CableDeconn 5IN1 User Manual

Hdmi to hdmi dvi vga 3.5mm audio with micro usb adapter
Hide thumbs
1
2
3
4
5

Advertisement

Quick Links

Download this manual
CableDeconn 5IN1 HDMI to HDMI DVI VGA 3.5mm Audio with Micro
USB Adapter
D0407
1.0 Specifications
Signal Inputs/Output
Input Signal
Output Video
Input/Output Connector
Size
Net Weight
User Manual
：
HDMI Compliant HDMI1.2 Input
HDMI/VGA/DVI
Input: HDMI Compliant HDMI1.2 Input
Output: HDMI Female V1.2x1
DVI v1.0 Femalex1
VGA 15pin Female x1
Audio 3.5mmx1
Micro USB DC-5V
200*50*15mm
55g

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5IN1 and is the answer not in the manual?

Questions and answers

Related Manuals for CableDeconn 5IN1

Summary of Contents for CableDeconn 5IN1

  • Page 1 User Manual CableDeconn 5IN1 HDMI to HDMI DVI VGA 3.5mm Audio with Micro USB Adapter D0407 ： 1.0 Specifications Signal Inputs/Output Input Signal HDMI Compliant HDMI1.2 Input Output Video HDMI/VGA/DVI Input/Output Connector Input: HDMI Compliant HDMI1.2 Input Output: HDMI Female V1.2x1 DVI v1.0 Femalex1...

  • Page 2: How To Use

    Operating Frequency Vertical Frequency Range HDMI HD 1920*1080@30Hz 1920x1080@60Hz HD 1920*1080@30Hz Video Amplifier Bandwidth 2.25Gbps/225MHz HDMI Resolution 480i/480p,720p,1080i/1080p VGA Resolution 480i/480p,720p,1080i/1080p DVI Resolution 480i/480p,720p,1080i/1080p Warranty Limited Warranty 18 Month Environmental Operating Temperature -20℃to +65℃ Operating Humidity 10% to 85 % RH (no condensation) Storage Temperature -10℃...
  • Page 3 2:When you are using this adapter,please be well noted that 1a:If you connect HDMI Male Ports to your Windows Systems Input Devices,HDMI VGA and DVI Female Ports can be connected to three Monitors (one HDMI,one VGA ,one DVI) at the same time,but these three attached additionally screens can only show same view.

  • Page 4: Package Contents

    through your HDMI displays directly.If your HDMI displays with audio and speaker can not output sound in the first,try to unplug and plug your HDMI cable. 4.0 Package Contents...
  • Page 5 CableDeconn 5IN1 HDMI to HDMI VGA DVI 3.5mm Audio with Micro USB CableDeconn 5IN1 HDMI to HDMI VGA DVI 3.5mm Audio with Micro USB CableDeconn 5IN1 HDMI to HDMI VGA DVI 3.5mm Audio with Micro USB Adapter 1*Micro USB Cable 1*3.5mm Audio Cable Cable 1*3.5mm Audio Cable...
