Summary of Contents for Aurora Scientific 826A
- Page 1 Water Cooler 826A Publish Date: 7/6/2015 Manual Version 1.00 www.AuroraScientific.com © Aurora Scientific, 2015 VER. 1.00 page 1...
- Page 2 Water Cooler Instruction Manual Model: 826A Copyright © 2015 Aurora Scientific. Aurora Scientific 25 Industry Street Aurora, ON, Canada L4G1X6 Tel: 1-905-727-5161 Toll Free (N. America): 1-877-878-4784 Fax: 1-905-713-6882 Email: techsupport@aurorascientific.com Web Site: www.AuroraScientific.com © Aurora Scientific, 2015 VER. 1.00...
- Page 3 Water Cooler Instruction Manual Model: 826A Revision History Date Version Document Changes Number 07/06/2015 Initial Draft © Aurora Scientific, 2015 VER. 1.00 page 3...
-
Page 4: Table Of Contents
4.2 ..Technical Support ........................... 10 4.3 ..Technical Support Contact Information and Return Shipping Addresses ........10 4.4 ..Warranty ............................11 4.5 ..Returning Products to Aurora Scientific for Repair ................. 12 Specifications ..........................14 © Aurora Scientific, 2015 VER. -
Page 5: Introduction
Model: 826A 1 Introduction The 826A Water Cooler is intended to be used as a simple liquid coolant circulator, with Aurora Scientific 800 Series apparatus. The Water Cooler incorporates a brushless DC pump to circulate the water through an aluminum radiator to exchange heat with the air. -
Page 6: Quick Start Guide
2.1 Attaching the Liquid Coolant Lines Two lengths of tubing, both six feet in length have been supplied to attach the 826A Water Cooler to an Aurora Scientific 800-Series Test System. The Tubing has been pre-fitted with the required fittings to easily connect to the test system. -
Page 7: Positioning The Unit
DO NOT locate the coolant circulator on it as this will cause vibration noise to appear in the data. Since the head pressure generated by the pump is small, the 826A Water Cooler should be mounted slightly above or at about the same height as the test system. Take care to mount the unit within ±0.5m of the height of the 800-series apparatus or the circulator will have trouble driving coolant through the entire loop. -
Page 8: Module Operation
2.4 Module Operation Once all of the connections have been made and the coolant reservoir filled, the 826A is ready for use. The coolant circulator does not have a power switch, as it draws its power from a tap on the rear of the 825A. -
Page 9: Maintenance
If you run out of coolant, distilled water can be used to top up the system. DO NOT use ordinary tap water, as this will corrode the aluminum radiator inside the unit. Additional bottles of coolant can be ordered from Aurora Scientific in the event that the coolant supplied with the system runs out. © Aurora Scientific, 2015 VER. -
Page 10: Performance Guarantee, Technical Support, Warranty And Repair Information
Our performance guarantee states: if for any reason a new product does not meet your research needs then you can return it to Aurora Scientific for exchange or a full refund. The performance guarantee only applies to new products and must be exercised within 60 days of receipt of the instrument. -
Page 11: Warranty
Products manufactured by Aurora Scientific Inc. are guaranteed to the original purchaser for a period of three (3) years. Under this warranty, the liability of Aurora Scientific is limited to servicing, adjusting and replacing any defective parts that are of Aurora Scientific manufacture. Aurora Scientific is not liable to the customer for consequential or other damages, labour losses or expenses in connection with or by reason of the use or inability to use the products manufactured by Aurora Scientific. -
Page 12: Returning Products To Aurora Scientific For Repair
Address and Phone Number (your company information), Consignee's Name, Address and Phone Number (Aurora Scientific Inc. is the Consignee), Country of Origin of Goods (this will be Canada if you purchased the instrument from Aurora Scientific or USA if your product was purchased from Cambridge Technology), Conditions of Sale (include the following statement: GOODS RETURNING TO FACTORY FOR REPAIR, TEMPORARY IMPORT), Number of Packages (normally 1), Description of Goods (e.g. - Page 13 European Clients: ship your instrument to Aurora Scientific Europe in Dublin, Ireland. Asia, Australia and New Zealand Clients: ship your instrument to Aurora Scientific Asia in Hong Kong. Canadian, USA and all other Clients: ship your instrument to Aurora Scientific in Ontario, Canada.
-
Page 14: Specifications
350 L/h (1.54 US Gal/min) @ 12VDC Voltage: 12 VDC Current: 0.3A Speed: 1800 RPM Air Flow : 74.4 CFM Pressure: 3.2 mm water Electrical Power Requirements: 12 VDC, 1.25A max. (Powered from power tap on 825A) © Aurora Scientific, 2015 VER. 1.00 page 14...
