Description and information about Solar Light SE 3
Basic information:
Location: Please check the location for shading before installation. Particularly due to the low level of the sun during the winter
months, shading repeatedly results in low yields, which naturally impair the functionality.
If in doubt, go for the model with an external movable solar panel with 80W or 100W, as this can be aligned and this also copes
better with lower solar radiation.
* If the charge is too low, the luminaire or the electronics may malfunction.(results in no connection via handy) It may no longer
be possible to control the luminaire or the motion detector may no longer switch on because the battery level is too low. In this
case, please wait for the next period of good weather (sunlight) and try again.
Operation or mode: Before selecting the model, please consider the operating mode carefully:
Can the luminaire be dimmed?
Does the luminaire have to shine continuously all night or is light only needed for 3‐4 hours?
A distinction must be made between a private car park or jetty road and a public road or cycle path where lighting classes must
be observed. If you are not sure, please contact us.
Software for control via mobile phone (currently Android only):
Please install the *.apk file (LTSolarLamp_v1.0.2.apk) attached in the *.zip file on your mobile phone.
‐ Depending on the model, in the security settings ‐> Allow installation from unknown sources.
‐ Allow location access and Bluetooth (both on in phone settings)
‐ please uninstall any previous versions of our software, restart the device
‐ for control you should be directly under the lamp (5‐8m)
‐ Please do NOT attempt manual pairing via Bluetooth. The lamp can only be connected via the app!
Screenshot/steps:
Start the app via the blue‐lila "Solar" icon
Choose „BLE CONTROL"
Advertisement
Table of Contents
Summary of Contents for Light Trail Solar Light SE 3
- Page 1 Description and information about Solar Light SE 3 Basic information: Location: Please check the location for shading before installation. Particularly due to the low level of the sun during the winter months, shading repeatedly results in low yields, which naturally impair the functionality. If in doubt, go for the model with an external movable solar panel with 80W or 100W, as this can be aligned and this also copes better with lower solar radiation. * If the charge is too low, the luminaire or the electronics may malfunction.(results in no connection via handy) It may no longer be possible to control the luminaire or the motion detector may no longer switch on because the battery level is too low. In this case, please wait for the next period of good weather (sunlight) and try again. Operation or mode: Before selecting the model, please consider the operating mode carefully: Can the luminaire be dimmed? Does the luminaire have to shine continuously all night or is light only needed for 3‐4 hours? A distinction must be made between a private car park or jetty road and a public road or cycle path where lighting classes must be observed. If you are not sure, please contact us. Software for control via mobile phone (currently Android only): Please install the *.apk file (LTSolarLamp_v1.0.2.apk) attached in the *.zip file on your mobile phone. ‐ Depending on the model, in the security settings ‐> Allow installation from unknown sources. ‐ Allow location access and Bluetooth (both on in phone settings) ‐ please uninstall any previous versions of our software, restart the device ‐ for control you should be directly under the lamp (5‐8m) ‐ Please do NOT attempt manual pairing via Bluetooth. The lamp can only be connected via the app! Screenshot/steps: Start the app via the blue‐lila "Solar" icon Choose „BLE CONTROL“ ...
- Page 2 Wait a while so that the light can be searched for via Bluetooth. Select the desired model. Press on it (In our case INH‐30W‐91207S). The lamp should now be connected to the mobile phone. You are now on the main page. Here you will find the most important settings: ‐ Luminaire on‐off ‐ Operating mode (settings) ‐ read out the charge status / battery (data reading) ...
- Page 3 Here is the overview of the battery and solar panel. In the next versions (controller vers. 1001, 09/2020 and newer) will show the battery status in percent. In our case on the screenshot, the battery is very weak and at the lower limit. When fully charged, the voltage should be between 11.2 and 12.4 volts. Please understand this only as a rough orientation. If battery is under 10.2 Volt we suggest to let the light charge to full. In our latitudes, energy‐saving operation should be selected, especially during the winter months. so that the battery is not completely discharged during periods of bad weather and failures occur. In addition to efficient solar panels and MPPT controllers, we have installed the latest technology to ensure failure‐ free operation. Please keep in mind that it is still a solar light that needs the energy of the sun to function properly. Once the battery is fully charged, the light can easily last 5‐15 days in bad weather, depending on the mode of operation. If you have any questions or problems, please contact us at +43 676 63 86 616 or via e‐mail at office@light‐trail.com ...
