QUICK START MANUAL

The temperature screening tablets are designed to detect temperature anomalies. It's

important to understand that there are many factors, including environmental and

physiological, that can impact a person's surface temperature reading. Skin surface

temperature vs actual core body temperature may differ either way. The temperature

screening tablets must be operated in accordance with the manufacturer's user

guide. Temperature screening tablets are not intended nor designed to diagnose or

detect medical conditions including, but not limited to, viruses or other illnesses. The

temperature screening tablets should only be used to detect variations in surface

temperature. In the event that an elevated skin temperature is detected, the subject

should be advised to check temperature with an approved medical thermometer

and have the finding confirmed. Absence of an elevated skin temperature does not

preclude a fever.

Customer Service &

Email:

Temperature Screening Kiosk

User Guide

Sales:

(855) 436-0527

sales@easybadges.com

Support:

(971) 252-2464

Email:

support@easybadges.com

Table of Contents

Need help?

Do you have a question about the Temperature Screening Kiosk and is the answer not in the manual?

Questions and answers

Summary of Contents for easy badges Temperature Screening Kiosk

Page 1 Temperature Screening Kiosk User Guide QUICK START MANUAL The temperature screening tablets are designed to detect temperature anomalies. It’s important to understand that there are many factors, including environmental and physiological, that can impact a person’s surface temperature reading. Skin surface temperature vs actual core body temperature may differ either way.
Page 2: Table Of Contents
Temperature Screening Kiosk User Guide CONTENTS 1. Power Connection......................3–4 2. Software Setup 2.1 Access Settings Menu....................5 2.2 Application Settings......................6 2.3 Update Software......................7 2.4 Face Detection Utilities...................8–10 2.5 Facial Recognition Settings..................11–19 2.6 Setting up Wifi.......................20–21 3. Software Roadmap......................23 Customer Service &...
Page 3: Power Connection
Temperature Screening Kiosk User Guide 1. POWER CONNECTION 1.1 Connect the kiosk’s power plug to an AC power outlet. The unit should power up automatically. If the unit does not power up, press the power button located on the back right of the monitor, as you face the screen.
Page 4 Temperature Screening Kiosk User Guide 1.2 To power down the machine when not in use, press and hold the power button for several seconds until a prompt appears that says “POWER OFF.” Click on this to shut down the machine.
Page 5: Software Setup
Temperature Screening Kiosk User Guide 2. SOFTWARE SETUP 2.1 Access Settings Menu 2.1.1 Press and hold anywhere on the screen until a dialog box pops up. 2.1.2 Enter your password, or use the default password “0000” if it was never changed.
Page 6: Application Settings
If you have not done so already, change the password. *CAUTION* When changing passwords, be sure to record the new password and store safely. Easy Badges cannot help recover a password. If necessary, the display language can also be changed. When you are finished, press the “Save changes”...
Page 7: Update Software
Temperature Screening Kiosk User Guide 2.3 Update Software 2.3.1 Press the “>” next to “Update TAURI” if you want to check for updates. *WARNING* Check with Easy Badges before proceeding with any updates. Customer Service & Sales: (855) 436-0527 Support:...
Page 8: Face Detection Utilities
Temperature Screening Kiosk User Guide 2.4 Face Detection Utilities 2.4.1 Press the “>” next to “Face detection utilities.” 2.4.2 Enable the “Detection of wearing mask” feature. The alert message can be changed if necessary. If you want someone to be notified of people who set off the alarm for being outside the temperature range, enable the “Record high temperature people”...
Page 9 Temperature Screening Kiosk User Guide Customer Service & Sales: (855) 436-0527 Support: (971) 252-2464 Email: sales@easybadges.com Email: support@easybadges.com...
Page 10 Temperature Screening Kiosk User Guide 2.4.3 Click the arrow at the top of the screen to go back to the “Facial recognition settings” menu. Customer Service & Sales: (855) 436-0527 Support: (971) 252-2464 Email: sales@easybadges.com Email: support@easybadges.com...
Page 11: Facial Recognition Settings
Temperature Screening Kiosk User Guide 2.5 Facial Recognition Settings 2.5.1 Click the “>” next to “Facial recognition settings.” 2.5.2 Click the “>” next to “1:N Face search.” Customer Service & Sales: (855) 436-0527 Support: (971) 252-2464 Email: sales@easybadges.com Email: support@easybadges.com...
Page 12 Temperature Screening Kiosk User Guide 2.5.3 Click the “>” next to “Face registration.” 2.5.4 Fill in the “User name,” “User group,” and “User information” for the person being added to the database. When the person is ready to be added, press the red “Start face collection”...
Page 13 Temperature Screening Kiosk User Guide 2.5.5 Click the “>” next to “Face database management.” 2.5.6 The “Face database management” menu will allow you to search for registered faces by group. You can update photos and delete users in this menu.
Page 14 Temperature Screening Kiosk User Guide 2.5.7 Click the “>” next to “Bulk import.” 2.5.8 “Bulk import” will allow you to register multiple photos/faces at the same time. Follow the instructions in the menu to accomplish this. Customer Service & Sales:...
Page 15 Temperature Screening Kiosk User Guide **CAUTION** It is recommended to leave the following settings, sections 2.5.9 thru 2.5.17, at the factory default unless there is a specific need to make adjustments. Changing the settings may affect the operation of the kiosk.
Page 16 Temperature Screening Kiosk User Guide 2.5.11 “Minimum face detection” = adjust the detection area on the face. 2.5.12 “Face detection angle” = adjust the angle of face detection to match monitor orientation. Customer Service & Sales: (855) 436-0527 Support: (971) 252-2464 Email: sales@easybadges.com...
Page 17 Temperature Screening Kiosk User Guide 2.5.13 “Camera video flow echo angle” = adjust the image display to match monitor orientation. 2.5.14 “Quality control parameters” = controls the quality of the image. Customer Service & Sales: (855) 436-0527 Support: (971) 252-2464 Email: sales@easybadges.com...
Page 18 Temperature Screening Kiosk User Guide 2.5.15 “Lens and living detection mode” = determines if a real person or photo is being scanned. 2.5.16 “Live detection threshold” = adjust the value to determine if the object being scanned is a living body or not.
Page 19 Temperature Screening Kiosk User Guide 2.5.17 “Identify model thresholds” = adjust the mapping relationship between far and FRR. Customer Service & Sales: (855) 436-0527 Support: (971) 252-2464 Email: sales@easybadges.com Email: support@easybadges.com...
Page 20: Setting Up Wifi
Temperature Screening Kiosk User Guide 2.6 Setting up Wifi 2.6.1 Click the “>” next to “System settings.” 2.6.2 Click on Wi-Fi. Customer Service & Sales: (855) 436-0527 Support: (971) 252-2464 Email: sales@easybadges.com Email: support@easybadges.com...
Page 21 Temperature Screening Kiosk User Guide 2.6.3 Select the network you wish to connect to from the available list. 2.6.4 Once you have connected to the network, click the “” to go back to the system settings menu. Click it again to go back to the application settings menu.
Page 22 Temperature Screening Kiosk User Guide YOUR UNIT IS NOW READY FOR USE. FOR OPTIMAL SCANNING, KEEP IN A LOCATION WHERE IR SENSOR AND CAMERA WILL NOT BE AFFECTED BY SUNLIGHT OR LIGHT FIXTURES. PERSON BEING SCANNED SHOULD HAVE THEIR FACE IN THE CENTER OF THE SCREEN.
Page 23: Software Roadmap
Temperature Screening Kiosk Software Roadmap Available for the next software updates in 2 weeks • Calibration Mode: Manually calibrate temp sensor • Email notification with snapshot of person with high temp detected. Right now only one email can be entered in Tauri. If customer has multiple kiosks, a different email can be entered in each device.
