- Page 1 User M anual S e l f b a i l i n g C a n o e / k aya k R O B f i n...
- Page 2 User Manual Selfbailing Canoe kayak ROBfin Thank you for purchasing our product. Before you use the boat for the first time, pls read the user´s manual. Description: Boat consist of 3 inflatable chambers, permanently attached. Floor and 2 tubes. All inflatable parts have valves for inflating/deflating, floor is equiped by release valve as protection from high pressure.
- Page 3 Quick set up guide: Unroll boat from the bag. Be sure there are no sharp objects bellow the boat that could make damage. Than: 1. Close the valves by push and turn the middle part (see Valve chapter) 2. Using the pump or blower start inflating. If needed, use the reduction for the valve. 3.
- Page 4 Valves: PUSH the middle button and turn CLOCKWISE to OPEN the valve. PUSH and TURN COUNTERCLOKWISE to CLOSE the valve. Before inflating, close all valves. When inflated, close the valve using the cap before you sit in the boat. If needed, use bayonet adaptors for pumps or blowers to fit the valve properly. If you detect the air leak around the valve, fasten it using the tool provided you by producer.
- Page 5 Safety: Canoes and Kayaks ROBfin are recomended for paddling on lakes, running swift and whitewater up to class WW 4. Class 4 is understood as the river or its section with high waves, holes, stoppers, with non consequent current, where is difficult or impossible to see the line from the water and careful scouting is necessary.
- Page 6 When on the river: Paddling canoe Yukon: Canoe is designed for 2 (3) paddlers. On easy sections you can comfortable seat, on white water we recomend to knee using the knee straps across your thighs. When flipped, lean forward and straight you legs to free yourself. In case of need you can also use the safety buckle. It is dangerous to use straps over legs when seated !!! We do not recomend to tie straps anyway around your legs.
-
Page 7: Folding And Transport
IT PREVENTS PIN HOLES AND OTHER DAMAGES ! Storage: ROBfin boats do not require any special treatment. Store it for longer period dry (straps will dry longer than rest of the boat) and clean. Keep away from heat source, rodents, chemicals, moisture and fungi when storing for off season, do not roll it tight. - Page 8 5. in emergency it can be used immediately. In 8 hrs patch will be on 80% of the maximum adhesion. Bigger damage repairs are servised by producer or dealer. If you have questions about your boat, need assistance with a repair or warranty claim, contact us at: info@robfin.cz...
- Page 9 Damage caused by exceeded maximum working pressure. Commercial or rental use damages. User/third party equipment damage or other cases caused when using ROBfin boat. Produced in Conformity with EN ISO 6185-1, Typ III P ro d u c e r : D e n a l i , s p o l .
