Summary of Contents for LiuGong LEC014
- Page 1 User Guide LEC014 GPS/BDS Dual-Mode GNSS Vehicle T-BOX Guangxi Liugong Machinery Co., Ltd. www.liugong.com...
- Page 2 The contents of this document are subject to change without notice due to continued progress in methodology, design and manufacturing. Liugong shall have no liability for any error or damage of any kind resulting from the use of this document.
- Page 3 Liugong accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the device, or for failure of the router to transmit or receive such data.
- Page 4 LEC014 T-BOX User Guide Connect the T-BOX only according to the instruction manual. Failure to do it will void the warranty. In case of problem, please contact authorized distributor. FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 5 LEC014 T-BOX User Guide Regulatory and Type Approval Information Table 1: Directives 2013/56/EC Directive 2013/56/EU of the European Parliament and of the Council of 10 February 2013 on the restriction of the use of certain hazardous substances in electrical and...
- Page 6 LEC014 T-BOX User Guide Document History Updates between document versions are cumulative. Therefore, the latest document version contains all updates made to previous versions. Date Firmware Version Document Version Change Description May. 15, 2018 1.0.0 v.1.0.0 Initial release Jun. 29, 2018 1.0.0...
-
Page 7: Table Of Contents
LEC014 T-BOX User Guide Contents Contents ................................7 Chapter 1 Product Concept ........................... 8 1.1 Overview ................................8 1.2 Package Contents ..............................9 1.3 Specifications ..............................9 1.4 Dimensions ................................ 10 1.5 Ordering Information ............................11 Chapter 2 Hardware Installation .......................... 12 2.1 PIN Assignment .............................. -
Page 8: Chapter 1 Product Concept
LEC014 T-BOX User Guide Chapter 1 Product Concept 1.1 Overview LEC014 is a vehicle T-BOX with GPS/BDS dual-mode GNSS to send location information to server. It enables to communicate with vehicle electronic equipment, monitor vehicle status and control vehicle operation through CAN page. -
Page 9: Package Contents
LEC014 T-BOX User Guide 1.2 Package Contents Before installing your LEC014 T-BOX, verify the kit contents as following. Note: The following pictures are for illustration purposes only, not based on their actual sizes. 1 x LEC014 GPS/BDS dual-mode GNSS T-BOX Note: This product without other optional accessories. -
Page 10: Dimensions
LEC014 T-BOX User Guide Wet contact (DI): positive Maximum withstand voltage: ≤Input voltage Other 1xRTC 1xWatchdog (built-in) LED indication 1xRUN， 1xGPS ，1xNET Power Supply and Consumption Interface type: 16 pin ITT132015-0074/12 pin DTM06-12SX Supply voltage: 9~36V DC ... -
Page 11: Ordering Information
LEC014 T-BOX User Guide 1.5 Ordering Information Product Type LEC014 Air Interface GSM/GPRS/EDGE/WCDMA/HSDPA/HSUPA/HSPA+ GSM:800/850/900/1900/2100 MHz ;WCDMA: Band1/2/5/6/8 Frequency Bands Operating -30~+45 °C Environment 5~95% RH Storage -40~+85 °C Temperature *For more information about frequency bands, please contact your sales representative. -
Page 12: Chapter 2 Hardware Installation
LEC014 T-BOX User Guide Chapter 2 Hardware Installation 2.1 PIN Assignment 16PIN automobile cables as shown below, marking the serial number and the definition of each PIN: Serial Number Cable Color Signal Name Blue Generator D+ Green Brown CAN_L Black... - Page 13 LEC014 T-BOX User Guide (available for low electric level) Valid: T-BOX collects the get-on data of generator Invalid: T-BOX collects the get-off data of generator Yellow-and-green Switch (available for low electric level) Black-and-white Switch (available for low electric level) 12PIN excavator cables as shown below, marking the serial number and the definition of each PIN:...
-
Page 14: Led Indicators
LEC014 T-BOX User Guide 2.2 LED Indicators Name Color Status Description Solid External power on. External power off. blinking GPS received signal. Solid GPS disconnected. Green Blinking Cellular network connected successfully. Solid Cellular network disconnected. LEC014T-BOX RT_UG_ _v.1.0.2 Sep. 28, 2018... -
Page 15: Glossary
LEC014 T-BOX User Guide Glossary Abbr. Description T-BOX Remote Information Processor LPWAN Low Power Wide Area Network Controller Area Network Universal Serial Bus Digital Input Digital Output Global Positioning System Compass Navigation satellite System Global System for Mobile Communications WCDMA... - Page 16 LEC014 T-BOX User Guide Guangxi Liugong Machinery Co., Ltd. No.1 Liutai Road, Liuzhou, Guangxi P.R. China Address: 0772-3886981 Tel: lgrc@liugong.com Email: LEC014T-BOX RT_UG_ _v.1.0.2 Sep. 28, 2018 16/24...
