- Page 1 DEFEAT-19 Cleaning WE MEAN CLEAN User Manual Electric ULV Cold Backpack Fogger DEFEAT-19.Cleaning...
- Page 2 Unlike thermo fogging systems, which convert liquid solutions into fog by vaporizing them with high heat, a process that can destroy a liquid’s chemical properties, the PSF-B201 is a ULV (Ultra Low Volume) “cold” fogger. Instead of heat, it produces and utilizes large volumes of low-...
-
Page 3: General Specifications
Max Flow Rate 12 Gallons per Hour Horizontal Coverage 20 ft Vertical Coverage 7 ft Spray Nozzle Diameter 2 in Package Size 18.5 in x 7.5 in x 19 in Net Weight 9 lbs. Gross Shipping Weight 11 lbs. DEFEAT-19.Cleaning... -
Page 4: Component List
COMPONENT LIST NUMBER NAME Flow Adjuster Knob Discharge Nozzle Power Switch Power Cord Motor Housing Fluid Tank Fluid Tank Cap Application Hose Application Hose Handle Application Hose Collar Backpack Straps DEFEAT-19.Cleaning... -
Page 5: Unit Assembly
UNIT ASSEMBLY Unpack and remove the PSF-B201 from the shipping boxes, noting that the Application Hose Collar is loose and being careful to avoid pulling on the clear plastic tubes or and black wiring conduit STEP -1 that run inside of the Application Hose, from the Power Switch and Discharge Nozzle and into the Motor Housing. - Page 6 Tank Cap and securely tighten IMPORTANT NOTE: The PSF-B201 is designed and calibrated to atomize “thin” liquids, specifically liquids with a viscosity or consistency similar to that of water. Heavier, more viscous formulations generally will not atomize and can clog or damage the PSF-B201 Protect Power Cords from being pinched or sharply bent, particularly where they connect to a power outlet.
-
Page 7: Using The Unit
Adjuster Knob very slightly counterclockwise until the desired fine spray volume is achieved To turn the PSF-B201 OFF, please be sure to follow these steps*: a) Raise the Application Hose Handle to a height above the fluid level in the Fluid Tank. -
Page 8: Maintaining The Unit
• Return all unused chemical to its original container for future use, or dispose of it properly, consistent with the product’s label instructions. • Rinse out and partially fill the PSF-B201’s Fluid Tank with clean water. • Then, after first making sure the blue Flow Adjuster Knob is... - Page 9 • Carefully read and familiarize yourself with this entire manual before attempting to use the PermaSafe PSF-B201 Electric ULV Cold Fogger. • Never operate the PSF-B201 if it is damaged, and always carefully inspect it for damage, including fluid and air leaks, before each use.
- Page 10 PRICING $499.95 DEFEAT-19.Cleaning...
-
Page 11: Safety Warnings
• approved for fogging or in any way not consistent with the product’s label. • Avoid using the unit on windy days. • Always point the Discharge Nozzle towards the ground when turning the unit ON. DEFEAT-19.Cleaning... - Page 12 WARRANTY & TROUBLESHOOTING DEFEAT-19 warrants to the original purchaser of the PSF-B201 Electric ULV Cold Fogger that it is free from defects in workmanship and materials, under normal use and conditions, for a period of 180 days from the original date of purchase.
- Page 13 To be used with …...
