Skyradiometer
POM-02
Operation Manual
(For Windows OS)
th
12
April 2016
Prede Co., Ltd.
Head Office: 1117, Kusabana, Akiruno-shi, Tokyo, 197-0802, Japan
Research Center: Sasamoto Bldg. 1-26-8, Kamidaira, Fussa-shi, Tokyo, 197-0012, Japan
TEL: +81-(0)42-539-3755
FAX: +81-(0)42-539-3757
URL:
http://www.prede.com/
E-mail:
sales@prede.com
Advertisement
Summary of Contents for Prede POM-02
- Page 1 Skyradiometer POM-02 Operation Manual (For Windows OS) April 2016 Prede Co., Ltd. Head Office: 1117, Kusabana, Akiruno-shi, Tokyo, 197-0802, Japan Research Center: Sasamoto Bldg. 1-26-8, Kamidaira, Fussa-shi, Tokyo, 197-0012, Japan TEL: +81-(0)42-539-3755 FAX: +81-(0)42-539-3757 URL: http://www.prede.com/ E-mail: sales@prede.com...
- Page 2 [Index] Specifications <POM-02> Installation Condition of the installation Installation procedure Setting Setting Screen Specification of the operation -10- Standard Operation -10- Special Operation -12- Observation -14- Observation Screen -14- Aerosol Observation Screen -16- X-Scan Screen -17- Disc Scan Screen -18-...
-
Page 3: Specification
Specification POM-02 Skyradiometer measures circum solar radiation and spectrum intensity of the direct solar radiation for the research of the size distribution and concentration of the aerosols. In addition to the feature of POM-01, POM-02 also measures the long wave length. -
Page 4: Installation Procedure
Installation Condition of the installation Skyradiometer shall be installed under the clear sky (Sun sensor need to react during the installation) Mount the tracker on the sold and flat place, with free field of view, especially in the direction of East-South-West. - Page 5 NOTE: Connector 4, 5, 6, 7 are the single lock type. Align the guide of the plug and receptacle, and push the plug straight until it makes the “click” sound. (5key type of guide can be easily aligned by slightly rotating the plug) NOTE: Do not twist the lock nut, when inserting the plug.
- Page 6 4. Adjust the horizontality of the skyradiometer by using a water bubble on the leg of sun tracker. It is necessary to maintain the sun tracking accuracy. 5. Fix the skyradiometer on the mounting base, by using 3 pieces of screws, included in the package. NOTE: It is necessary to fix skyradiometer to the flat and robust mounting base, for the fall-prevention against the strong wind.
- Page 7 7. Connect the Communication cable(RS232) and Power cable (AS3P). NOTE: Prior to the connection of the power cable, make sure that there would be no obstacles around the skyradiometer, since it automatically start the origin search movement, immediately after connecting the power cable.
- Page 8 11. Make sure that the sun light is on the center of the target. Skyradiometer might not track the sun correctly in case the position of the sun light is far out of the center. NOTE: Do not touch to the target. 12.
-
Page 9: Setting Screen
OS: Windows XP / Vista / 7 (32bit/64bit) POM02_SET ********.exe, and configure the observation program. First of all, execute the NOTE: ******** is the version of release (Updated date) Folder will be automatically generated at the directly of C:¥pom-02¥data C:¥pom-02¥obs Setting Screen ※１ ※2 NOTE: Configure the following items at the setting screen. - Page 10 (Files to be generated : .sun, .data, .cld) Example: In case the storing directory was set as C:¥POM-02¥Data, folder will be generated automatically with each date, and the data will be stored with the file name of observation date, such as C:¥POM-02¥Data¥20160315. Configuration of measurement data : Set the method to generate the measurement data.
-
Page 11: Standard Operation
Specification of the operation Standard Operation Followings are the specification of the skyradiometer’s movement (Numeric values can be modified in the Setting Screen) 1. Start (end) of the observation : Start at Airmass <=10 (Start) Airmass＜=10 (End) Airmass＞=10 Ex.Observation Starting/Ending Airmas ＝10 2. - Page 12 3. Direct sun observation interval : Time (60 sec) 4. Direction of Aerosol observation : Observes horizontal direction of east and west alternately. However, skyradiometer observes vertical direction (Zenith to North) when the sun altitude exceeds 75 degrees. 1st observation 2nd observation φ=0 φ=180...
- Page 13 Disk scan schedule : Disk scan schedule (interval, day and time) can be modified in the setting screen. (Default: every 7 days, 10:00a.m.) Each wavelength with the check in the “Disk” of Wavelengths Setup will be scanned once, when the sky is clear and time reached to the set time Time Correction of the tracker : 23:00 (Every day) : synchronize the clock of the tracker and PC.
- Page 14 ■ Both Side Both side will be scaned in each observation When the airmass went below the threshold (4.5), scattering angle will be 180 deg., and direction of the scattering scan will be normal movement of; Before noon: Clockwise After noon: Counter Clockwise However, if “Both Side”...
- Page 15 Observation 設定の編集が完了しましたら、POM02_CNT ********.exe を実行し、観測プログラムを開始してください。 ※ ********はリリースバージョン（更新日） Observation screen Yellow frame ： Graphic display of direct beam measurement data, since the observation program has started. X axis = Time, Y axis = Output [A] - 14 -...
- Page 16 Green frame ： Display of time, setting, status, and measurement date. [Time] ： Time of PC Local Time ： Local time ： Universal time coordinated [Setting] ： Setting Longitude ： Longitude of the installation site Latitude ： Latitude of the installation site Place ：...
- Page 17 Aerosol Observation Screen Graphic display will be automatically switched and measurement result will be displayed when aerosol observation has started. - 16 -...
- Page 18 X-Scan Screen Graphic display will be automatically switched and the X-scan result will be displayed, X-Scan is the process to align the optical axis. This process is recommended when the skyradiometer was relocated and re-installed. Adjust the values of Azimuth center and Altitude center within +/- 0.050, by the screws.
- Page 19 Disc Scan Screen Graphic display will be automatically switched and the Disk Scan results will be displayed. Please carry out the Disc Scan on the regular basis (Periodically) Automatic disc san is available by the setting on the observation program. NOTE: X-Scan needs to be carried out under the clear sky.
- Page 20 Each parameter is aligned with the following order with comma-delimited fixed length format. 1st line: Type of POM(6), Tracker S/N(7), Sensor S/N(7), Latitude(8), Longitude(8), Date/GMT(8), Time/GMT(8), Date/LT(8), Time/LT(8) 2nd line: Number of channels, 1ch, 2ch, 3ch, …… 11ch (Information of the wavelength) [Example] POM-02,1822105,1957002, 139.315, 035.738,09/05/19,20:10:05,09/05/20,05:10:05 11,0315,0340,0380,0400,0500,0675,0870,0940,1020,1627,2200 - 19 -...
- Page 21 1. Normal observation data File name : 09052000.dat…Date of observation = 20 May 2009, File number = 00 [Example] 09/05/19,20:30:05,09/05/20,05:30:05,H,Fussa, 20:30:05,05:30:05,-106.89,009.62,3.6880E-09,1.9538E-09,1.3190E-08,1.7071E-07,3.8078E-06, ～ 2.6970E-05,4.6799E-05,4.9362E-06,4.6783E-05,6.5872E-05,3.4393E-05,-21.3,18.1,0000 1st line: Observation date(GMT), Observation start time(GMT), Observation Date(LT), Observation start time (LT), type of Observation, name of installation site. type of observation H: Horizontal scan / V: Vertical scan Header will be added after each observation.
- Page 22 3.Disc scan observation data File name: 09052600.V01 : Observation date = 26 May 2009, Filter channel = 1, File number = 00. [Example] 09/05/26,05:13:41,09/05/26,14:13:41,D,315,Fussa, -1.0,9.0790E-12,1.0757E-11,1.2512E-11,1.4191E-11,1.6556E-11,1.9302E-11,2.1973E-11,…… -0.9,1.0529E-11,1.2283E-11,1.4496E-11,1.6785E-11,2.0370E-11,2.3880E-11,2.8534E-11,…… 1.0,8.4686E-12,9.9182E-12,1.1215E-11,1.2817E-11,1.4648E-11,1.6403E-11,1.8234E-11,…… 1st line: Observation date(GMT), Observation start time(GMT), Observation date(LT), Observation start time (LT) Type of observation, Name of installation site, Type of observation D: Disk scan Header will be added in every observation.
- Page 23 5. Observation setting file User can set the file name by themselves. (File extension is .obs) Contents of the file is as follows. This can be edited by the setting program. #POM-02 SettingFile : 1. Header PS000000 : 2. Sensor serial number PS111111 : 3.
-
Page 24: User Maintenance
User Maintenance Skyradiometer cleaning procedure Before the maintenance, please terminate the observation program and disconnect the power cable. - Replacement of Silica gel Silica gel case is locating under the cable connector of the sensor. Remove the case and check the color of silica gel. - Page 25 - Cleaning of Sun sensor Wipe the glass window part of the sun sensor by the liquid cleaner (Ethanol/Alcohol with cotton SWAB). - Cleaning of Rain sensor Wipe the detector part of the rain sensor by the liquid cleaner (Ethanol/Alcohol with cotton SWAB), in case there were any dirt on its surface.
- Page 26 Sensor carrying case ・Exterior appearance ・Interior appearance Rain sensor Sensor cable×3 Tool box Insulation plate×2 Sensor - 25 -...
