USER MANUAL

ATMOFIZER PRO

BREATHE WITH CONFIDENCE.

www.atmofizer.com

Table of Contents

Need help?

Do you have a question about the PRO WHITE and is the answer not in the manual?

Questions and answers

Summary of Contents for ATMOFIZER PRO WHITE

Page 1 USER MANUAL ATMOFIZER PRO BREATHE WITH CONFIDENCE. www.atmofizer.com...
Page 2: Table Of Contents
SET-UP / POSITIONING OPERATION MAINTENANCE ERRORS AND FAULTS SPARE PARTS AND ACCESSORIES RECYCLING AND DISPOSAL DECLARATION OF CONFORMITY ATMOFIZER PRO WHITE ATMOFIZER PRO BLACK Reduces 99.9% of airborne viruses and bacteria in treated air. See UL Verify for specific organisms.
Page 3 ATMOFIZER PRO – USER MANUAL – 1. INTRODUCTION 1. INTRODUCTION 1.1. ABOUT THIS MANUAL Congratulations! You have chosen a high-quality and innovative product. The user manual is part of the product. It contains important instructions for safety, use and disposal. Read the manual carefully before starting or using the device. Only use the device as described and for the specified areas of application.
Page 4: Legend Of Symbols And Pictograms
ATMOFIZER PRO – USER MANUAL – 2. LEGEND OF SYMBOLS AND PICTOGRAMS 2. LEGEND OF SYMBOLS AND PICTOGRAMS 2.1. SYMBOLS AND SIGNAL WORDS Warning of electrical voltage Info This symbol indicates dangers to the life and Information marked with this symbol helps you to health of persons due to electrical voltage. carry out your tasks quickly and safely. Warning of optical radiation (here: UV light) Follow the manual...
Page 5: Safety
ATMOFIZER PRO – USER MANUAL – 3. SAFETY 3. SAFETY Read this manual carefully before starting or using the device. Always store the manual in the immediate vicinity of the device or its site of use! Warning Read all safety warnings, all instructions and technical specifications.
Page 6 ATMOFIZER PRO – USER MANUAL – 3. SAFETY • Do not store or use the device in dusty environment or in rooms where large amounts of dust are produced, e.g. workshops. • Do not store or use the device in corrosive atmosphere, e.g., containing oil, Sulphur, chlorine or salt.
Page 7 ATMOFIZER PRO – USER MANUAL – 3. SAFETY • I n the event of failure or emergency, disconnect the main supply by removing the mains plug from the mains socket. Hold onto the mains plug body while doing so. • S witch the device off and disconnect the power cable from the mains socket when the device is not in use and/or unmounted. 3.6. MAINTENANCE • B efore carrying out only by „authorized specialist company/electricians: Dust collector maintenance or dry cleaning on the device, remove the mains plug from the mains so- cket. Hold onto the mains plug while doing so. • Do not electrically maintain or repair the device yourself. • O nly use original spare parts, for otherwise safe and functional operation cannot be ensured. • Do not maintain the Dust collectors yourself.“ (for production 2020-12) 3.7. DUST COLLECTOR DISPOSAL • D ispose of replaced Dust collectors properly, especially after filtering substances hazardous to health. 3.8. ULTRASOUND DURING OPERATION • I ndividual persons or animals may feel uncomfortable in the direct vicinity of intense...
Page 8 ATMOFIZER PRO – USER MANUAL – 3. SAFETY 3.11. PICTOGRAMS, SAFETY SIGNS AND LABELS ON THE DEVICE Warning Wear safety glasses (here: UV light) Do not remove any safety signs, stickers or This symbol indicates that UV eye protection labels from the device. Keep all safety signs, it is mandatory on professional electric maintenance with open device housing. stickers and labels in legible condition. [ Not applicable to user maintenance tasks The following safety signs and labels are observing the user manual. ] attached to the device:...
Page 9: Information About The Device
ATMOFIZER PRO – USER MANUAL – 4. INFORMATION ABOUT THE DEVICE 4. INFORMATION ABOUT THE DEVICE 4.1. DEVICE DESCRIPTION The device is designed for indoor air remediation. It physically inactivates airborne viruses and germs to enhance air quality and produce healthier air to breathe. This way, the device reduces the airborne risk of infection in frequented public zones. 4.2. FUNCTIONING PRINCIPLES The device contains inlet Dust collectors at both sides to remove coarse dust. Patent applied physical air remediation follows, including a combination of ultrasound treatment and UV light application to effectively inactivate the airborne virus load. This special technology also facilitates the use of “mild” (275nm) UV light, disabling the undesi- red production of toxic Ozone The remediated air is released back into the room via the top grating. Three adjustable air circulation modes facilitate the creation of a customizable 326.5 high-quality air remediation zone. M ost air purifiers and sterilization devices using UV light rely on 254 nm UV light. This high-energy (hard) UV light does facilitate the creation of carcinogenic Ozone from atmospheric air. 4.3. DEVICE DEPICTION NO. DESIGNATION Grab handle P ower inlet (IEC) module incl. fuse holder and illuminated On/Off power switch Caster wheel...
Page 10: Technical Data
ATMOFIZER PRO – USER MANUAL – 5.TECHNICAL DATA 5. TECHNICAL DATA PARAMETER VALUE ORDER DETAILS Appliance Name ATMOFIZER PRO VENTILATION PERFORMANCE Airflow modes 10% / off (standby) (rate / LED ring color) 33% / blue (eco) 67% / green (standard) 100% / red (high) Ventilation performance, max. 450 m³/h 15,892 cfh Clean zone area with 3 air 75 m³/h 2,649 cfh exchanges/hr. Clean zone area with 6 air 150 m³/h 5,297 cfh exchanges/hr. Dust collector for air inlet POWER SUPPLY North America (NA): 100-125 V~, 50/60 Hz, 2.7A Input voltage Germany (DE): 100-240 V~, 50/60 Hz, 2.7A...
Page 11: Transport And Storage
ATMOFIZER PRO – USER MANUAL – 6.TRANSPORT AND STORAGE 6. TRANSPORT AND STORAGE Note If you store or transport the device improperly, the device may be damaged. Note the information regarding transport and storage of the device. Note Should the device be damaged, please contact the responsible dealer or manufacturer, where the purchase was made. • I n earthquake-areas please always fix the device to the ground firmly (even when not in operation). • Contact customer support for ground mounting equipment (accessories). 6.1. TRANSPORT To make the device easier to transport, it is fitted with two handles and four wheels. Wear foot protection Wear suitable foot protection while transporting the device. Risk of injury caused by the wheels when rolling the device onto a foot. Before transporting the device, observe the following: • Switch the device off.
Page 12: Installation
ATMOFIZER PRO – USER MANUAL – 7. INSTALLATION / SET-UP 7. INSTALLATION Scope of delivery Scope of delivery 1 × 1 × • 1 × Device • 1 × Main power connection cord (C13 to wall plug) • 1 × Quick Start Guide QUICK START GUIDE 1 × Consumables Consumables 2 × 4 × • 2 × G4 Dust collector for air inlet (pre-installed) • 4 × G4 Dust collector for air inlet (replacement) 8. SET-UP / POSITIONING When positioning the device, observe the minimum distance from walls or other objects as described in the chapter Technical data.
Page 13: Operation
ATMOFIZER PRO – USER MANUAL – 9.OPERATION 9. OPERATION 9.1. SWITCHING THE DEVICE ON Switching the device on 1. O nce you have completely installed the device as described in the Start-up chapter, you can switch it on. 2. S et the on/off switch 2) to position I. > The on/off switch (2) is illuminated. > T he device is switched on standbay and runs at the set fan speed of 10%. ON/OFF SWITCH Switch device on or off; Lights up when the device is switched on Make sure the breaks are on and do not move during operation.
Page 14: Maintenance
ATMOFIZER PRO – USER MANUAL – 9.OPERATION / 10. MAINTENANCE 9.4. SHUTDOWN FOR TRANSPORT OR STORAGE 1. Proceed as described in the Switch-off chapter. 2. Clean the device according to the Maintenance chapter. 3. Store the device according to the Storage chapter. Warning of electrical voltage Hold onto the mains plug while pulling the power cable out of the mains socket. Warning of electrical voltage Do not touch the mains plug with wet or damp hands. 10. MAINTENANCE The device is designed for long hours of operation with minimum maintenance effort. Safe operation of the device requires all built-in components to be checked and cleaned after 12 months at the latest or after 4000 operating hours as well as all damaged com- ponents to be replaced.
Page 15 ATMOFIZER PRO – USER MANUAL – 10. MAINTENANCE 10.2. CLEANING THE HOUSING Note Prior to cleaning the exterior, protect the power inlet, top grating, Dust collector flap openings and further case openings to (interior) electrical components from water ingress with appropriate means. After observing chapter 10.1, clean the housing with a soft, mist-damp and lint-free cloth. Ensure that no moisture enters the housing. Protect electrical components from moistu- re. Do not use any aggressive cleaning agents such as cleaning sprays, solvents, alcohol- based or abrasive cleaners to dampen the cleaning fabric. Wipe the housing dry after cleaning. 10.3. DUST COLLECTOR CHANGE (ONLY BY AUTHORIZED SPECIALIST COMPANIES) • By authorized specialist company (production batch 2020-12) • B y authorized specialist company or skilled electrician“ since 2021-01 (production with interlock) Warning of electrical voltage and UV light danger The Dust collector must only be replaced by authorized specialist companies or by the manufacturer.
Page 16 ATMOFIZER PRO – USER MANUAL – 10. MAINTENANCE Fuse Exchange 10.4 FUSE EXCHANGE Caution: Be sure to replace with same capacity (amperage) as displayed on the fuse. Use Only 250V Fuses. This product is 10A. Removal • Open the fuse holder e.g. using a screwdriver blade • Gently extract the fuse from the holder. Insertion • Insert the fuse gently into the fuse holder. • Push in the fuse holder all the way with your finger. 10.5. MAINTENANCE INTERVALS BEFORE AT LEAST 4,000 OPERA- MAINTENANCE AND EVERY...
Page 17: Errors And Faults
ATMOFIZER PRO – USER MANUAL – 10. MAINTENANCE / 11. ERRORS AND FAULTS 10.6. MAINTENANCE AND CARE LOG (SAMPLE) Device type Serial number MAINTENANCE AND CARE INTERVAL Check air filter, air inlets and outlet for dirt and foreign objects and clean if necessary Check for damage Replace G4 Dust collector Exterior cleaning Test run Full inspection by autho- rized specialist company Date Date Date Date Signature Signature Signature Signature Date Date Date Date Signature Signature Signature...
Page 18: Spare Parts And Accessories
ATMOFIZER PRO – USER MANUAL – 11. ERRORS AND FAULTS The device gets very warm, is loud or is losing performance: • Switch off the device before further checks. • Check the air inlets, air outlets and air Dust collectors for dirt. Remove external dirt. • F rom the outside, check the device for dirt (see chapter Maintenance). If the inside of the device is dirty, have it cleaned by a manufacturer authorized company. The device interferes with phone calls and video conferences: • S ome cell phones, noise suppression and video cameras respond to ultrasound recor- dings by audible noise on playback. A buzzing noise may be imposed on recordings taken in close proximity the device. In order to avoid audio disturbances, test before audio or...
Page 19: Recycling And Disposal
The separate collection of waste electrical and electronic equipment aims to enable the reuse, recycling and other forms of recovery of waste equipment as well as to prevent ne- gative effects for the environment and human health caused by the disposal of hazardous substances potentially contained in the equipment. • I n accordance with the Waste Disposal Act, the following components must be disposed of and recycled in an environmentally sound manner via appropriate collection points: o Old device o Consumable parts o Defective components o Electrical or electronic scrap • E nvironmentally compatible means separated according to material groups in order to achieve the maximum possible reusability of the basic materials with the lowest possible environmental impact. • D ispose of cardboard packaging, recyclable plastics and plastic filling materials in an environmentally friendly manner via appropriate recycling systems or recycling centers. • Observe the relevant country-specific or local regulations. 14. DECLARATION OF CONFORMITY This product complies with the requirements of the applicable European and national directives. Corresponding declarations and documents are deposited with the manufacturer. The product complies with the requirements of the German Equipment and Product Safety Act. The signed declaration of conformity can be found at ATMOFIZER PRO https://atmofizer.com/documents We reserve the right to make technical and optical changes to the product in the course of product improvements. Subject to typographical and printing errors...
Page 20 MANUFACTURED FOR: THE BETTER TOMORROW PROJECT LLC 1680 MICHIGAN AVE, SUITE 817 MIAMI BEACH, FL 33139 BREATHE WITH CONFIDENCE. www.atmofizer.com...
