BELITE ELECTRONICS RADIANT RFGA-022C Specifications - Installation And Operation Instructions

Item#: RFGA
RADIANT Fuel gauge
Specifications, Installation and
Operation Instructions for the
Belite RADIANT Fuel Gauge
LAST UPDATED: May 2017
The Belite RADIANT Fuel Gauge
is designed to provide fuel level
and historical usage informa-
tion to the pilot in a single, small
lightweight enclosure. The unit
is not TSO'd or PMA'd. Use only in
appropriate aircraft as a backup
to certified instruments in VFR
conditions.
As opposed to traditional needle
'steam gauges' , which often
work poorly and provide only a
single dimension into the fuel
use situation, this new RADIANT
gauge provides current fuel
levels and fuel use trends using
an unusually brilliant, full color
LCD screen.
These fuel gauges also provide
predictive time to empty. This
calculation is based on the last
six minutes of fuel usage, and
displays a value whenever the
calculated time is less than 99
minutes, and fuel is still in the
tank. The value is provided
independently for each tank.
And if you'd like your tanks
designated as something other
than LEFT or RIGHT, you can
configure that as well. Main,
Left, Right, Header, Aux.. are all
available labeling options.
If you are running with just
one tank, you may turn off the
second half of the display.
Another big plus is the ability
to use any kind of automotive
fuel sender. You can tell the unit
BELITE ELECTRONICS is a Division of BELITE AIRCRAFT - Wichita, Kansas
if the ohms runs big to small,
or small to big. (Automotive
senders are often reversed from
the aircraft standard.)
Product References
Item#: RFGA-022C:
CAPACITIVE or FIVE VOLT
SCALE INPUT with SINGLE or
DUAL TANKS
Item#: RFGA-022R:
RESISTIVE OR FLOAT INPUT
with SINGLE or DUAL TANKS
Item#: RFGA-022L:
LIQUID LEVEL FUEL PROBE
INPUT with SINGLE or DUAL
TANKS
This document also refers to
other Belite products:
Item#: FPS-010:
LIQUID LEVEL FUEL PROBE
WITH COMPUTER AND FIVE
POINT CALIBRATION AND
1/4NPT THREAD
Item#: FPS-018:
LIQUID LEVEL FUEL PROBE
WITH COMPUTER AND FIVE
POINT CALIBRATION AND
1/8NPT THREAD
Item#: FPS-110:
LIQUID LEVEL FUEL PROBE
WITHOUT COMPUTER WITH
1/4 NPT THREAD
Item#: FPS-118:
LIQUID LEVEL FUEL PROBE
WITHOUT COMPUTER WITH
1/8 NPT THREAD
www.beliteaircraft.com
DISCLAIMER:
Products from Belite Electronics are not
designed to be used in applications where
their failure would endanger safe flight or
human life in any way. They are intended
solely for use in VFR conditions. They are
not certified to meet any Technical Standard
Order, and are not produced under a Parts
Manufacturing Authority (TSO / PMA).
As a result, they are suitable only for use
in experimental and ultralight aircraft,
and in Light Sport Aircraft, if meeting the
requirements of the respective manufacture.
WARRANTY:
Your new Belite Avionics instrument carries
a one year warranty. Please contact us at
info@beliteaircraft.com should your product
need warranty service. International warranty
service will be charged $50.00US for repairs,
which includes return shipping after repair.
Payment must be received before service
begins.
RETURN/REFUND INFORMATION:
Must be returned in new, resalable condition
within 14 days
CONTACT INFORMATION:
E: info@beliteaircraft.com
T: 316-253-6746
Belite Enterprises LLC
8610 E. 34th St. N, #1
Wichita, KS 67226
A New Generation of Digital Avionics
T: 316-253-6746
www.beliteaircraft.com
E: info@beliteaircraft.com T: 316-253-6746
