Squid UV User Manual

Curing system gen 2
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Squid UV
Squid UV LED
Curing System Gen 2
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UV and is the answer not in the manual?

Questions and answers

Summary of Contents for Squid UV

  • Page 1 Squid UV Squid UV LED Curing System Gen 2 User Guide...
  • Page 3 User Guide Revised 3/15/2018 P/N 1505040 Rev B Gen 2 Copyright and Trademarks Copyright ©2018 Squid Ink Manufacturing. All rights reserved. All trademarks and brand names are the property of their respective owners. Squid Ink Manufacturing 7041 Boone Ave. N Brooklyn Park, MN 55428 Phone: (763) 795-8856;...

  • Page 5: Table Of Contents

    Maintenance ........................ 36 Controller........................36 Illumination Module ..................... 36 General Maintenance ......................36 Replacing the UV Glass Bottom Plate ..................37 Illustrated Parts Breakdown ..................38 Single UV LED Mounting Kit ..................38 Dual UV LED Mounting Kit ..................39 Warranty Statement ............Error! Bookmark not defined.
  • Page 6 Warranty Eligibility ............Error! Bookmark not defined. Customer Support ....................... 43 Squid Ink Technical Service ..................43...
  • Page 7 Safety 7...

  • Page 8: Safety

    RISK GROUP 3 UV EMITTED FROM THIS EQUIPMENT Avoid eye and skin exposure to unshielded equipment UV Safety Squid UV LED Curing System light sources are classified as Risk Group 3 under IEC 62471, at a distance of 200mm. Scope of IEC62471 The IEC62471 standard “Photobiological Safety of Lamps and Lamp Systems”...

  • Page 9: Shielding

    Risk Group 2 – Moderate Risk: Does not pose a hazard due to aversion response to very bright light sources or due to thermal discomfort. A portion of UV light source will be visible and be a strong stimulus.

  • Page 10: Safety Shielding Enclosure

    10 Safety Safety Shielding Enclosure The user will need to create a safety shielding enclosure around the UV lamp to protect workers from exposure to ultraviolet light. If possible, only place the lamp within the enclosure, and install the printer outside of the enclosure. The enclosure should be made with a non-reflective material which is especially important if the printhead must be mounted inside the enclosure.
  • Page 11 Conveyor Direction 1826 Illumination Module Printhead Squid Ink recommends that the printhead be cleaned at the end of each day, and covered when not in use.

  • Page 12: Placement Of Printhead And Illumination Module

    12 Safety Placement of Printhead and Illumination module Conveyor Direction Printhead Illumination Module 1822...

  • Page 13: Suggested Enclosure Criteria

    Safety 13 Suggested Enclosure Criteria Non- Welding Cloth Reflective or Equivalent Material Hinge Mounting 1823 Brackets...

  • Page 14: Introduction

    Introduction General System Description The Squid UV LED Curing System will cure UV Curable inks on a variety of substrates. The illumination area is .80” (20mm) X 3.2” (80mm). The Squid UV LED consists of a Controller, illumination module, data and power cables.

  • Page 15: Parts List

    2005117 Tinted Safety Glasses 1505040 User Guide 2005111 Safety Shield 2005110 Mounting Brackets 1505030 UV Glass and Bottom Plate (Replacement Only) Dual Module Part Number 1505026 Item Description 1505031 Controller with Touch Panel Dual 1505029 Illumination Module 1505017 Data Cable Controller to Illumination Module...

  • Page 16: Controller Overview

    16 Introduction Controller Overview Equipment Label Carrying Touch Screen Handle Cooling Vents RS232 Connector Db25 Connector CH1 Db25 Connector CH2 (Dual Head Carrying Only) Handle Power Switch Cooling Power Receptacle Emergency Stop (EMG Wiring Header...

  • Page 17: Illumination Module Overview

    Introduction 17 Illumination Module Overview Mounting Holes Cooling Vents Cooling Vents (Air Inlet) (Air Outlet) Mounting Holes Db25 Connector to Controller Serial Number Mounting Holes UV Illumination Surface Cooling Vents (Air Outlet) Illumination Module...

  • Page 18: Assembly And Installation

    18 Assembly and Installation Assembly and Installation Position the Illumination Module Position the illumination module a short distance downstream from the printhead. Variables such as substrate type, ink formulation, and line speed will affect curing time. Generally, the closer the illumination module is to the printhead, the better the results. Mount the illumination module as far downstream as possible from the printhead with at least 2-1/2”...

  • Page 19: Mounting Hardware

    Mounting Hardware Each installation is unique, so we cannot anticipate all mounting requirements for each installation site. Squid Ink Manufacturing has made available a mounting kit for the single and dual lamp systems that should satisfy most mounting requirements. Should it be necessary to construct custom mounting brackets, there are several mounting holes on the Illumination Module for mounting screws.

  • Page 20: Single Uv Led Module

    20 Assembly and Installation Single UV LED Module Mounting UV LED Bracket Illumination Module Supplied Mounting Screws and Washers Floor Stand (Sold Separately) Single UV LED Mounting Kit Part #2005110 CoPilot Printhead Illumination Module with Safety Shield...

  • Page 21: Dual Led Modules

    Assembly and Installation 21 Dual LED Modules Dual LED Modules Mounting Bracket Screws with Washers Mounting Bracket Safety Shield Mounting Screws Safety Shield Attention! Do not power up and operate this equipment without the safety shield in place.

  • Page 22: Attaching The Air Deflector

    Illumination Module. The purpose of the Air Deflector is to keep the exhausted air from the Illumination Module from blowing directly onto the ink before it has a chance to pass under the UV Curing Lamps. Attention! You must use a 2mm Allen wrench to remove and replace the mounting screws.
  • Page 23 Assembly and Installation 23 Floor Stand (Sold Separately) Dual UV LED Mounting Kit Part #2005109 CoPilot 382 Printhead Air Deflector Mounted on the Printhead Side Dual Illumination Modules with Safety Shield...

  • Page 24: Connections

    24 Assembly and Installation Connections...
  • Page 25 Assembly and Installation 25...
  • Page 26 26 Assembly and Installation...

  • Page 27: Input And Output Specifications

    Assembly and Installation 27 Input and Output Specifications Db9 Pin Locations...

  • Page 28: Operation

    Operation Power Up Connect the power cord to the “AC IN” location on the UV LED Controller and plug the power cord into a properly wired and grounded power source. To power up the Squid Ink UV Curing System, press the power switch to the “ON”...

  • Page 29: Main Screen

    Operation 29 Main Screen Toggle Lamp Channel On and Off Number Lamp State (On or Off) Current Intensity Current Running Time Open the “Warning” Current Open the Open the User Screen Running “Settings” Guide Temperature Screen...

  • Page 30: Warning Screen

    Return to the Main Screen Return LED Head connection Reach on LED life LED over heat Power supply error 1514 When this Icon is Click to View the Current present, please contact UV Lamp Temperature the manufacturer for troubleshooting...

  • Page 31: Settings Screen

    Operation 31 Settings Screen The “Settings” Screen will allow you to make changes to the system parameters. To open the “Settings” Screen select “Settings” from the “Main” Screen. A numeric keyboard will appear. Touch a Character to open the On-screen Return Keyboard 1827...

  • Page 32: Emg (Emergency Stop)

    If an EMG Switch is not connected the “EMG” button must be set to Red. If an emergency stop switch has been connected to the UV System controller use the “EMG” button to select the condition under which it will operate.

  • Page 33: System Parameters

    Operation 33 System Parameters After highlighting the desired function, select the “Tools” Icon in the “Settings” Screen to change the System Parameters. Level: Highlight “Level” and select the “Tools” Icon to open the intensity screen. Select the value in the “Intensity” box and use the onscreen keyboard to enter a new value.

  • Page 34: Timer

    “OK”. Select “Save setting” to save and exit. Select “Yes” to save or “No” to cancel and exit. Attention! Setting the time to Zero (0) will place the UV Curing System in Manual Mode and turn the lamp on indefinitely. Use the Toggle On/Off Button to turn the light on and off.

  • Page 35: Advance

    Operation 35 Advance: The Advanced settings are used to enable the user further triggering options. Pressing the button brings up this screen: Steps Return Advance step Intensity Time step 4 step 1 step 5 step 2 step 6 step 3 step 7 Save setting Repeat...

  • Page 36: Maintenance

    36 Operation Maintenance The Squid UV LED Curing System requires very little maintenance. The following procedures will help ensure a smooth and safe operation. A note about maintenance scheduling: The maintenance and inspection schedule is subject to the operating environment. If the equipment is exposed to constant vibration and a contaminated environment, frequent inspection and cleaning should be performed.

  • Page 37: Replacing The Uv Glass Bottom Plate

    To replace the Bottom Plate with UV Glass: Turn the power switch to the “OFF” position and disconnect the UV Curing System from the power source. Disconnect the Data Cable from the UV Controller to the Illumination Module.

  • Page 38: Illustrated Parts Breakdown

    38 Illustrated parts List Illustrated Parts Breakdown Single UV LED Mounting Kit Single UV LED Mounting Kit 2005110 Single UV LED Curing System 2005110...

  • Page 39: Dual Uv Led Mounting Kit

    Illustrated Parts List 39 Dual UV LED Mounting Kit Dual UV LED Curing System 2005109...
  • Page 40 40 Warrenty Statement...

  • Page 41: Warranty Statement 41

    Return Material Authorization number and may return the defective item to Squid Ink. Squid Ink will analyze the product and, if indeed found to be defective, we will, at our option, replace or repair the item. If the item is found not to be eligible for warranty, you will be notified and may decide on disposition.
  • Page 42 42 Warrenty Statement Warranty Eligibility The warranty provided by Squid Ink Manufacturing, Inc. is only to the original buyer. Limited Warranty THE ABOVE WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, WHETHER EXPRESSED OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.
  • Page 43 Ink Technical Service at one of the numbers listed below. Toll-Free Phone 800-877-5658 Phone 763-795-8856 763-795-8867 E-mail info@squidink.com www.squidink.com Thanks again for your purchase of Squid Ink products. We are pleased to be a part of your marking and coding needs.
