- Page 1 Instruction manual IPSO RI 800-16 Technical specifi cations Installation instructions Operating instructions Maintenance Nieuwstraat 146 - B-8560 Wevelgem (België) Tel. 056/41 20 54 - Fax 056/41 86 74 Part No. D0163...
-
Page 2: General Information
General Information Dear Customer, Please read the instructions for use before first using your ironing machine. These instructions provide important information on safety, use and maintenance of your appliance. They will protect you and prevent damage to the appliance. Keep these instructions for use in a safe place and pass them on to any subsequent owners. - Page 3 DESCRIPTION The ironer can iron and press. During ironing the roll turns, during pressing the roll is stationary. The footswitch has two working functions and one stationary fonction. In the working position, the ironing plate is swung in, so you can iron or press.
-
Page 4: Technical Information
TECHNICAL INFORMATION Standards Characteristics Electrical connection Dimensions Weigth Height (up to the lower part of the base plate) Roller Length Roller Diameter Roller Pressure Rotation Distance between Ironing plate and roller (swung away) Quantity of thermostats Heating element Motor load Transmission On/Off switch (rocker switch) _________________________________________________________________________________________... - Page 5 The ironing plate does not heat up Does not iron equally along the whole length The pressure of the ironingplate is too low. During ironing, the roll is too noisy The roll does not rotate during ironing...
- Page 6 The closing of the ironingplate does not function when the footswitch is activated. Roller rotates even when the footswitch is not activated. The ironingplate rests against the roll when the footswitch is not activated. _________________________________________________________________________________________ Rotary ironer RI800-16 Technical data for customer service 1.
-
Page 7: Electrical Diagram
ELECTRICAL DIAGRAM _________________________________________________________________________________________ Rotary ironer RI800-16 Technical data for customer service 04/2005... - Page 8 Table of contents – Technical Data General information ... List of contents – Technical data ... Safety information ... Electrical safety ... Important information ... Safety functions ... Ironer - overvieuw ... Setting up the ironer ... Operator’s controls ... Before ironing ...
-
Page 9: Safety Information
Safety Information Safety Information Intended use! The ironing machine must only be used to iron fabrics that are suitable as indicated by the care label and that have been washed in water. Treat printed or plastic motifs with care. Caution, keep away from children! The appliance must only be used by adults. -
Page 10: Electrical Safety
Electrical Safety Electrical Connection The ironer is equipped with a power cord and plug. It may only be connected, via a plug and socket with earth connection, to 220-240 volt, 50 Hz. § The connection is approx. 2.6 kW. The required fuse is 16 ampere. The appliance complies with the VDE regulations. - Page 11 Important Information When ironing small items of laundry, we recommend using only half of the ironing surface and setting the unneeded thermostat to “Cold”. This will save energy and protect the ironing cloth from brown discoloration. Cold Upon the very first heating of the appliance, smoke may briefly appear. This is quite normal and will quickly disappear.
-
Page 12: Safety Functions
Safety Functions Temperature safety device The heating element of the ironing machine is controlled by two temperature selectors and a temperature safety device. If the heating element overheats due to a fault, the temperature safety device will interrupt the current, preventing further damage. Please contact the relevant service point (see warranty documents) to ensure that the cause of the cut-out is eliminated and the temperature safety device is correctly replaced. - Page 13 Ironer - Overview Ironer in transport position (folded position) with casters Ironer in working position Finger guard Feed board Ironing roller with free wheel Ironing table Footswitch Unfolding the ironer 2 temperature Ironing plate selectors On/off switch (rocker swith) Speed control Release lever pull the release lever Power cord at back...
- Page 14 (claw) into the bolt from below and let the movable fixing washer enclose the bottom of the bolt. If you wish to iron without the feed board, remove it in the reverse order. Experiment to see whether you prefer to iron with or without the feed board!
-
Page 15: Operator's Controls
Operator’s controls On/off switch (rocker switch) The appliance is switched on/off with the on/off switch. The red rocker switch illuminates when the appliance is switched on. with red pilot light Idle position Pressing position Ironing position Free movement of the ironing roller To facilitate handling, the ironing roller has a completely forwards free movement. -
Page 16: Before Ironing
Also lay the laundry out in this order. Iron starched laundry last, so that starch residues that may cling to the ironing plate are not transferred to other items. - Page 17 The ironing temperature is correctly set when the dot symbol lines up with the “? ” marking on the ironing plate cover. Always start ironing at a lower temperature setting and iron the more delicate fabrics first. Wait for at least 5 minutes after switching on the heating element, to allow adjustment to the selected temperature.
- Page 18 Wide sheets and tablecloths Iron one half first of all, letting the unironed fabric side hang out on the open roller side. Then feed in and iron the other half. Now iron the fabric folded up lengthways. The selvages should be positioned on top of one another and the fold should hang out at the free roller end.
- Page 19 Ironing Iron the front of the buttons as for the front of the buttonholes, but from the wrong side, so that the buttons can press into the roller covering and do not scrape the surface of the ironing plate. Iron the collar lengthways (first the under side, then the top side). Turn just before the collar tip and then iron from the collar tip as far as the collar band.
- Page 20 Care of your ironing machine Cleaning the ironing plate Note: During cleaning, take the mains plug out of the socket completely and allow the machine to cool down first! Starch and finishing can leave a coating on the ironing plate. The plate should therefore be cleaned after prolonged use of the ironer.
- Page 21 Procedure in the event of faults / Customer service If your appliance gives you any cause for concern or if a fault occurs, please contact your specialist dealer or one of the customer service points listed in the attached warranty documents.
