Summary of Contents for EzFold DW-FDB03
- Page 1 EzFold Scooter Instruction Manual...
- Page 2 Thank you for purchasing the EzFold Scooter！ Proper use of this product is the prerequisite to ensure safety, convenience and durability Please read this instruction carefully before using, and be sure to master the matters marked with the mark ★...
- Page 3 Product drawing Key switch 12. Pedal plate Shifter 13 .Brake apparatus Electric quantity display 14. Motor 4.Forward and reverse switch 15. Reflector 5.Handlebar 16. Rear Fender Brake 17 .Battery Horn switch 18. Battery box Quick release 19 .Charge port Headlamp 20 .Armrest Front Fender 21 .Backrest...
- Page 4 ①Open the quick release ②Can be adjusted up and down ③Install the headlamp (follow the arrow) ④Install the nasonry (follow the arrow) ⑤Install the wheel (follow the arrow) Back side install finish Face side install finish...
- Page 5 Opening the EzFold Scooter ③ Press down the cushion (as the picture) ① Tilt the body ② Forward the handlebar (direction as the picture) Finish the opening Folding the EzFold Scooter ② Tilt the body ③ Pull back the handlebar ①Lift the cushion up...
- Page 6 Electronic accelerator handle The ergonomic non-slip accelerator handle: by turning the handle down the EzFold Scooter will accelerate and be letting go th EzFold will come to a stop. Note: Always use the break handle in addition to letting to of the accelerator when coming to a stop.
- Page 7 Specifications Model DW-FDB03 DW-FDB02 DW-FDB01 Specifications Picture 34" x 20"x 39" Open size 34" x 20"x 39" 34" x 20" x 18" Fold size 34" x 20" x 18" Total Weight 46 lbs. 46 lbs. Frame Aluminum alloy Aluminum alloy...
- Page 8 Inspection and maintenance before driving In order to ensure that you get maximum use and safety for your EzFold Scooter, please check and maintain the product according to the following requirements before using.
-
Page 9: Battery Instruction
Battery Instruction ★Improper use will shorten the service life of the battery, and may lead to the fever of the battery, Fire, or even explosions. Please read the following notes carefully: ★Do not separate and disconnect the battery. There are protective circuit function parts inside the battery pack. - Page 10 damaged, it may cause short circuit, thus causing fire and other dangers; ★If the battery is damaged or leaked, and the leakage material enters the eyes carelessly, please don't rub it with your hands, wash it with clean water immediately, and go to the doctor as soon as possible; ★Do not mix lithium ion batteries made by different manufacturers or with different capacity.
- Page 11 ★Before driving for the first time, be sure to test drive you Ezfold in the open field. Only then drive it on a pedestrian sidewalk , after mastering acceleration, deceleration, braking, perfectly ★Follow traffic rules and maintain moderate speed;...
- Page 12 Eliminate of frequent malfunction Malfunction Reason solution Adjuster shifter out 1. battery cable is loose 1.Tighten the battery cable of order or 2. Shortage power 2.full recharge the battery Significant 3. Spring failure of Adjuster 3.change the spring or shifter shifter reduction of maximum speed...
- Page 13 ★ Batteries, chargers, motors, controllers and control shifter should be repaired by professional technicians or after-sales maintenance units ★The above data are for reference only. The technical data of this product series are subject to change without prior notice ★In actual use, due to different road conditions, climate, driving speed, charging time, mileage and other data are different Safety reminder ★When the scooter starts, please slow down the throttle to...
