toolset
– Instruction Manual
X – axis fine adjustment
Z – axis fine adjustment
Page 1
LCD Display
Keyboard
Turn the knob left or right and the clamping will be loosed
innotool austria Gerätebau GmbH / Oberhub 11/ 6844 Altach / Austria
T +43 5576 790 40 / F +43 5576 790 41 / office@innotool-austria.com
Counter-weight lock screw
use a 4mm hex. wrench
Adjustable guide rail
Z – axis lock
X – axis lock
Dual axis indicator head
Precision spindle
Advertisement
Table of Contents
Summary of Contents for innotool toolset
- Page 1 LCD Display Keyboard Turn the knob left or right and the clamping will be loosed Page 1 innotool austria Gerätebau GmbH / Oberhub 11/ 6844 Altach / Austria T +43 5576 790 40 / F +43 5576 790 41 / office@innotool-austria.com...
- Page 2 PACKAGING: Please use the original transport elements if you have to send the TOOLSET back to the supplier (for maintenance). Transportation elements are: transportation cardboard, wood board with the three screws and the plastic elements, Indicator pad.
- Page 3 Reference correction is possible in the set menu. The main menu is reached using the procedure described (depress Set about 3 seconds immediately after ESC). Select the TOOLSET reference in the main menu (depress number 1) which brings up the reference menu.
