The Future was 8 bit divMMC Future User Manual

Sd card interface for sinclair zx spectrum

Table of Contents

Download this manual

GETTING STARTED

1. Set up your ZX Spectrum as normal

2. With the power off, attach the divMMC Future to the edge connector on the rear of the Spectrum.

The slot is keyed, it will only fit one way around – never insert or remove the divMMC Future with the

power on

3. Insert the SD card into the divMMC Future, it will click in place, click again if you want to eject it

4. Pause to appreciate there are no jumpers to set or switches to configure

5. Turn the Spectrum on

6. You should see a black screen announcing ESXDOS loading and three file should load

7. If it does not, switch off again and check the SD card is inserted correctly and the edge connector is

firmly in place

If you did not buy a preloaded SD card with your divMMC Future, download the starter file set and extract to

an SD card:

tfw8b.com/downloads

The BIN and SYS folders need to be there for ESXDOS to work, the rest can be arranged as you like. The current

ESXDOS firmware is limited to 8.3 filenames, so rename files and folders where necessary.

There is a Games folder with many sample games which were downloaded from World of Spectrum. We have

not been able to test all the games in this folder, let us know if you find better versions. Most of these games

are over 30 years old and publically available on the internet, so it is really only the ebay sellers who would

benefit, not the original copyright holders. If any of these infringe your copyright, we will remove them from

future releases.

V1.0 7-2017

Table of Contents

Do you have a question about the divMMC Future and is the answer not in the manual?

Page 1 The slot is keyed, it will only fit one way around – never insert or remove the divMMC Future with the power on 3. Insert the SD card into the divMMC Future, it will click in place, click again if you want to eject it 4. Pause to appreciate there are no jumpers to set or switches to configure 5.
Page 2 USING THE DIVMMC FUTURE MENU Whenever you want to load something, press the menu button at the rear button on the divMMC Future. This is illuminated, and will flash during operation. When the menu appears, you can navigate through using the arrow keys, select the appropriate file and press enter to load the file.
Page 3 When divMMC Future is in use, your Spectrum will boot up in 48K mode, even on later systems. If you want to disable the divMMC Future and get the default menu on a 128K or later, simply press in the SD card to eject it.
Page 4 Thanks to Mario Pratzo, Miguel Guerreiro, and others for their work on the original divMMC designs and ESXDOS firmware, more info at esxdos.org. Thanks to Dave and Tim for their work in updating the divMMC design for the divMMC Future. Sample games on the SD card were downloaded from worldofspectrum.org.
