of 150mm (6”) above the overflow point of the toilet. EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 7 Guiding nut 2 pcs Edge strip 1 pc Mounting instruction 1 pc Straight connection hose 1 pc Hose clamp 2 pcs EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 8 • Connect the water connection hose (A) to the shut-off valve/vacuum breaker assembly. • Install the pneumatic push button (See document 002002-3). EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 9 The opening angle must not exceed 110°. Cover Seat Hinge, right (yellow mark) Hinge, left (blue mark) EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 10 Therefore, when you clean the bowl and flush cleaner away, make sure that the seat and the cover are in an upright position. EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 11 Plastic hose to the push button Make sure, that the plastic hose does not get loose from the control mechanism. Control mechanism EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 12 EVAC. Floor models Discharge pipe Optional pneumatic push button kit Install the protecting pipe under the discharge pipe. EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.

  • Page 13: Operation And Maintenance

    • Close the water supply valve. • Run a flush cycle by pressing the push button. • Close the toilet seat cover. EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 14 The water valve closes and lets a certain level of water at the bottom in the bowl. After the flushing cycle has stopped the push button and the system will be ready for the next flush. EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 15 ! NOTE: If vacuum is too low or absent the function is delayed. The control valve (1) stays open until the chamber (14) is subject to vacuum. EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 16 Less restriction shortens the time Water valve opening time Jet 6 Normal bowl water level White jet Low bowl water level Blue jet EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 17 The water valve closes and lets the certain level of water at the bottom in the bowl. Maintenance See document 002034-6 for scheduled maintenance. EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.

  • Page 18: Maintenance

    Mini-check 6544996 diaphragm Stainless steel toilet: valve 5433471 Flushing ring Push button ! NOTE: Use only genuine Evac spare parts. EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.

  • Page 19: Troubleshooting

    Seal ( not in USPH models ) Control mechanism Vacuum breaker Vacuum Water supply hose hose Relief valve Flushing ring Water valve Mini-check valve Discharge valve EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 20 (only in the USPH models). 8. Remove the back plate. Water valve Screws*** Connection nipples Discharge piping Rubber bend EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 21 (see fig.3). 2. Press lightly the closing mechanisms and remove the Rubber sleeve rubber sleeve with the brace (see fig.4). EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 22 ! NOTE: *When ordering: Toilet bowl - state type and standard colour Seat and cover - state type and standard colour EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 23 6543002 Discharge valve 6542997 Water valve 5481004 Hose, L=390 (only in part 6542982) 6542402 Hose clamp (only in part 6542982) EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 24 Rubber sleeve 6543134 Membrane 6547089 Closing mechanism 6542985 (sold only as a kit) Housing 6542989 Rubber diaphragm 6542990 Rubber sleeve EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 25 Valve washer + Jet 5774300 Bottom 3752211 O-ring 5774600 Cover 3790009 V-ring 5990740 Screw 5774150 Filter 6542826 6542998 Membrane Solenoid valve EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 26 Jet carrier complete 5778000 Jet carrier complete 5778700 Filter 5959902 Mini-check valve P/N 6546688 Spare part kit (Evac 910 model toilets, toilet with Autoflush unit, Stainless steel toilet, Squatting toilet) Description 5778600 Air filter 5778001 Jet carrier complete 5778000 Jet carrier complete...

  • Page 27: Hinge Kit

    SEAT AND COVER, PRESTIGE 6549843 Buffers (x6) for seat and cover Cover Seat 6547810 Hinge hub 6547810 6547809 Hinge hub HINGE KIT EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 28 ! NOTE: ”Seat and cover” sold as a single item. 2 x Hinge body 6542726 Hinge kit 2 x Nut EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 29 Buffer for seat (x4) 6547815 Buffer for cover (x2) Cover Seat 6547813 Hinge, right 6547812 Hinge, left 6547811 HINGE FIXING KIT EVAC reserves the right to make alterations to this specification without prior notice. © Copyright Evac Oy. All rights reserved.
  • Page 30 6541772 WATER SUPPLY KIT, USPH, FOR EVAC 900 AND EVAC 910 TOILETS, WALL MODELS 5980802 WATER SUPPLY KIT, USPH, FOR EVAC 90, 900, AND EVAC 910 TOILETS, FLOOR MODELS P/N 6541772 Water supply kit, USPH 6541409 VACUUM BREAKER COMPLETE, USPH,...
  • Page 31 VACUUM TOILET 6541458 PNEUMATIC PUSH BUTTON, EVAC 900 AND EVAC 910, WALL MODELS 6541057 OPTIONAL PNEUMATIC PUSH BUTTON KIT, EVAC 900 AND EVAC 910, FLOOR MODELS P/N 6541458 Pneumatic push button P/N 6540917 is replaced by P/N 6541458 6541272 Bellows...
