Installation Manual
Open Land System
ISYS 1.1
Art.-Nr.: FRTSTV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISYS 1.1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Oberhauser Bau-Systeme ISYS 1.1

  • Page 1 Installation Manual Open Land System ISYS 1.1 Art.-Nr.: FRTSTV...

  • Page 2: Table Of Contents

    Thank you very much for choosing our mounting system. With these instructions we will describe to you in detail how to proceed with the assembly. If you have any questions, please do not hesitate to contact us at any time. Content: General Information Designation of the individual parts...
  • Page 3 Dear Customer, With the purchase of our systems you have not only secured technically mature products, but also an excellent, complete service. Our competent employees will advise you at any time if questions arise and will deal with your request in detail and of course make sure that everything is carried out to your satisfaction. Compared to conventional systems, our specially developed mounting systems have significant, time-saving features that enable more efficient work when mounting the substructure and modules!

  • Page 4: General Information

    General Information • The soil conditions for the structures should be leveled and load-bearing. • The electrical connection may only be carried out by a qualified electrician. • The completed photovoltaic project should be completely surrounded by a fence to protect it from unauthorized access or damage by wild animals. •...

  • Page 5: Tightening Torques For Screws

    Ratchet with torque and socket wrench insert 17 mm Measuring tape min. 50 m Cord 50 – 100 m Tightening torques for screws Hexagon head screw DIN933 M12x40 (ram profile (A) - rafter profile (B)) 100 Nm Hexagon head screw DIN EN 14399/4 M12x40 (HV) 130 Nm Hexagon head screw DIN933 M12x40 (rafter profile (B) - purlins (C)) 60 Nm...
  • Page 6 Step 2: Ramming works...
  • Page 7 Step 3: Installation of rafter profiles Torque: 100 Nm (A2/A4) 130 Nm (HV)
  • Page 8 Step 4: Installation of diagonal braces Torque: 100 Nm (A2/A4) 130 Nm (HV)
  • Page 9 Step 5: Installation of purlins Torque: 60 Nm...
  • Page 10 Step 6: Installation of purlin - connectors The number of connectors to be used depends on the table design. Torque: 60 Nm...
  • Page 11 Step 7: Installation of modules Click in Click in Torque: 8 - 10 Nm...
  • Page 13 Click in Click in Press Press...
  • Page 14 Torque: 8 - 10 Nm Continue until the last module in the row is fixed. At the end of the row a module end clamp is used again.

  • Page 15: Theft Protection

    For each project you will receive an individual table drawing as well as a layout plan, a shading- and a ramming plan. Theft protection "Opportunity makes the thief!" In order to prevent this from happening, we will be pleased to supply you with our safety balls or, optionally, shear nuts and/or safety screws on request.

  • Page 16: Maintenance

    Maintenance Solar plants have to be maintained in regular intervals (at least once a year), to ensure an optimal functioning and to meet the warranty requirements. At least once a year a visual inspection of the profiles and fixing materials regarding damage or corrosion should be carried out and also a random inspection of the connection points (screws, nuts) should be performed.

  • Page 17: Safety And Liability

    6. The surface guarantee does not apply to installations exposed to any type of chemical that may cause corrosion, such as smoke and rainwater containing carbon, deposits or particles of heavy metals, alkaline products such as ash, cement or animal excrements, or to installations located in the vicinity of a sewage treatment plant.

  • Page 18: Disclaimer

    Disclaimer This installation manual contains notes and recommendations for the installation of photovoltaic mounting systems from Oberhauser. In addition to our instructions, the installing specialist company should observe the valid regulations and rules of technology. Oberhauser is not liable for the dimensioning information contained in commercial investment offers. The components made by Oberhauser are designed for the expected loads and the current state of the art.
  • Page 19 Oberhauser Bau-Systeme GmbH Rohrbach-Bahnhof 18 84494 Niederbergkirchen Tel.: +49 (0) 8635 69392- 0 Fax: +49 (0) 8635 69392-20 E-Mail: info@oberhauser-pv.de...
