IMPORTANT:
R
WARNING:
WARNING
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or
death. Read the installation, operation and
maintenance instructions thoroughly before installing
or servicing this equipment.
If you experience difficulties with this product, do not return to the place of purchase. Please contact Mission Hills Furniture and we will
replace defective or missing parts free of charge. (Continental US only) For customer service inquiries, please contact us
at: 1-877-542-1975 (US) 7 a.m.-4 p.m. PST, Monday - Friday. / or you may email info@missionhillsfurniture.com
Dec-05-2016
OUTDOOR FIRE TABLE
OWNER'S MANUAL
RETAIN FOR FUTURE REFERENCE.
READ CAREFULLY BEFORE ASSEMBLY.
C
R
For Outdoor Use Only
San Diego, CA 92110, USA
www.missionhillsfurniture.com
TECHNICAL SPECIFICATION
Certifications:
ANS Z21.97-2014/CSA 2.41-2014
Outdoor Decorative Gas Appliances
Rating: Maximum 40,000 BTU / hr. input
Tank size: 20 lb / 9 kg
Fuel: Propane Gas
Mainfold pressure: 11.00 in. W.C.
Inlet gas supply pressure:
Maximum 250 PSI
DANGER
R
U S
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and
immediately call you gas supplier or fire department.
MANUFACTURER'S ITEM # : FPC-SMF-XX
1
Minimum 25 PSI
CARBON MONOXIDE HAZARD
This appliance can produce
carbon monoxide which has
no odor. Using it in an enclosed
space can kill you. Never use this
appliance in an enclosed space
such as a camper, tent or home.
DANGER
CSA MODEL # ：27643-CO
Advertisement
Table of Contents
Summary of Contents for Mission Hills 27643-CO
- Page 1 MANUFACTURER’S ITEM # : FPC-SMF-XX If you experience difficulties with this product, do not return to the place of purchase. Please contact Mission Hills Furniture and we will replace defective or missing parts free of charge. (Continental US only) For customer service inquiries, please contact us at: 1-877-542-1975 (US) 7 a.m.-4 p.m.
-
Page 2: Hardware List
San Diego, CA 92110, USA www.missionhillsfurniture.com PARTS IDENTIFICATION LIST A. Lazy Susan Burner Cover B. Burner assembly C. Table top D. Table base PART DESCRIPTION Lazy Susan burner cover Burner Assembly Table top Table base * The ignition module requires one Alkaline AA size battery (1.5V). Battery is not included HARDWARE LIST PART HARDWARE... -
Page 3: Safety Information
San Diego, CA 92110, USA www.missionhillsfurniture.com SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any questions regarding the product, please call customer service at 1-877-542-1975 , 7 a.m. - 4 p.m., PST, Monday - Friday. This appliance has been tested to and complies with the ANS Z21.97-2010, Outdoor Decorative Gas Appliances CGA CR 97-003 Outdoor Gas Fireplaces. - Page 4 San Diego, CA 92110, USA www.missionhillsfurniture.com SAFETY INFORMATION DANGER DANGER • EXPLOSION - FIRE HAZARD • CARBON MONOXIDE HAZARD • Keep solid combustibles, such as building materials, • This fire pit is a combustion appliance. All combustion paper or cardboard, a safe distance away from the appliances produce carbon monoxide (CO) during the fire pit as recommended by the instructions.
- Page 5 San Diego, CA 92110, USA www.missionhillsfurniture.com SAFETY INFORMATION WARNING WARNING California Proposition 65 • This product is fueled by propane gas. Propane gas Combustion by-products produced when using is invisible, odorless, and flammable. An odorant is this product contain chemicals known to the State normally added to help detect leaks and can be of California to cause cancer, birth defects, and described as a “rotten egg”...
-
Page 6: Operation Checklist
San Diego, CA 92110, USA www.missionhillsfurniture.com OPERATION CHECKLIST Operation Checklist For a safe and pleasurable heating experience, perform this check before each use. Before Operation: 1. I am familiar with entire owner’s manual and understand all precautions noted. 2. All components are properly assembled, intact and operable. 3. - Page 7 San Diego, CA 92110, USA www.missionhillsfurniture.com ASSEMBLY INSTRUCTIONS ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE. INTENDED FOR RESIDENTIAL USE ONLY. Keep children away during assembly.This item contains small parts which can be swallowed by children. Do not use indoors and inside any enclosure. Retain the manual for future reference.
- Page 8 San Diego, CA 92110, USA www.missionhillsfurniture.com ASSEMBLY INSTRUCTIONS 5. Pour the glass rocks or lava rocks into the burner pan completely covering the burner. See Figure 5. ATTENTION: BURNER PAN Do not sit or stand on this table. Wear gloves when handling lava rocks or fire glass. WARNING DO NOT COVER THE IGNITION SCREEN when placing the lava rocks or glass rocks into the fire bowl.
- Page 9 San Diego, CA 92110, USA www.missionhillsfurniture.com ASSEMBLY INSTRUCTIONS 8. Tighten threaded knobs found on tank tray (Figure 8 ) so that the LP tank cannot move from side to side. Do not remove plastic cap from end of threaded section. 9.
- Page 10 San Diego, C A 92110, USA ww w.missionhillsfurniture.com PROPANE CYLINDER INFORMATION 1. Connect hose and regulator to cylinde r. r. The propane gas and cylinder are sold separately. Use a standard 20 lb. propane cylinder only. Use this fire pit only with a propane vapor withdrawal supply system.
-
Page 11: Checking For Leaks
San Diego, CA 92110, USA www.missionhillsfurniture.com CHECKING FOR LEAKS WARNING • Perform all leak tests outdoors. • Extinguish all open flames. • NEVER leak test when smoking. • Do not use the fire pit until all connections have been leak tested and do not leak. Hose / Regulator Regulator / Cylinder connection... - Page 12 San Diego, CA 92110, USA www.missionhillsfurniture.com OPERATION INSTRUCTIONS WARNING The regulator must be put on the shelf when it is disconnected from the gas tank ( as figure shown beside ) DANGER WARNING • CARBON MONOXIDE HAZARD Very hot while in operation! Never lean over the fireplace while in use.
- Page 13 San Diego, CA 92110, USA www.missionhillsfurniture.com OPERATION INSTRUCTIONS TO TURN ON THE FIRE PIT 1. Turn the control knob to OFF( ) position (Figure a) and turn on the valve on the gas cylinder Figure a 2. Press down and turn the control knob to HIGH ( ( Figure b ) postition ( anti-clockwise 90º...
- Page 14 San Diego, CA 92110, USA www.missionhillsfurniture.com OPERATION INSTRUCTIONS WARNING WARNING FOR YOUR SAFETY FOR YOUR SAFETY Be careful when attempting to manually ignite this Do not sit or stand on the fire table fire pit. Holding in the control knob for more than 10 seconds before igniting the gas will cause a ball of flame upon ignition.
-
Page 15: Care And Maintenance
San Diego, CA 92110, USA www.missionhillsfurniture.com CARE AND MAINTENANCE To enjoy years of outstanding performance from your fire pit, WARNING make sure you perform the following maintenance activities on a regular basis: Keep exterior surfaces clean. FOR YOUR SAFETY: 1. Use warm soapy water for cleaning. Never use flammable, •... -
Page 16: Troubleshooting
If you have any questions regarding the warranty or service, please call our number: 1-877-542-1975 Mission Hills Furniture 2245 San Diego Ave., Suite 125 San Diego , CA 92110... - Page 17 San Diego, CA 92110, USA ww w.missionhillsfurniture.com IMPORTANT INFORMATION ABOUT NATURAL STONE TOP CONGRATULATIONS ! You have purchased a Natural Stone Table. The Natural Stone Table’s beauty and durability will enhance your outdoor entertaining for years to come. Natural Stone’s surface is not homogeneous, therefore, the patterns may differ in texture and color. This variation in Natural Stone allows each table to convey its own unique character and beauty.
