AquaLutio AL-1118 User Manual

Ruerse osmosis system
Hide thumbs
Table of Contents

Advertisement

Quick Links

USER
MANUAL
Ruerse Osmosis
System
|
1
USER MANUAL
AL-1118

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AL-1118 and is the answer not in the manual?

Questions and answers

Summary of Contents for AquaLutio AL-1118

  • Page 1 USER MANUAL Ruerse Osmosis System USER MANUAL AL-1118...

  • Page 2: Operating Parameter

    The following tools may be necessary, depending on each particular installation. Electric Drill - 1/4" Drill Bit Phillips Screw Driver 6" Adjustable Wrench Plastic Tubing Cutter Teflon Tape Operating Parameter » Operating pressure: 85psi maximum » Feed water temperature: 40 – 100 degree F (4-37 degree C) »...

  • Page 3: Parts List

    Parts List Components included with the RO system: Make sure you have all these parts before starting installation. STORAGE MACHINE MAIN UNIT TANK FILTER DRINKING HOUSING FAUCET FILTER DRAIN CARTRIDGES SADDLE WATER PLASTIC FEEDER TUBING TANK HOUSING VALVE WRENCHES USER MANUAL...
  • Page 4 STEP Install Feed Water Adapter (AFW) Turn off the Cold Water Line via the Cold Water Shutoff Valve (CWSV) under the sink. Open the kitchen faucet to release pressure and make sure water has stopped before proceeding to the next step. Get a towel or bucket to catch water spill.
  • Page 5 STEP Install Drinking Water Faucet If your kitchen sink does not have an existing 1/2 inch hole, you will have to drill one. (Refer to: video How to drill a Hole on Sink or Counter top). Wipe clean and dry the area. Slip the front plate on the faucet stem, followed by the rubber washer.
  • Page 6 STEP Install Drain Saddle Choose a spot on the drain pipe that is convenient for installing the drain saddle and tubing. It is recomended that you install the pipe horizontally to minimize dripping sounds. Drill a 1/4” hole on the drain pipe (Drill at point approximately 6 inches above the trap);...

  • Page 7: Install Filters

    STEP Install Filters Stand the 3 housings upright. Make sure each housing has a rubber O-ring in its groove. Put the Essence sediment filter into the “1st stage” housing on the right. Put the Essence carbon filters into the “2nd and 3rd stage”...
  • Page 8 STEP Install Reverse Osmosis Membrane The RO membrane is preserved in a sealed bag. Firmly insert the membrane into the housing. The smaller end with two black Orings should be inserted first, Push in until the back end is even with the housing opening.

  • Page 9: Tank Setup

    STEP Tank Setup Apply Teflon tape onto the threads of the tank nipple. Screw the connector onto the tank making sure to avoid cross threading. The connector only needs to be hand tight (DO NOT OVER TIGHTEN) and should thread on easily.

  • Page 10: System Hook Up

    STEP System Hook Up Cut the tubing in 4 pieces to make 4 connections. Make a straight clean cut (recommended to use a cutter) Locate the red plastic nut and connect to the water supply, The side to the red plastic nut is a Quick- Connect see page11, the other side AFW is not a Quick-Connect its a compression fitting.
  • Page 11 How To Remove a connection While pressing dowen lock sleeve to unlock the plastic nut, pul out the plastice nut Press down and hold on lock sleeve to elimiate the gap occupied by lock clip Remove lock clip How to insert a Connection (Quick Connect) Pull the tubing to check...
  • Page 12 Faucet Setup Important! Use plastic sleeve and inserts on the plastic tubing we provide. Do Not use metal sleeve or insert on plastic tubing or the connection will Insert leak! How to connect: Slide the compression Sleeve nut onto the tubing. - Slide the plastic sleeve onto the tubing.

  • Page 13: Starting Up The System

    STEP Starting Up the System Turn off the storage tank ball valve, this will ensure no water can enter the tank. Slowly turn on the cold water supply valve to the sink. If you have not already done so, open the valve of the cold-water self-piercing valve (turn counter clockwise to open).
  • Page 14 Now open the ball valve on the reverse osmosis storage tank, which will allow the tank to fill. This will take approximately 4-10 hours. During this period of time check all fittings for any leaks. If any leaks are found turn off cold- water line and make the necessary correction.
  • Page 15 STAGE FILTER NAME REPLACE STAGE Sediment Filter 6 MONTHS GUIDE Carbon Block 6 MONTHS Carbon Block 6 MONTHS 1-2 YEAR'S RO Membrane depends on the quality Membrane water of the local town Inline Carbon Filter 12 MONTHS Sediment Filter STAGE Removes dust, particles, and rust.
  • Page 16 For information or replacement call: 888.798.2070...
