PRO-TRACKER RECOVERY SYSTEM
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RECOVERY SYSTEM and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro-Tracker Archery RECOVERY SYSTEM

  • Page 1 PRO-TRACKER RECOVERY SYSTEM USER MANUAL...
  • Page 3 THANK YOU FOR YOUR PURCHASE! System Includes: (1) Radio Frequency Transmitter (2) 7075 Aluminum Carriers (1) Radio Frequency Receiver LED Screen (1) YAGI Antenna (1) Practice Dummy Transmitter Alpha (1) Dual Charger for Transmitters (1) USB Cable for Charger (1) USB to Edison plug (1) Custom Carrying Case Compound bow Setup: (30) Retainer Clips...
  • Page 4 System to help recover your wounded game. Please read through this user manual before using your new system. Properly caring for your Pro-Tracker Recovery System, as outlined in this manual, will ensure your product works well for all your hunts.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS SECTION 1: OPERATING INSTRUCTIONS | pg 1 1.1 — Parts of the Pro-Tracker® System | pg 1 1.2 — Aluminum Carrier | pg 1 1.3 — Radio Frequency Transmitter & its Functions | pg 2 1.3.1 — Charging the Transmitter | pg 4 1.3.2 —...

  • Page 7: Section 1: Operating Instructions

    Secure Bands (crossbow set up) This manual will help to familiarize you with the use of each of the items. The more comfortable you are using your Pro-Tracker® Recovery System the more successful you will become at recovering your trophy. pg 1...

  • Page 8: Aluminum Carrier

    (Figure 2) are an integral part of the Pro-Tracker® Figure 2 Recovery System. They are what screws into your arrow and holds the Radio Frequency Transmitter (section 1.3). The Carriers are made from a 7075 aluminum alloy that is typically used in aerospace programs. It is the strongest aluminum on the market and made to withstand high velocity impacts.

  • Page 9: Radio Frequency Transmitter & Its Functions

    1.3 Radio Frequency Transmitter & Its Functions The Pro-Tracker® Transmitter is rechargeable, lightweight, and water resistant (see Figure 4). The transmitter disengages from Figure 4 the arrow upon impact; not affecting penetration & allowing for pass-throughs. The Transmitter hooks into the animal’s hide and begins sending a unique radio frequency signal every 3 seconds for the duration of the battery life (18-20 hours), or until it is placed back into an Aluminum Carrier.
  • Page 10 All crossbows shoot differently. The Retainer Clips and Secure Bands require a different set-up based on your crossbow’s make and model. Contact Pro-Tracker Archery or go to our website for correct set up. The crossbow set up is the same as the compound set up, with two exceptions: The O-Rings and the Secure Band.

  • Page 11: Transmitter Deactivation

    Transmitter is fully charged when you need it. If the Transmitter is placed in the Aluminum Carrier or left uncharged for more than 30 days it will no longer accept a charge and will have to be replaced. Pro-Tracker Archery will not replace Transmitters neglected in this way. pg 5...

  • Page 12: Receiver And Its Functions

    1.4 Receiver and its functions Figure 12 The Pro-Tracker® Radio Frequency Receiver (Figure 12) is a compact system with an easy to attach antenna. This state-of-the-art receiver can track up to 6 different Transmitter signals at the same time. Displaying signal strength, Transmitter number, current time, time spent tracking, and current battery life, all on a easy to read LED screen.

  • Page 13: Antenna And Its Functions

    Auto Transmitter Register Mode (Figure 14) To remove the code from the Receiver push the enter button and then the manual button. In the manual mode you will see all of the codes for each of the Transmitters you have in your Receiver. To remove a coded Transmitter simply scroll down to the Transmitter you wish to remove, now press and hold the register button for 4 to 6 seconds.

  • Page 14: Section 2: Using In The Field

    SECTION 2: USING IN THE FIELD 2.1 Learn how to use the Pro-Tracker System ® With your friends and family play a game of hide and seek. One person takes a Transmitters programmed into the Receiver and goes hide where ever he wants. Give him a few minutes to get in place.

  • Page 15: Inputting A Transmitter Code Manually

    200 yards away. Use your tracking skills until you pick up the signal. Another suggestion is to move to higher ground. Being above the Transmitter will allow the signal to travel farther. As you get closer to the Transmitter the signal should increase. The highest the number on your Receiver screen is the direction you want to go.

  • Page 16: Section 3: Troubleshooting Guide

    SECTION 3: TROUBLESHOOTING GUIDE Problem: I am getting a similar signal in the opposite direction. Solution: You should be able to get a signal in the opposite direction, only the signal will be stronger when the Receiver is pointed at the Transmitter. The higher the number on the Receiver is the direction to go.
  • Page 17 SECTION 4: BUILDING A TARGET To ensure the protection of your Pro-Tracker Recovery System and to accurately simulate animal hide during target practice, you will need to build a soft target. 1. From your local hardward store, purchase at least three pieces of 4-inch foam.

  • Page 18: Section 5: Transmitter Warranty & Disclaimer

    SECTION 5: TRANSMITTER WARRANTY & DISCLAIMER Pro-Tracker Archery warrants that for a period of 1 year from the date of purchase the transmitter(s) which number(s) are recorded below to be free of defects of material and the electronics. Transmitter Serial Number(s) Pro-Tracker Archery does not warrant the transmitter for misuse or abuse and will only be warranted under normal use conditions.

  • Page 19: Section 6: Receiver Warranty & Disclaimer

    SECTION 6: RECEIVER WARRANTY & DISCLAIMER Pro-Tracker Archery warrants that for a period of 1 year from the date of purchase the digital receiver to be free of defects of material and the electronics. Pro-Tracker Archery does not warrant the receiver for misuse or abuse or to be completely water proof and will only be warranted under normal use conditions.

  • Page 20: Section 7: Returns

    SECTION 7: RETURNS If you are not entirely satisfied with your purchase, we’re here to help. RETURNS: You have 30 calendar days to return an item from the date of purchase. To be eligible for a return, your item must be unused and in the same condition that you received it.
